SARMOG 623 Assembly Instructions

Misure / Measures
Sp. 16mm
76,8cm
Componenti / Elements
13
7
1
5
12
3
8
11
4
10
Mobile 3 ante
1 cassetto
3-door 1-drawer
Schiena
Backrest
Sp. 3mm
h.101cm
174cm 179cm
h.55cm
l/w.42cm
5cm
34,3cm
2
6
9
16
15
14
unit
Dettagli / Details
- Struttura materiale in truciolare nobilitato
- Maniglie e piedini cromo satinato
- Guide cassetto in metallo
- Contiene: 6 ripiani regolabili in altezza
- Mobile in kit
- Material structure in engineered wood
- Chrome-plated feet and handles
- Metal drawer runners
- Inside: 6 adjustable shelves
- Kit furniture
h.171cm
Sp. 10mm
l/w.29cm
Pos. Pezzi / Pcs
1 1
2 1
3 1
4 1
5 1
6 1
7 1
8 1
9 1
10 1
11 1
12 1
13 1
14 1
15 1
16 1
Ripiani
Shelves
Sp. 10mm
42,3cm
28,5cm
29,1cm
Descrizione / Description
Coperchio - Top (768 x 343 x 16mm)
Fianco dx - Rh Side (1710 x 318 x 16mm)
Fianco sx - Lh Side (1710 x 318 x 16mm)
Anta 1 - Door (558 x 453 x 16mm)
Anta 2 - Door (1025 x 453 x 16mm)
Anta 3 - Door (1717 x 306 x 16mm)
Tramezza Vert. - Vert. Partition Shelf (1710 x 317 x 16mm)
Tramezza Or. - Hor. Partition Shelf (425 x 317 x 16mm)
Tramezza Or. - Hor. Partition Shelf (292 x 75 x 16mm)
Base (766 x 317 x 16mm)
Schiena 1 - Backrest (441 x 689 x 3mm)
Schiena 2 - Backrest (441 x 1027 x 3mm)
Schiena 3 - Backrest (303 x 1725 x 3mm)
Davanti Cassetto - Front Drawer (453 x 129 x 16mm)
Sponda Cassetto - Shore Drawer (400 x 300 x 12mm)
Fondo Cassetto - Drawer Backrest (387 x 301 x 3mm)
28,5cm
