Summary of Contents for BPS CBE22
- Page 1 MT-CBE22-41022142-R00...
- Page 2 Code: MT-CBE22-41022142-R00 CBE22 Manuale tecnico – Technical manual Page 1/5 COMPONENTI FORNITI Quadro comando mod. CBE 22 (con OFF/Est/Inv + 3 velocità + Termostato elettronico) 2 viti (A+B) per fissaggio staffa comando sull’unità 1 Clip (C) per fissaggio sensore temperatura sull’unità...
- Page 3 Code: MT-CBE22-41022142-R00 CBE22 Manuale tecnico – Technical manual Page 2/5 Comando a bordo unità elettronico con OFF/Estate/Inverno + 3 Velocità + Electronic control panel with OFF/Summer/Winter + 3 Speed + Electronic Termostato ambiente elettronico + Sonda temperatura aria. room thermostat + Air temperature sensor.
- Page 4 “MVC” Controllato (on/off) dal termostato ambiente Est.: “MVC” Controlled (on/off) by room thermostat Inv.: “MVC” Controllato (on/off) dal termostato ambiente Inv.: “MVC” Controlled (on/off) by room thermostat CBE22;SND-A + TM STANDARD CBE22-A002-80029010-R00 Code AUTR L (Com) 230V – 1Ph – 50Hz...
- Page 5 “MVC” Sempre acceso (non controllato dal termostato) “MVC” Always on (not controlled by thermostat) Inv.: Inv.: “EV-CF-230V” Controllata (on/off) dal termostato ambiente “EV-CF-230V” Controlled (on/off) by room thermostat CBE22;SND-A + EV-CF-230V + TM SPECIAL CBE22-A005-80029010-R00 Code AUTR L (Com) 230V – 1Ph – 50Hz...
- Page 6 “MVC” Always on (not controlled by thermostat) Inv.: Inv.: “EV-C-230V” Controllata (on/off) dal termostato ambiente ; “EV-F-230V” Chiusa “EV-C-230V” Controlled (on/off) by room thermostat ; “EV-F-230V” Closed CBE22;SND-A + EV-F-230V + EV-C-230V + TM STANDARD CBE22-A007-80029010-R00 Code AUTR L (Com) 230V –...
