Page 1 NEXCOM International Co., Ltd. Network and Communication Solutions Network Security Appliance NSA 7150/7150A User Manual NEXCOM International Co., Ltd. www.nexcom.com Published August 2022...
Page 2: Table Of Contents
Power Connector to Power Board ..........15 Knowing Your NSA 7150 ................3 Header to LED ................16 Front Panel ..................3 Header to BTN Switch ..............16 Rear Panel ...................4 OCulink Connector ................17 Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 3 Installing a LAN Module ................38 Installing a CPU ..................40 Removing the Front Cover ..............40 Removing the Rear Cover ..............41 Removing the Middle Cover ..............42 Installing the CPU ................43 Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 4: Preface
No describes how to keep the system CE compliant. part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written consent from NEXCOM Declaration of Conformity International Co., Ltd.
Page 5: Rohs Compliance
0.1% or 1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm. In order to meet the RoHS compliant directives, NEXCOM has established an engineering and manufacturing task force in to implement the introduction of green products. The task force will ensure that we follow the standard...
Page 6: Warranty And Rma
“NEXCOM RMA Service Form” for the RMA number apply process. ▪ If RMA goods can not be repaired, NEXCOM will return it to the customer without any charge. ▪ Customers can send back the faulty products with or without accessories (manuals, cable, etc.) and any components from the card, such as CPU...
Page 7 ESD workstation. If no such station is available, you can provide some ESD protection by wearing an antistatic wrist strap and attaching it to a metal part of the computer chassis. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 8: Safety Information
There is a danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions. viii Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 9: Safety Precautions
RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS. 10. All cautions and warnings on the equipment should be noted. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 10: Technical Support And Assistance
Preface Technical Support and Assistance Conventions Used in this Manual 1. For the most updated information of NEXCOM products, visit NEXCOM’s Warning: website at www.nexcom.com. Information about certain situations, which if not observed, can cause personal injury. This will prevent injury to yourself 2.
Page 11: Global Service Contact Information
Tel: +886-2-8226-7786 Tel: +886-2-8976-3077 Beitun District, Fax: +886-2-8226-7782 Email: sales@diviotec.com Taichung City, 406, Taiwan, R.O.C. Email: services@tmrtek.com www.diviotec.com Tel: +886-4-2249-1179 www.tmrtek.com Fax: +886-4-2249-1172 Email: jacobhuang@nexaiot.com www.nexaiot.com Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 12 9F, Tamachi Hara Bldg., LongGang District, 4-11-5, Shiba Minato-ku, ShenZhen, 518112, China Tokyo, 108-0014, Japan Tel: +86-755-8364-7768 Tel: +81-3-5419-7830 Fax: +86-755-8364-7738 Fax: +81-3-5419-7832 Email: steveyang@nexcom.com.tw Email: sales@nexcom-jp.com www.nexcom.cn www.nexcom-jp.com Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 13: Package Contents
Preface Package Contents Before continuing, verify that the NSA 7150/7150A package that you received is complete. Your package should have all the items listed in the following table. Item Part Number Name 19S00715000X0 NSA 7150 50311F0110X00 Flat Head Screw 5044440031X00...
Page 14: Ordering Information
Preface Ordering Information The following information below provides ordering information for NSA 7150/7150A. Barebone NSA 7150 (P/N: 10S00715000X0) 2U, dual Intel ® 3rd Xeon ® Scalable Processor, w/o QAT, LCM, 8 x LAN modules and RunBMC NSA 7150A (P/N: 10S00715001X0)
Page 15 100G 3,4/7,8 NC 120FIS4-OS 2BS30012001X0 EZE810CAM2 PCIe x16 2 QSFP28 None None 100G 1,2/5,6 NL 110FM-OS 2BS60011000X0 MT28924A0-NCCF-VE PCIe x16 1 QSFP28/56 None None 200G 1,2/5,6 Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 17: Chapter 1: Product Introduction
▪ Support OCP NIC 3.0 ▪ 2 x Management ports ▪ Support IPMI 2.0 RunBMC ▪ 8 x PCIe 4 LAN modules ▪ 1300W 1+1 CRPS redundant power supply Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 18: Hardware Specifications
▪ 8 x LAN Module Slots + 1 x PCIe 4 x16 Low Profile Card ▪ UL ▪ 8 x OCP NIC 3.0 Slots + 1 x PCIe 4 x16 Low Profile Card (Optional) Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 19: Knowing Your Nsa 7150
Used to connect console devices with RJ45 type connection. indicators RJ45 type LAN Modules console port Reset Eight LAN module bays. button ports SFP type management LAN RJ45 type management LAN Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 20: Rear Panel
The round head screw included in the accessory pack (P/N: 50311F0162X00) can be installed here as the ground screw. Ensure that the ground screw is installed first before use. Power AC power switch sockets Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 21: Chapter 2: Jumpers And Connectors
Static electricity can damage many of the electronic ▪ Use correct screws and do not over tighten screws. components. Humid environments tend to have less static electricity than Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 22: Jumper Settings
(on) and open (off). Two-Pin Jumpers: Open (Left) and Short (Right) Three-Pin Jumpers: Pins 1 and 2 are Short Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 23: Locations Of The Jumpers And Connectors
JP24 R2197 JP26 JP20 C1703 JP25 CN8 CN10 C1723 TPM1 JP18 CN30 DIMM1 LED25 CN29 JP19 CN11 CN15 CN19 CN22 CN27 C37 C53 C517 C38 C54 Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 24: Jumper
2-4 On Force Bypass of CPU2 1-2 On: default 4-6 On Normal Operation Definition 3-5, 4-6 On: default RST_RTCRST_N Definition Definition FM_CPU1_SKTOCC_N FM_CPU2_SKTOCC_N FM_CPU1_SKTOCC_ FM_CPU2_SKTOCC_ LVT3_N LVT3_N Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 25: Bmc Remote Spd Debug Header
LT Key Downgrade Disable (Default) RST_SMB_SWITCH_N 6-8 On Flash Security Override Enable 6-8 Off Flash Security Override Disable (Default) 10-12 On Top Swap Enable 10-12 Off Top Swap Disable (Default) Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 26: Pch Strap Debug Use
JTAG Header to CPLD JTAG Pin FM_ME_RCVR_N DOWNGRADE_N 1-2 Off BMC to CPLD JTAG Pin (Default) FM_PASSWORD_ P3V3_AUX Definition CLEAR_N JTAG_SEL AUD_AZA_SDO FM_PCH_BMC_ P3V3_AUX THRMTRIP_EXI_STRAP_N FM_PCH_BIOS_RCVR_ SPKR Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 27: Cpld Jtag Select
Force PFR CPLD Update 3-4 Off Normal Operation (Default) 5-6 On PFR CPLD in Debug Mode 5-6 Off Normal Operation (Default) Definition Definition FM_PFR_FORCE_ RECOVERY_N FM_PFR_PROV_ UPDATE_N FM_PFR_DEBUG_ MODE_N Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 28: At/Atx Header & Cpld Jtag Prog Enable Header
Connector type: 2x3 6-pin header Connector location: JP18 Function 1-3 On ATX (Default) 3-5 On 2-4 On Enable PROG (Default) 4-6 On Disable PROG Definition Definition P3V3_CPLD P3V3_CPLD AT_ATX_SEL JTAG_PLD_JTAGEN Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 29: Internal Connectors
Connector location: CON1 Connector location: CN1 Definition Definition Definition Definition P12V_AUX P12V_AUX P12V_AUX P12V_AUX P12V P12V P12V_AUX P12V_AUX P12V_AUX P12V_AUX P12V_AUX P12V_AUX P12V_AUX P12V_AUX P12V P12V Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 30: Internal Power Connector (Cn2 To Cn12)
Connector type: 2x4 8-pin header Connector type: 2x4 8-pin header Connector location: CN2 and CN12 Connector location: CN3 Definition Definition Definition Definition P12V P12V P12V P12V P12V P12V P12V P12V Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 31: Internal Power Connector (Con1 To Cn21)
B1-9 P12V P12V A10-18 P12V B10-18 P12V P12V_AUX P12V_AUX SMB_PFR_PMB1_STBY_ LVC3_CRPS_SDA P12V P12V SMB_PFR_PMB1_STBY_ FM_PS_EN_PSU_N LVC3_CRPS_SCL P12V_STBY_PSU IRQ_SML1_PMBUS_ RETURN_SENSE BMC_ALERT_N PWRGD_PS_PWROK CRPS_PRESEND1 AC_FAIL_PSU 12V_REMOTE_SENSE P3V3_CPLD CRPS_PRESEND2 Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 32: Header To Led
Header to LED Header to BTN Switch Connector type: 1x2 2-pin header Connector type: 1x2 2-pin header Connector location: JP12 Connector location: JP13 Definition Definition P3V3_CPLD PWRBTN_N ID_LED_N Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 33: Oculink Connector
PE_SLOT_TX_C_DN1 PE_SLOT_RX_DP5 PE_SLOT_TX_C_DP5 PE_SLOT_RX_DN5 PE_SLOT_TX_C_DN5 SLOT_R2_SCL PE_SLOT_PWRBRK0# SLOT_R2_SDA IRQ_LVC3_WAKE_SLOT_N PE_SLOT_RST_N PE_SLOT_RX_DP2 PE_SLOT_TX_C_DP2 PE_SLOT_RX_DN2 PE_SLOT_TX_C_DN2 PE_SLOT_RX_DP6 PE_SLOT_TX_C_DP6 PE_SLOT_RX_DN6 PE_SLOT_TX_C_DN6 PE_SLOT_RX_DP3 PE_SLOT_TX_C_DP3 PE_SLOT_RX_DN3 PE_SLOT_TX_C_DN3 PE_SLOT_RX_DP7 PE_SLOT_TX_C_DP7 PE_SLOT_RX_DN7 PE_SLOT_TX_C_DN7 Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 34: Oculink Connector
PE_SLOT_RX_DN4 PE_SLOT_TX_C_DN4 PE_SLOT_RX_DP1 PE_SLOT_TX_C_DP1 PE_SLOT_RX_DN1 PE_SLOT_TX_C_DN1 PE_SLOT_RX_DP5 PE_SLOT_TX_C_DP5 PE_SLOT_RX_DN5 PE_SLOT_TX_C_DN5 PE_SLOT_RX_DP2 PE_SLOT_TX_C_DP2 PE_SLOT_RX_DN2 PE_SLOT_TX_C_DN2 PE_SLOT_RX_DP6 PE_SLOT_TX_C_DP6 PE_SLOT_RX_DN6 PE_SLOT_TX_C_DN6 PE_SLOT_RX_DP3 PE_SLOT_TX_C_DP3 PE_SLOT_RX_DN3 PE_SLOT_TX_C_DN3 PE_SLOT_RX_DP7 PE_SLOT_TX_C_DP7 PE_SLOT_RX_DN7 PE_SLOT_TX_C_DN7 Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 35: Fan Connector
Connector type: 1x6 6-pin header Connector type: 1x4 4-pin header Connector location: J4, J5 and J6 Connector location: CN23 and CN28 Definition Definition Definition Definition P12V P12V P12V TACH TACH Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 36: Power Team Debug Header
SYS RTC Header Connector type: 1x3 3-pin header Connector type: 1x2 2-pin header Connector location: JP14 (CPU1) and JP23 (CPU2) Connector location: J1 Definition Definition 3V3_BAT Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 37: Sata Power Connector
IPMB Debug Header Use Connector type: 1x4 4-pin header Connector type: 1x4 4-pin header Connector location: J2 Connector location: CN5 Definition Definition Definition Definition IPMB_DATA P12V IPMB_CLK P5V_AUX Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 38: Sata Connectors
Connector type: Standard Serial ATA 7P (1.27mm, SATA-M-180) Connector type: 1x4 4-pin header Connector location: CN8, CN9 and CN10 Connector location: JP26 Definition Definition Definition Definition 3.3V UART_RX UART_TX Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 39: Tpm Header
Connector type: 1x6 6-pin header Connector location: TPM1 Connector location: JP25 Definition Definition Definition Definition P3V3_AUX SPI_PCH_TPM_CS_R_N P3V3_CPLD IRQ_TPM_SPI_N JTAG_TCK_CPLD JTAG_TDO_CPLD RST_PLTRST_TPM_R_N JTAG_TDI_CPLD JTAG_TMS_CPLD SPI_TPM_CLK_R SPI_PCH_MUXED_R_IO1 SPI_PCH_MUXED_R_IO0 Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 40: Xdp Debug Connector (For Pch)
Connector location: CN7 Definition Definition Definition Definition TRC_2CH0_D6 TRC_2CH0_D7 TRC_2CH1_D0 TRC_2CH1_D1 TRC_2CH1_D2 P1V05_PCH_AUX TRC_2CH1_D3 DBP_VISA_RSMRST_N TRC_2CH0_CLK TRC_2CH1_D4 TRC_2CH1_D5 TRC_2CH1_D6 TRC_2CH0_D0 TRC_2CH1_D7 TRC_2CH0_D1 P3V3_AUX TRC_2CH0_D2 TRC_2CH0_D3 TRC_2CH0_D4 TRC_2CH0_D5 TRC_2CH1_CLK Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 41: Xdp Debug Connector (For Cpu1)
CPUPWRGD SMB_HOST_XDP_STBY_ MCI_CPU1_PTI14 JTAG_DBP_TRST_N H_DBP_PREQ_N_R LVC3_SCL H_DBP_PRDY_R_N PVCCIO_CPU1 SMB_HOST_XDP_STBY_ MCI_CPU1_PTI15 MCI_CPU1_PTI0_CLK LVC3_SDA DBP_SPI_PCH_IO2_ JTAG_DBP_PCH_TCK P3V3_AUX DEBUG_CONSENT_N DBP_CPU_OBSFN_B_ FM_DBP_PRESENT_R_N MBP3_GTL_N MCI_CPU1_PTI0 DBP_HOOK8_MBP2_ MCI_CPU1_PTI1 BOOT_HALT_N MCI_CPU1_PTI2 MCI_CPU1_PTI3 MCI_CPU1_PTI1_CLK Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 42: Xdp Debug Connector (For Cpu2)
Definition Definition Definition Definition MCI_CPU2_PTI6 MCI_CPU2_PTI7 MCI_CPU2_PTI8 MCI_CPU2_PTI9 MCI_CPU2_PTI10 PWRGD_CPU2_LVC3_ PVCCIO_CPU2 MCI_CPU2_PTI11 MIPI60 MCI_CPU2_PTI0_CLK MCI_CPU2_PTI12 MCI_CPU2_PTI13 MCI_CPU2_PTI14 MCI_CPU2_PTI0 MCI_CPU2_PTI15 MCI_CPU2_PTI1 P3V3_AUX MCI_CPU2_PTI2 MCI_CPU2_PTI3 MCI_CPU2_PTI4 MCI_CPU2_PTI5 MCI_CPU2_PTI1_CLK Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 43: Gpio Header
Connector location: J3 Definition Definition Definition Definition P3V3_CPLD VGA_VCC CPLD_GPI01 CPLD_GPO01 SMB_BMC_DDC_SCL_R1 CPLD_GPI02 CPLD_GPO02 SMB_BMC_DDC_SDA_R1 CPLD_GPI03 CPLD_GPO03 V_BMC_GFX_REAR_ VSYN_R3 V_BMC_GFX_REAR_ HSYN_R3 V_BMC_GFX_REAR_ BLU_R1 V_BMC_GFX_REAR_ GRN_R1 V_BMC_GFX_REAR_ RED_R1 Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 44: Riser Left Connector
P3V3 P3V3 P3V3 P3V3 P3V3 P3V3 P3V3 P3V3 P3V3 P3V3 P3V3 P3V3 P3V3 P3V3 P3V3_AUX P3V3_AUX P3V3_AUX P3V3_AUX PE_SLOT3_CLK_DP PE_SLOT7_CLK_DP PE_SLOT3_CLK_DN PE_SLOT7_CLK_DN PE_SLOT4_CLK_DP PE_SLOT8_CLK_DP PE_SLOT4_CLK_DN PE_SLOT8_CLK_DN Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 45: Riser Right Connector
SLOT7_R2_SCL PE_SLOT8_TX_C_DN5 SLOT7_R2_SDA PE_SLOT8_TX_C_DP5 PE_SLOT8_RX_DN5 P3V3 PE_SLOT8_RX_DP5 P3V3 PE_SLOT8_TX_C_DN4 P3V3 P3V3_AUX PE_SLOT8_TX_C_DP4 PE_SLOT78_RST_N IRQ_LVC3_WAKE_SLOT78_N PE_SLOT8_RX_DN4 PE_SLOT8_RX_DP4 PE_EXPANSION_CLK_DP PE_EXPANSION_CLK_DN PE_SLOT8_TX_C_DN7 PE_SLOT8_TX_C_DP7 PE_SLOT8_TX_C_DN3 PE_SLOT8_RX_DN7 PE_SLOT8_TX_C_DP3 PE_SLOT8_RX_DP7 PE_SLOT8_RX_DN3 PE_SLOT8_RX_DP3 Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 46 PE_SLOT8_TX_C_DP0 PE_SLOT7_RX_DP3 PE_SLOT8_RX_DN0 PE_SLOT7_TX_C_DN2 PE_SLOT8_RX_DP0 PE_SLOT7_TX_C_DP2 PE_SLOT7_RX_DN2 PE_SLOT7_TX_C_DN7 PE_SLOT7_RX_DP2 PE_SLOT7_TX_C_DP7 PE_SLOT7_TX_C_DN1 PE_SLOT7_RX_DN7 PE_SLOT7_TX_C_DP1 PE_SLOT7_RX_DP7 PE_SLOT7_RX_DN1 PE_SLOT7_TX_C_DN6 PE_SLOT7_RX_DP1 PE_SLOT7_TX_C_DP6 PE_SLOT7_TX_C_DN0 PE_SLOT7_RX_DN6 PE_SLOT7_TX_C_DP0 PE_SLOT7_RX_DP6 PE_SLOT7_RX_DN0 PE_SLOT7_TX_C_DN5 PE_SLOT7_RX_DP0 PE_SLOT7_TX_C_DP5 Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 47: Io Slot Connector
USB2_P01_IO_DN USB2_P02_IO_DN NCSI_TXD0_A NCSI_RXD0_A USB2_P01_IO_DP USB2_P02_IO_DP NCSI_TXD1_A NCSI_RXD1_A FM_OC1_USB_N NCSI_CLK_I210_R1_A NCSI_CRS_DV_A CLK_100M_I210_LANB_DP CLK_100M_I210_LANA_DP CLK_100M_I210_LANB_DN CLK_100M_I210_LANA_DN NCSI_TX_EN_A PCIE_RX_LANB_DP PCIE_TX_LANB_DP BMC_COM_SW_N CPLD_UART_DCD_N PCIE_RX_LANB_DN PCIE_TX_LANB_DN IBMC_SIO_LCM_TXD CPLD_UART_CTS_N IBMC_SIO_LCM_RXD CPLD_UART_DSR_N Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 48 BMC_R_TXD5 CPLD_UART_R_RXD BMC_R_RXD5 P3V3 P3V3 P3V3 P3V3 P3V3 P3V3 P3V3_AUX P3V3_AUX P3V3_AUX P3V3_AUX P3V3_AUX P3V3_AUX P5V_AUX P5V_AUX P5V_AUX P5V_AUX P5V_AUX P5V_AUX LED_PCH_HDD LED_PWR_STBY_ON IO_ALERT_LED# NMI_BTN_N_L POWER_ERROR_LED Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 49: Ocp Slot Connector
PE_SLOT_CLK1_DP PE_SLOT_CLK0_DP OA12 PE_SLOT_CLK3_DP OB12 PE_SLOT_CLK2_DP OA13 OB13 PE_SLOT_RX_DN0 PE_SLOT_TX_C_DN0 OA14 NO USE OB14 NO USE PE_SLOT_RX_DP0 PE_SLOT_TX_C_DP0 P12V P12V PE_SLOT_RX_DN1 PE_SLOT_TX_C_DN1 P12V PE_SLOT_RX_DP1 PE_SLOT_TX_C_DP1 P12V Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 50 PE_SLOT_RX_DP6 PE_SLOT_TX_C_DP6 PE_SLOT_RX_DN14 PE_SLOT_TX_C_DN14 PE_SLOT_RX_DN7 PE_SLOT_TX_C_DN7 PE_SLOT_RX_DP14 PE_SLOT_TX_C_DP14 PE_SLOT_RX_DP7 PE_SLOT_TX_C_DP7 PE_SLOT_RX_DN15 PE_SLOT_TX_C_DN15 NO USE NO USE PE_SLOT_RX_DP15 PE_SLOT_TX_C_DP15 PE_SLOT_RX_DN8 PE_SLOT_TX_C_DN8 PE_SLOT_RX_DP8 PE_SLOT_TX_C_DP8 NO USE NO USE Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 51: Connector (M Key)
PCIE_TX_M2_R_3_DN P3V3 PCIE_TX_M2_R_0_DN PCIE_TX_M2_R_3_DP P3V3 PCIE_TX_M2_R_0_DP PE_RST_M2_N P3V3 FM_CLKREQ_M2_1_N PCIE_RX_M2_R_2_DN P3V3 CLK_100M_M2_DN IRQ_LVC3_WAKE_N PCIE_RX_M2_R_2_DP CLK_100M_M2_DP NGFF_CONFIG_0 PCIE_TX_M2_R_2_DN PCIE_TX_M2_R_2_DP PCH_SUSCLK_33K_R_SSD FM_M2_1_PEDET P3V3 PCIE_RX_M2_R_1_DN P3V3 PCIE_RX_M2_R_1_DP P3V3 NGFF_CONFIG_2 Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 52: Block Diagram
SLOT1 _OCP SLOT2 _OCP PCI-E X16 SLOT PCIe Gen4 X16 PCIe Gen4 X16 PCIe Gen4 X16 PCIe Gen4 X16 IO BOARD NSK1160 UART5 I210 I211 CONSOLE USB3X2 Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 53: Chapter 3: System Setup
Remove these screws and put them in a safe place for later use. 2. With the screws removed, gently slide the cover outwards and then lift up the cover to remove it. Lift here Screws on the sides Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 54: Installing A Lan Module
CAUTION! CAUTION! CAUTION! before replacing or adding LAN modules to prevent electric shock or system damage. 1. Loosen the two screws on the LAN module. Handle Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 55 Before using Optical fiber for transferring data, make sure you have connected an approved Optical Transceiver Module. User needs to install appropriate and UL approved Laser Class I Transceivers, rated 3.3Vdc, max. 1W. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 56: Installing A Cpu
Before installing or removing internal components on CAUTION! CAUTION! CAUTION! the mainboard, please ensure that the AC power cord is unplugged for at least over 10 seconds. Front Cover Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 57: Removing The Rear Cover
Chapter 3: System Setup Removing the Rear Cover 2. Remove the front cover. 1. Locate the rear cover and remove the screws securing it as shown below. Rear Cover Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 58: Removing The Middle Cover
2. Remove the rear cover. 1. Locate and remove the screws on the four corners of the middle cover. Middle Cover Upper Upper Left Right Lower Lower Left Right Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 59: Installing The Cpu
Chapter 3: System Setup Installing the CPU 2. Remove the middle cover to access the CPU sockets. 1. Remove the protective cap on the CPU socket. Protective Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 60 3. With the CPU placed into the processor carrier, install the CPU onto the CPU aligned to the triangular mark (pin 1 indicator) on the processor CPU socket. carrier. Triangular Mark Processor Carrier Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 61 4, 3, 2 and 1. Please ensure that the T30 screws are tightened with a CAUTION! CAUTION! CAUTION! torque of 6-12 IN-LB. Otherwise, the motherboard may be damaged. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 62: Installing Memory Modules
AC power cord is unplugged for at least over 10 seconds. Note: For information on the memory population rule, please refer to pages 48 and 49. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 64: Ddr4 Memory Population Table
DDR4 memory population table for the 3rd Gen Intel® Xeon® Scalable Processor is shown below. If you use only one please refer to the table of corresponding color (yellow for CPU0 and orange for CPU1) Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 65: Ddr4 And Intel ® Optane™ Persistent Memory Population Table
DDR4+BSP memory population table for the 3rd Gen Intel® Xeon® Scalable Processor is shown below. If you use only one please refer to the table of corresponding color (yellow for CPU0 and orange for CPU1) Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 66: Assembling The 2.5" Removable Drive Bay
Assembling the 2.5” Removable Drive Bay The 2.5” removable drive bay kit contains the parts pictured below: 1. Locate the installation location for the drive bay kit. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 67 Chapter 3: System Setup 2. Install the two copper standoffs to the location circled below. 3. Align the mounting holes on the base plate to the copper standoffs. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 68 4. Secure the base plate to the standoffs with screws. 5. Align the mounting holes on the drive bay enclosure to the mounting holes on the drive bay bracket. Drive Bay Bracket Drive Bay Enclosure Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 69 8. Fix the drive bay bracket to the base plate with screws. 7. Repeat step 6 for securing the screws on the other side of the bracket. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 70 9. Connect the SATA data and power cables to the respective connectors on the board and the other ends of the cables to the connectors on the drive bay enclosure. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 71: Assembling The 3.5" Removable Drive Bay
Assembling the 3.5” Removable Drive Bay The 3.5” removable drive bay kit contains the parts pictured below: 1. Locate the installation location for the drive bay kit. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 72 Chapter 3: System Setup 2. Install the two copper standoffs to the location circled below. 3. Align the mounting holes on the base plate to the copper standoffs. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 73 4. Secure the base plate to the standoffs with screws. 5. Push the eject button on the HDD drive tray to release the latch. Eject button Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 75 9. Slide the tray back into the drive bay enclosure, and push firmly until you 10. Fix the drive bay enclosure to the base plate with screws. hear a distinctive click sound. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 76 11. Connect the SATA data and power cables to the respective connectors on the board and the other ends of the cables to the connectors on the drive bay enclosure. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 77: Chapter 4: Bios Setup
This chapter describes how to use the BIOS setup program for NSA 7150/7150A. The settings made in the setup program affect how the computer performs. The BIOS screens provided in this chapter are for reference only and may change It is important, therefore, first to try to understand all the setup options, and if the BIOS is updated in the future.
Page 78: Default Configuration
Powering on the computer and immediately pressing allows you to enter Setup. Load optimized default values. Saves and exits the Setup program. Press <Enter> to enter the highlighted sub-menu Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 79 When “” appears on the left of a particular field, it indicates that a submenu which contains additional options are available for that field. To display the submenu, move the highlight to that field and press Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 80: Bios Setup Utility
F3: Optimized Defaults Total Memory 32768 MB F4: Save & Exit ESC: Exit System Date [Tue 01/05/2021] System Time [18:17:12] Version 2.21.1279. Copyright (C) 2021 American Megatrends, Inc. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 81: Advanced
Security Device. TCG EFI protocol and INT1A interface will not be available. F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.21.1279. Copyright (C) 2021 American Megatrends, Inc. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 82 Change Settings Configuration settings for serial port 1. Selects an optimal setting for the Super IO device. Serial Port 2 Configuration Configuration settings for serial port 2. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 83 Enables or disables the serial port. Change Settings Selects an optimal setting for the Super IO device. Device Mode Configures the operating mode of the serial port. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 84 Socket0 PECI0 to VIN5 (PVCCIN_CPU1) Fan1 Speed to VBAT Detects and displays the temperatures, fan speeds and output voltages. Detects and displays the fan speeds and output voltages. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 85 Bits Per Second Selects the serial port transmission speed. The speed must match the other side. Long or noisy lines may require a lower speed. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 86 Selects the Putty keyboard emulation type. BME DMA Mitigation Enables or disables the function to re-enable bus master attribute during PCI enumeration for PCI bridges after SMM is locked. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 87 This is a workaround for OSs that does not support XHCI hand-off. The USB transfer time-out XHCI ownership change should be claimed by the XHCI driver. The time-out value for control, bulk, and Interrupt transfers. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 88 F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.21.1279. Copyright (C) 2021 American Megatrends, Inc. Network Stack Enables or disables UEFI network stack. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 89 Configures which devices the system will boot from. Network Controls the execution of UEFI and Legacy PXE OpROM. Storage Controls the execution of UEFI and Legacy Storage OpROM. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 90 F4: Save & Exit F4: Save & Exit ESC: Exit ESC: Exit Version 2.21.1279. Copyright (C) 2021 American Megatrends, Inc. Version 2.21.1279. Copyright (C) 2021 American Megatrends, Inc. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 91: Platform Configuration
Enters the PCI Express Configuration submenu. Enters the Server ME Configuration submenu. PCH SATA/sSATA Configuration Enters the PCH SATA/sSATA Configuration submenu. USB Configuration Enters the USB Configuration submenu. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 92 Enables or disables CPU VR Config. Pcie Pll SSC Enables or disables PCIe Phase Locked Loop for spread spectrum clock. Shutdown Policy Configures the shutdown policy. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 93 This option configures the Serial ATA drives to use AHCI (Advanced Host Controller Interface). AHCI allows the storage driver to enable the advanced Serial ATA features which will increase storage performance. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 94 This option configures the Serial ATA drives to use AHCI (Advanced Host Controller Interface). AHCI allows the storage driver to enable the advanced Serial ATA features which will increase storage performance. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 95 Displays information of the firmware installed in the system. Enables or disables XHCI manual mode. USB Per-Connector Disable Provides the option to enable or disable each USB connector. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 96: Socket Configuration
UPI Configuration and Memory Configuration Enters the UPI Configuration and Memory Configuration submenu. IIO Configuration and Advanced Power Management Configuration Enters the IIO Configuration and Advanced Power Management Configuration submenu. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 97 Enables or disables extended APIC support. L2 RFO Prefetch Disable Enable Intel® TXT Enables or disables L2 RFO prefetch. Enables or disables Intel TXT support. Enables or disables Virtual Machine Extensions. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 98 Provides the option to enable or disable all cores. 0 means enable all cores. FFFFFFF means disable all cores. CPU Socket 1 Configuration Processor settings for the CPU on socket 1. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 99 Configures the MMCFG size. MMIO High Base Configures the base memory size of MMIO high base. MMIO High Granularity Size Configures the high memory size of MMIO high base. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 100 Enables or disables SRAT (Static Resource Affinity Table). SRAT Memory Hot Plug Enables or disables SRAT Memory Hot-Plugging. SRAT CPU Hot Plug Enables or disables SRAT CPU Hot-Plugging. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 101 Enters the Uncore General Configuration submenu. Configures the link speed mode. Uncore Per Socket Configuration Link Frequency Select Enters the Uncore Per Socket Configuration submenu. Configures the uncore frequency. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 102 Enters the CPU 0 submenu. CPU 1 Enters the CPU 1 submenu. CPU 2 Enters the CPU 1 submenu. CPU 3 Enters the CPU 1 submenu. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 103 CPU 0 UPI Port 2 CPU 1 UPI Port 2 Enters the CPU 0 UPI Port 2 configuration submenu. Enters the CPU 1 UPI Port 2 configuration submenu. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 104 CPU 2 UPI Port 2 CPU 3 UPI Port 2 Enters the CPU 2 UPI Port 2 configuration submenu. Enters the CPU 3 UPI Port 2 configuration submenu. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 105 Enables or disables the UPI link. Current UPI Link Speed Current UPI Link Speed Configures the current UPI link speed. Configures the current UPI link speed. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 106 Enables or disables the UPI link. Current UPI Link Speed Current UPI Link Speed Configures the current UPI link speed. Configures the current UPI link speed. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 107 Enables or disables the UPI link. Current UPI Link Speed Current UPI Link Speed Configures the current UPI link speed. Configures the current UPI link speed. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 108 Enables or disables the UPI link. Current UPI Link Speed Current UPI Link Speed Configures the current UPI link speed. Configures the current UPI link speed. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 109 Enables or disables the UPI link. Current UPI Link Speed Current UPI Link Speed Configures the current UPI link speed. Configures the current UPI link speed. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 110 Enables or disables the UPI link. Current UPI Link Speed Current UPI Link Speed Configures the current UPI link speed. Configures the current UPI link speed. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 111 Configures the options for Enforce Plan of Record. When enabled, Plan of Record restrictions for DDR4 frequency and voltage programming is enforced. Enforce Population POR Enables or disables Enforce Population POR. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 112 BIOS will try to configure 2LM but if BIOS is unable to configure 2LM, volatile memory mode will fall. AppDirect cache Enables or disables AppDirect cache. eADR Support Enables or disables eADR support. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 113 Enables or disables correctable error interruption. Sck0 RP NonFatal Uncorrectable Err Enables or disables non-fatal error interruption. Sck0 RP Fatal Uncorrectable Err Enable or disables fatal error interruption. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 114 PCI-E Port Clock Gating Enables or disables PCIe clock gating for each root port. Data Link Feature Exchange Enables or disables Data Link Feature Exchange in PCIe 4.0. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 115 This option enables or disables ASPM support for all downstream devices. Enables or disables Alternate TxEq. PCI-E Extended Sync SRIS Enables or disables the PCI-E Extended Sync mode. Enables or disables SRIS. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 116 Override Max Link Width Configures the link speed to override the max link width set by bifurcation. PCI-E Port DeEmphasis Configures the de-emphasis control for the PCIe port. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 117 PCI-E Port MPSS Enables or disables MCTP. Configures the option for max payload size supported for PCI-E port. P2P Memory Read Enables or disables P2P Memory Read. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 118 PCI-E Port DeEmphasis PCI-E Port D-state Configures the de-emphasis control for the PCIe port. Configures the PCIe port to normal power state or low power state. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 119 Enables or disables P2P Memory Read. Enables or disables the option to hide the root port. PME to ACK MCTP Enables or disables PME to ACK messages. Enables or disables MCTP Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 120 PCI-E Port DeEmphasis PCI-E Port D-state Configures the de-emphasis control for the PCIe port. Configures the PCIe port to normal power state or low power state. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 121 Enables or disables the option to hide the root port. P2P Memory Read MCTP Enables or disables P2P Memory Read. Enables or disables MCTP PME to ACK Enables or disables PME to ACK messages. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 122 PCI-E Port DeEmphasis PCI-E Port D-state Configures the de-emphasis control for the PCIe port. Configures the PCIe port to normal power state or low power state. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 123 Enables or disables P2P Memory Read. Enables or disables the option to hide the root port. PME to ACK MCTP Enables or disables PME to ACK messages. Enables or disables MCTP Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 124 PCI-E Port DeEmphasis PCI-E Port D-state Configures the de-emphasis control for the PCIe port. Configures the PCIe port to normal power state or low power state. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 125 Enables or disables the option to hide the root port. P2P Memory Read MCTP Enables or disables P2P Memory Read. Enables or disables MCTP PME to ACK Enables or disables PME to ACK messages. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 126 PCI-E Port DeEmphasis PCI-E Port D-state Configures the de-emphasis control for the PCIe port. Configures the PCIe port to normal power state or low power state. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 127 Enables or disables P2P Memory Read. Enables or disables the option to hide the root port. PME to ACK MCTP Enables or disables PME to ACK messages. Enables or disables MCTP Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 128 PCI-E Port DeEmphasis PCI-E Port D-state Configures the de-emphasis control for the PCIe port. Configures the PCIe port to normal power state or low power state. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 129 Enables or disables the option to hide the root port. P2P Memory Read MCTP Enables or disables P2P Memory Read. Enables or disables MCTP PME to ACK Enables or disables PME to ACK messages. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 130 Configures the PCI-E completion timeout value. Sck1 RP Correctable Err Enables or disables correctable error interruption. Sck1 RP NonFatal Uncorrectable Err Enables or disables non-fatal error interruption. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 131 Configures the link speed to override the max link width set by bifurcation. Configures the value of the Tx/Rx EQ for slot 8. PCI-E Port DeEmphasis Configures the de-emphasis control for the PCIe port. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 132 PCI-E Port MPSS Enables or disables MCTP Configures the option for max payload size supported for PCI-E port. P2P Memory Read Enables or disables P2P Memory Read. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 133 PCI-E Port DeEmphasis PCI-E Port D-state Configures the de-emphasis control for the PCIe port. Configures the PCIe port to normal power state or low power state. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 134 Enables or disables the option to hide the root port. P2P Memory Read MCTP Enables or disables P2P Memory Read. Enables or disables MCTP PME to ACK Enables or disables PME to ACK messages. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 135 PCI-E Port DeEmphasis PCI-E Port D-state Configures the de-emphasis control for the PCIe port. Configures the PCIe port to normal power state or low power state. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 136 Enables or disables P2P Memory Read. Enables or disables the option to hide the root port. PME to ACK MCTP Enables or disables PME to ACK messages. Enables or disables MCTP Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 137 PCI-E Port DeEmphasis PCI-E Port D-state Configures the de-emphasis control for the PCIe port. Configures the PCIe port to normal power state or low power state. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 138 Enables or disables the option to hide the root port. P2P Memory Read MCTP Enables or disables P2P Memory Read. Enables or disables MCTP PME to ACK Enables or disables PME to ACK messages. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 139 PCI-E Port DeEmphasis PCI-E Port D-state Configures the de-emphasis control for the PCIe port. Configures the PCIe port to normal power state or low power state. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 140 Enables or disables P2P Memory Read. Enables or disables the option to hide the root port. PME to ACK MCTP Enables or disables PME to ACK messages. Enables or disables MCTP Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 141 PCI-E Port DeEmphasis PCI-E Port D-state Configures the de-emphasis control for the PCIe port. Configures the PCIe port to normal power state or low power state. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 142 Enables or disables the option to hide the root port. P2P Memory Read MCTP Enables or disables P2P Memory Read. Enables or disables MCTP PME to ACK Enables or disables PME to ACK messages. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 143 PCI-E Port DeEmphasis PCI-E Port D-state Configures the de-emphasis control for the PCIe port. Configures the PCIe port to normal power state or low power state. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 144 Enables or disables P2P Memory Read. Enables or disables the option to hide the root port. PME to ACK MCTP Enables or disables PME to ACK messages. Enables or disables MCTP Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 145 I/O device assignment to VMM through DMAR ACPI tables. DMA Control Opt-In Flag Enables or disables DMA Control Opt-In Flag. Interrupt Remapping Enables or disables Interrupt Remapping. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 146 Enters the CPU C State Control submenu. Enables or disables Intel AVX License Pre-Grant Override. ® SpeedStep (Pstates) Enables or disables Intel SpeedStep technology. ® Dynamic SST-PP Enables or disables Dynamic SST-PP. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 147 Perf P-Limit Clip Configures the performance P-Limit Clip value. Perf P-Limit Threshold Configures the performance P-Limit Threshold value. Perf P Limit Enables or disables performance P Limit. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 148 Enables or disables CPU C1 auto demotion. CPU C1 auto undemotion Enables or disables CPU C1 auto undemotion. CPU C6 report Enables or disables C6 report to the operating system. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 149: Server Mgmt
Configures the options for power control policy. When SEL is Full Configures the action to perform when SEL is full. Log EFI Status Codes Configures the options for logging EFI status codes. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 150 BMC). Unspecified option will not modify any BMC network parameters during BIOS phase. When log is full Configures the action to perform when log is full. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 151: Security
NumLock on wherein the function of the numeric keypad is the number keys. When set to Off, the function of the numeric keypad is the arrow keys. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...
Page 152: Save & Exit
Confirm by selecting Yes. Launch EFI Shell from Filesystem Device To launch EFI shell from a filesystem device, select this field and press <Enter>. Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved. NSA 7150/7150A User Manual...

This manual is also suitable for:

Nsa 7150a

Nexcom NSA 7150 User Manual

Chapter 1: Product Introduction

Chapter 2: Jumpers and Connectors

Chapter 3: System Setup

Chapter 4: BIOS Setup

Quick Links

Need help?

Questions and answers

Related Manuals for Nexcom NSA 7150

Summary of Contents for Nexcom NSA 7150

This manual is also suitable for:

Table of Contents
