  • Page 1 INSTALLATION, OPERATION & MAINTENANCE MANUAL GLOBE VALVES OS & Y FORGED ISO 15761/API 602/ B16.34 www.australianpipelinevalve.com.au...
  • Page 2 Valves - Cast Steel Valves - Forged Steel Sleeved & Lined Valves & Wellheads APV valves and pipeline products form the most APV FAMILY OF BRANDS RANGE - CATALOGUES competitive portfolio in the market.” Diamond Gear Flowturn Ball Valves Flowturn Gate, Globe...
  • Page 3 GLOBE VALVES OS & Y - FORGED - ISO 15761/API 602/B16.34 I N D E X Introduction Safety Information Valve Identification 1.0 Installation 7-11 Installation positions Preparation for installation End connections 8-11 Post-installation procedures 2.0 Operation 3.0 Maintenance 12-17 Gland packing adjustment 12-13 Backseating 13-14...
  • Page 4 GLOBE VALVES OS & Y - FORGED - ISO 15761/API 602/B16.34 Disassembly of yoke nut Disc and seats 22-23 Disc & seat repair 23-24 Valve reassembly & test 24-25 Appendix A - Body/bonnet bolting torque 27-28 Appendix B - Figure number system Appendix C - Exploded B.O.M.

  • Page 5: Responsibility For Valve Application

    RESPONSIBILITY FOR VALVE APPLICATION The User is responsible for ordering the correct valves. The user is responsible for ensuring APV Valves are selected and installed in conformance with the current pressure rating and design temperature requirements.

  • Page 6: Safety Information

    This manual provides instructions for storing, general servicing, installation and removal of globe valves. APV and it’s resellers refuse any liability for damage to people, property or plant as well as loss of production and loss of income under any circumstances but especially if caused by: Incorrect installation or utilisation of the valve or if the valve installed is not fit for intended purpose.
  • Page 7 If a gasket seal is disturbed while removing or adjusting gasketed parts, APV recommends installing a new gasket while reassembling. A proper seal is required to ensure optimum operation.
  • Page 8 V A L V E I D E N T I F I C A T I O N Each APV valve is identified with a nameplate, which is placed over the handwheel and secured with the hand wheel nut on gate and globe valves, and riveted to the cover on check valves. Below is an example.

  • Page 9: Installation Positions

    GLOBE VALVES OS & Y - FORGED - ISO 15761/API 602/B16.34 1 . 0 I N S T A L L A T I O N Piping should be properly aligned and supported to reduce mechanical loading on the end connections. 1.1 INSTALLATION POSITIONS Globe valves are unidirectional and have the direction of flow indicated on the valve body.

  • Page 10: Preparation For Installation

    GLOBE VALVES OS & Y - FORGED - ISO 15761/API 602/B16.34 1.2 PREPARATION FOR INSTALLATION • Remove protective end caps or plugs and inspect valve ends for damage to threads, socket weld bores or flange faces. • Thoroughly clean adjacent piping system to remove any foreign material that could cause damage to seating surfaces during valve operation.
  • Page 11 PWHT depending on material specifications. APV forged globe valves do not run the risk of seat loosening during welding due to the fact that they are supplied with integral Stellite body seats.
  • Page 12 GLOBE VALVES OS & Y - FORGED - ISO 15761/API 602/B16.34 Special trim options and body materials such as valves with PTFE packing/soft seat/ special seals/ and gaskets that have maximum temperature limits less than the valve, may require special welding and heat treatment considerations which are not included herein.

  • Page 13: Post-Installation Procedures

    GLOBE VALVES OS & Y - FORGED - ISO 15761/API 602/B16.34 APV does not make any recommendations in regards to the actual PWHT details of temperature and time. This work is not within the scope of APV. APV recommends that all applicable “Piping Code” requirements be considered.

  • Page 14: Maintenance

    GLOBE VALVES OS & Y - FORGED - ISO 15761/API 602/B16.34 3 . 0 M A I N T E N A N C E Proper safety equipment and apparel should be worn when preparing to service a valve. Observe the following general warnings: •...
  • Page 15 GLOBE VALVES OS & Y - FORGED - ISO 15761/API 602/B16.34 Over tightening will cause the packing to fail prematurely as well as increasing the force required to operate the valve. The packing gland flange should not bend even slightly, if it does you have over-tightened the valve and have to replace the flange. If the leak cannot be stopped by tightening the gland nuts, it is necessary to add additional packing rings or completely repack the valve.

  • Page 16: Packing Replacement

    GLOBE VALVES OS & Y - FORGED - ISO 15761/API 602/B16.34 Under no circumstances should the back seat be used to allow gland packing replacement or repair while the valve and system are pressurised. One of the most common misunderstandings is to believe that is the Globe valve is back seated (fully open position - and backseat sealing made), this will help to prevent wear of the packing rings.
  • Page 17 3.4 PREVENTATIVE MAINTENANCE AND PERIODIC INSPECTIONS APV recommends that periodic inspections be carried out on all valves. The frequency of these inspections depends on the severity of the service and the frequency of the valve operation. As a minimum, all valves should be inspected quarterly to ensure proper operation and discourage the damage compounding effects of leakage.
  • Page 18 Regular maintenance of the valve is required to assure smooth operation. Stem threads should be inspected and lubricated frequently to ensure ease of operation. APV valves are supplied with the stem threads engaging the yoke nut pre-greased. These components should be kept constantly lubricated by applying the grease directly on the stem when the valve is in the open position or through the grease injector in the yoke nut when provided.
  • Page 19 GLOBE VALVES OS & Y - FORGED - ISO 15761/API 602/B16.34 FIGURE 5 Lubrication Points Globe Valve - Top Works Globe Valve - Top Works (no grease fitting) (single grease fitting) 4 . 0 EXTRAORDINARY REPAIRS & MAINTENANCE Due to the relatively low replacement cost of small diameter standard carbon steel valves under, it is usually less expensive to replace the complete valve than to have maintenance personnel effect repairs.
  • Page 20 Remove old packing as per Section 4.2.1 below. e) APV fugitive emission graphite and PTFE packing has solid seal ring that must be cut for removal. Any remains of existing packing must be removed from the stuffing box and stem.
  • Page 21 120° STAGGER OF JOINTS* 45° END CUT* TYPICAL GLOBE VALVE (BOLTED BONNET DESIGN) STEM PACKING* *Example only, refer to as-built drawing. Die formed/moulded genuine APV packing set is required for fugitive emission service. Australian Pipeline Valve - Installation, Operation and Maintenance Manual...
  • Page 22 GLOBE VALVES OS & Y - FORGED - ISO 15761/API 602/B16.34 The stem packing style will vary according to valve size, type and class as well as the stem packing material specified. Examples include combination sets, wire reinforced braided packing, PTFE Chevron moulded sets, live loaded sets. Note 4.3 BONNET DISASSEMBLY &...
  • Page 23 See sample drawing Appendix C. Please refer to as-built drawing as APV has various styles of pressure seal designs. The procedure to remove a pressure seal bonnet is as follows: 1.
  • Page 24 GLOBE VALVES OS & Y - FORGED - ISO 15761/API 602/B16.34 Only an experienced valve repair professional should attempt repairs to pressure seal bonnet valves. There are different designs of pressure seal bonnet: - locknut type (breech lock), bonnet take-up type (bolted yoke arm) and the bolted style, hence, refer to as-built drawings.
  • Page 25 These valves are available with either threaded-in seat rings or an integral seat, both of which may be repaired (threaded in seats shall be replaced) while the valve is in line. Globe valves require a guide fixture (refer to APV approved repairer) to maintain alignment during the Australian Pipeline Valve - Installation, Operation and Maintenance Manual...
  • Page 26 GLOBE VALVES OS & Y - FORGED - ISO 15761/API 602/B16.34 lapping operation. The globe stem/disc assembly may be used in the lapping operation. However, due to its loose design, it is necessary to prevent the disc from rotating on the stem. After lapping it is recommended that the surface of the seat and disc be checked for proper contact using marking blue.
  • Page 27 For the valve disc seating surface damage exceeding 0.12mm (0.005”), up to a maximum of 1mm (0.040”) can be removed in a lathe by an APV approved valve repairer (for disc with angle 27°). Australian Pipeline Valve - Installation, Operation and Maintenance Manual...
  • Page 28 GLOBE VALVES OS & Y - FORGED - ISO 15761/API 602/B16.34 Typical Forged Bolted Bonnet Globe Valve Expanded View 1. Disc FIGURE 9 Plug type disc is machined to the tightest tolerances to ensure trouble free shut off and cycling. 2.
  • Page 29 (9) Most B8M and B8 bolts are class 1 so do not assume class 2 unless you are sure. For ‘pressure seal’ bonnet consult APV for torques (where bolting is applicable). Bolt tensions shown must be decreased by 25% when other or no lubrication used. Non lubricated bolts can have an efficiency of less than 50% the torque of values stated.
  • Page 30 GLOBE VALVES OS & Y - FORGED - ISO 15761/API 602/B16.34 A P P E N D I X A - C O N T D . FIGURE 10 BOLT TIGHTENING SEQUENCE EXAMPLES Example only, refer to as-built drawing. Australian Pipeline Valve - Installation, Operation and Maintenance Manual...
  • Page 31 GLOBE VALVES OS & Y - FORGED - ISO 15761/API 602/B16.34 A P P E N D I X B Figure Number System D - CLASS G - NACE ASME 150LBS Blank = NON NACE ASME 300LBS = NACE ASME 600LBS H - BORE ASME 800LBS = STANDARD BORE...
  • Page 32 GLOBE VALVES OS & Y - FORGED - ISO 15761/API 602/B16.34 A P P E N D I X C Exploded B.O.M. Welded Bonnet Example only, refer to as-built drawing. Australian Pipeline Valve - Installation, Operation and Maintenance Manual...
  • Page 33 GLOBE VALVES OS & Y - FORGED - ISO 15761/API 602/B16.34 A P P E N D I X C - C O N T. Exploded B.O.M. Pressure Seal Bonnet Example only, refer to as-built drawing. Australian Pipeline Valve - Installation, Operation and Maintenance Manual...

  • Page 34: Warranty

    GLOBE VALVES OS & Y - FORGED - ISO 15761/API 602/B16.34 W A R R A N T Y 1. LIMITED WARRANTY: Subject to the limitations expressed herein, Seller warrants that products manufactured by Seller shall be free from defects in design, material and workmanship under normal use for a period of one (1) year from installation but in no case shall the warranty period extend longer than eighteen months from the date of sale.
  • Page 35 NOTES Australian Pipeline Valve - Installation, Operation and Maintenance Manual...
  • Page 36 If you have any requirements in the field of valves, please contact us for a prompt response. Continuous development of Australian Pipeline Valve products may necessitate changes in the design or manufacture process. Australian Pipeline Valve reserves the right to effect any such changes without prior notice. IOM APV Globe Forged ©...
