Xinje VH6 Series User Manual

Xinje VH6 Series User Manual

Frequency convertor
Hide thumbs Also See for VH6 Series:
Table of Contents

Advertisement

Quick Links

VH6
series frequency convertor
User manual
Wuxi XINJE Electric Co., Ltd.
Data No. INV C 04 20210120 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VH6 Series and is the answer not in the manual?

Questions and answers

Алексей
April 21, 2025

XINJE VH6-DM200: Встраиваемый модуль расширения энкодера для преобразователей- как им пользоваться нужно вращение мотора на настроить на определенное число импульсов энкодера. Спасибо

0
1 comments:
Mr. Anderson
May 10, 2025

To use the Xinje VH6-DM200 encoder expansion module to set the motor rotation to a specific number of encoder pulses, follow these steps:

1. Install the ABZ incremental encoder and connect it to the CN1 input on the VH6-DM200 module using the correct pin assignments (e.g., A+, B+, Z+).

2. Set parameter P1-25 to 0 to enable the use of the ABZ incremental encoder.

3. Set parameter P1-26 to the correct pulse per rotation (PPR) value of your encoder. Valid range: 1–65535. This defines how many pulses correspond to one full motor rotation.

4. Set parameter P1-27 if needed to adjust the encoder installation angle. Valid range: 0.0–359.9°.

5. Set parameter P1-28 to define the encoder phase order (0 for forward direction, 1 for reverse).

These settings allow the inverter to accurately detect motor rotation in terms of encoder pulses and control the motor accordingly.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for Xinje VH6 Series

Summary of Contents for Xinje VH6 Series

  • Page 1 User manual Wuxi XINJE Electric Co., Ltd. Data No. INV C 04 20210120 1.0...
  • Page 2 Basic description  Thank you for purchasing Xinje VH6 series frequency converter. Please read this product manual carefully before carrying out relevant operation.  The manual mainly provides users with relevant guidance and instructions for the correct use and maintenance of the frequency converter. The manual involves the functions of the frequency converter capability, usage, installation and maintenance, etc.

  • Page 4: Table Of Contents

    Catalog 1. PRODUCT INTRODUCTION ............................ 5 1-1. P .............................. 5 RODUCT OVERVIEW 1-1-1. Naming rule ..............................5 1-2. S ............................... 6 PECIFICATION 1-2-1. Technical specification............................ 6 1-2-2. General specification ............................6 1-3. P ..............................9 ART DESCRIPTION 2. INSTALLATION AND WIRING ..........................12 2-1.
  • Page 5 3-5. S ..........................36 WING FREQUENCY FUNCTION 3-6. F ............................. 37 IXED LENGTH CONTROL 3-7. VFD ........................... 38 COUNTING FUNCTION 3-8. M ........................39 OTOR PARAMETERS AND TUNING 3-8-1. Motor parameter setting ..........................39 3-8-2. Motor tuning ..............................40 3-9. U X ..........................
  • Page 6 6-3-4. Reactor selection guide ..........................153 6-3-5. Brake resistor selection ..........................153 7. FAULT AND SOLUTION ............................156 7-1. F ..........................156 AULT ALARM AND SOLUTION 7-2. F ............................159 AULT RECORD QUERY 7-3. F ............................... 159 AULT RESET 7-4. VFD ................
  • Page 7 5. After unpacking, check whether the internal accessories are complete, including operation panel and expansion card. Note: If any of the above five points appear during unpacking, please contact the local Xinje office or Xinje dealer in time, and we will solve the problem for you as soon as possible.
  • Page 8  Wiring Notice 1. Please confirm whether the rated voltage of AC main circuit power supply is consistent with that of frequency converter. Danger of injury and fire. 2. Do not do voltage withstand test on the inverter. Will cause damage to semiconductor components, etc. 3.
  • Page 9  Maintenance and inspection Notice 1. The keyboard, control circuit board and driver circuit board are equipped with CMOS integrated circuits. Please pay special attention when using. If you touch the circuit board directly with your fingers, static induction may damage the integrated chip on the circuit board.
  • Page 10  About the protection level The protection grade IP20 of VH6 series frequency converter is achieved when the status display unit or keyboard is selected. ...

  • Page 11: Product Introduction

    1. Product introduction 1-1. Product overview VH6 series is a full function closed-loop vector inverter developed by Xinje company. The product adopts vector control technology, which realizes the open-loop vector control and closed-loop vector control of asynchronous and synchronous motor, and also strengthens the reliability and environmental adaptability of the product.

  • Page 12: Specification

    1-2. Specification 1-2-1. Technical specification Model VH6-4_ _ _-B Adaptive motor (KW) 11.0 15.0 18.5 22.0 30.0 Input rated current (A) 14.6 20.5 26.0 35.0 38.5 46.5 Power supply capacity 11.0 17.0 21.0 24.0 30.0 40.0 (KVA) Output rated current (A) 13.0 17.0 25.0...
  • Page 13 Item Specification than 20mV. Card B can expand one channel (AI3). AI1 and AI2 support 0 ~ 10V or 0 ~ 20mA input, AI3 supports -10V ~ 10V input and can be used as PT100 input Up to 4 channels of digital output Y, card A is equipped with 1 channel (Y1) + 1 channel (TA1TB1TC1) as standard, and card B is expandable with Digital output channel 1 channel (Y2) + 1 channel (TA2TB2TC2).Y2 terminal can support the...
  • Page 14 Item Specification Timing control Timing control function: the time range is 0.1Min~6500.0Min Two sets of motor parameters can realize the switching control of two Multi-motor switching motors Motor overheat AI3 supports PT100 sensor function protection Flexible and Multi function terminal X has 51 types, Y has 41 types, AO has 19 kinds of diversified terminal logic function selection, meet the general inverter control function functions...

  • Page 15: Part Description

    1-3. Part description  VH6-45P5-B/VH6-47P5-B...
  • Page 16  VH6-4011-B/VH6-4015-B...
  • Page 17  VH6-4018-B/VH6-4022-B/VH6-4030-B...

  • Page 18: Installation And Wiring

    2. Installation and wiring 2-1. Installation environment 2-1-1. Environment requirements  It should be installed in a well ventilated indoor place, and the ambient temperature should be within the range of -10° C ~ 40° C. If the temperature exceeds 40° C, it needs external forced cooling or derating. ...

  • Page 19: Multiple Installation

    2-1-4. Multiple installation Note: the distance of A and B is more than 50mm, and the distance of C and D is more than 100mm. 2-1-5. Vertical installation Note: when installing vertically, the wind shield must be added, otherwise it will cause mutual influence between multiple inverters, resulting in poor heat dissipation.

  • Page 20: Wiring Notice

    2-2. Wiring notice Notice  Ensure that the power supply has been completely cut off for more than 15 minutes before wiring, otherwise there is a risk of electric shock.  It is strictly forbidden to connect the power cable with the output terminal U, V and W of the frequency converter.

  • Page 21: Arrangement And Description Of Main Circuit Terminals

    Note: circuit breaker, contactor, AC reactor, fuse, brake resistor and output reactor are optional parts. Please refer to chapter 6 for details. 2-3-2. Arrangement and description of main circuit terminals  VH6-45P5-B/VH6-47P5-B main circuit terminals  VH6-4011-B/VH6-4015-B, VH6-4018-B/VH6-4022-B/VH6-4030-B main circuit terminals ...

  • Page 22: Wiring Process Of Main Circuit

    ① Please refer to chapter 6 for output cable. ② No capacitor or surge absorber can be connected to the output side of the inverter, otherwise the inverter will be damaged. ③ When the length of motor cable is more than 100m, it is easy to produce electrical resonance due to the influence of distributed capacitance, so it is necessary to install AC output reactor near the frequency converter.

  • Page 23: Configuration And Wiring Of The Control Circuit

    2-4-1. Control circuit terminals (1) Wiring mode slot A expansion card Note: VH6 series frequency converter has four card slots ABCD. Slot A I/O expansion card is standard installed when out of factory, slot BCD expansion card need to be selected by customers.
  • Page 24 Input voltage range: 0~10V (Input impedance: 22kΩ) AI1-GND Input current range: 0~20mA (Input impedance: 500Ω) Analog input AI2-GND Select voltage by switch 0~10V/current input 0~20mA Voltage output range: 0~10V. External load: 2kΩ-1MΩ Current output range: 0~20mA. External load less than 500Ω Analog output AO1-GND Select voltage/current output by switch...

  • Page 25: Analog I/O Wiring

    2-4-2. Analog I/O wiring (1) Analog input terminal AI wiring AI1/AI2 terminal receives analog signal input, and AI1/AI2 dial switch can select input voltage (0 ~ 10V) or current (0 ~ 20mA). The specific wiring is shown in the figure below: (2) Analog output terminal AO wiring AO1 external analog meter can indicate a variety of physical quantities, AO1 dial switch can select output voltage (0 ~ 10V, external load 2KΩ...
  • Page 26  Single inverter source wiring mode  Multi-inverter source wiring mode  Single inverter leakage wiring mode...
  • Page 27  Multi-inverter leakage wiring mode (2) Digital output terminal When the digital output terminal needs to drive the relay, freewheeling diodes should be installed on both sides of the relay coil. Otherwise, it is easy to damage the DC24V power supply. The driving capacity is no more than 50mA.

  • Page 28: Communication Terminal Wiring

    2-4-4. Communication terminal wiring The communication interface provided by frequency converter is standard RS485 communication. The following wiring methods can form a single master single slave or single master multi slave control system. Using the software of upper computer (PC or PLC controller) can realize the real-time monitoring of the inverter in the industrial control system, and realize the complex operation control functions such as remote and high automation.

  • Page 29: Operation And Application

    3. Operation and application 3-1. Operation panel 3-1-1. Appearance The operation panel and control terminal of the frequency converter can control the starting, speed regulating, stopping, braking, operation parameter setting and peripheral equipment of the motor. The appearance of the operation panel is shown in the figure below.

  • Page 30: Led Lights

    Button Name Function Decrease Decrease the value or pause frequency in operation In the editing state, you can choose to set the modification bit of the data; Shift/monitor in other states, you can switch the display state and monitor parameters 3-1-3.
  • Page 31 50.00 -P0- -PC- PC-00 PC-00 05.00 05.00 display Stop ENT/DATA MENU/ESC ENT/DATA operation parameter Confirm, Confirm, Select Select Enter the Select enter enter third parameter parameter first level PC-00 second level menu menu level menu 08.05 08.00 08.00 -PC- PC-01 MENU/ESC MENU/ESC ENT/DATA...

  • Page 32: Multi-Function Buttons

    (4) Set user password Suppose that user password P8-03 has been set to 02345. The numbers in bold in the figure below indicate the flash position. 50.00 0.0.0.0.0 0.0.0.0.5 0.0.0.0.5 0.2.0.0.5 display Button MENU/ESC operation Stop, run user password parameter Ones digit Increase to 2 Shift to the...

  • Page 33: Quick Reference Of Parameters

    3-1-6. Quick reference of parameters There are many function codes in VH6 series. In order to facilitate users to quickly find the function codes, the frequency converter provides two methods to quickly find the function codes (1) Users can select and customize the commonly used function codes, up to 32 of which can be customized to form a user-defined function code group.

  • Page 34: Power On

    The function parameters of user-defined menu come from group PE. If the function parameters are selected by group PE, and set to P0.00 means that they are not selected, and a total of 32 can be set. If "null" is displayed when entering the menu, it means that the user-defined menu is empty.
  • Page 35 Start Wiring as requirements Wiring correct? Input voltage normal? Display power on screen? Contactor Pull-in sound? Display set frequency Power on Power on succeeded failed Check the reason...

  • Page 36: Start To Debug

    3-2-3. Start to debug Start Install the VFD and wiring Observe the safety measures and power on Parameter initialization, and set the control mode according to the application requirements 1. Set startup command, frequency setting mode 2. Set function according to the startup command and frequency setting mode 3.

  • Page 37: Debugging Process

    3-2-4. Debugging process Subprocess Set motor parameters as the label Self-learning without load? Obtain correct motor parameters Set motor Complete static self- Dynamic self- parameters learning learning Set P1-35 by manual Subprocess Set motor parameter as the label Set encoder parameters Self-learning without load? Self-learning with Self-learning...

  • Page 38: Start Stop Of The Vfd

    3-3. Start stop of the VFD 3-3-1. Start stop signal There are three kinds of start stop signal sources of frequency converter, which are panel start stop, terminal start stop and communication start stop. They are selected by function parameter P0-02. 3-3-1-1.

  • Page 39: Start Mode

    Example of communication parameter setting: Parameter Name Setting value Note operation command P0-02 Communication command channel Communication P9-00 Modbus-RTU protocol selection P9-01 Local address Station number 1 P9-02 Baud rate 19200BPS P9-03 Data format 8-E-1 3-3-2. Start mode There are three starting modes of frequency converter, which are direct starting, speed tracking restart and asynchronous machine pre-excitation starting.
  • Page 40 3-3-2-2. Speed tracking restart Setting Parameter Name Note value Speed tracking restart mode is applicable to the large inertia mechanical load. The frequency curve of starting process is shown in the following P4-00 Start mode figure. If the load motor is still running on inertia when the frequency converter is started, the speed tracking and restart can avoid the over-current.

  • Page 41: Stop Mode

    P4-00=2;Pre-excitation start P4-00=2;Pre-excitation start P4-19 Default value: Acc/dec time mode P0-15 P4-01=0.00Hz； P0-15 Upper limit P4-02=0.0s; Upper limit frequency frequency P4-19=0. P4-02 Start frequency hold time DC brake DC brake P0-18 P0-18 time time Acc time Acc time P4-04 P4-04 P4-01 Start frequency...

  • Page 42: Vfd Operation Frequency

    3-4. VFD operation frequency The frequency converter is equipped with two frequency setting channels, named as main frequency source A and auxiliary frequency source B, which can work in a single channel or switch at any time, or even set calculation method for combination, so as to meet the different control requirements of the application site.

  • Page 43: Fixed Length Control

    Output frequency Hz Swing amplitude Aw=Fset*A0-06 Max swing frequency Center frequency Fset Min swing frequency Textile jump frequency Aw=Fset*A0-07 Speed up as Swing frequency Rise time of Speed down acc time period triangular wave as dec time command A0-06 swing amplitude AW: When swing amplitude is relative to the center frequency (A0-05=0), AW＝frequency source P0-05×...

  • Page 44: Vfd Counting Function

    In the application, it is necessary to set the corresponding input terminal function as "length counting input" (function 22). When the pulse frequency is high, the X4 port must be used. The actual length A0-01 can be calculated by dividing the number of pulses sampled by terminals and A0-02 pulse number per meter. When the actual length is greater than the set length A0-00, the multi-function digital output "length reached"...

  • Page 45: Motor Parameters And Tuning

    Length Set count value Set count value Current counting length Multi-function output Y: Set count value reached Multi-function output Y: specified count value reached Multi-function output X: length count reset 3-8. Motor parameters and tuning 3-8-1. Motor parameter setting When the inverter operates in vector control (P0-01 = 1 or 2) mode, it is required to set correct motor parameters, which is different from VF (P0-01 = 0) mode.

  • Page 46: Motor Tuning

    3-8-2. Motor tuning The methods to get the internal electrical parameters of the controlled motor are: dynamic tuning, static tuning, manual input of motor parameters and so on. Tuning mode Suitable condition Effect No load dynamic It is suitable for asynchronous motor. The situation where the motor and Best tuning application system are easy to separate.

  • Page 47: Using Method Of Terminalx

    P1-10: Asynchronous motor no load current Motor 2 PA-06~PA-10: same to above definition If the motor cannot be completely disconnected from the load, select 1 (static tuning of the asynchronous machine) in P1-35 (motor 2 is PA-35), and then press run on the keyboard panel to start the tuning operation of motor parameters.

  • Page 48: Using Method Of Terminal Ao

    relationship is set through P2-18 ~ P2-45. The sampling value of AI can be read in U group function code; the converted calculation value is used for internal subsequent calculation, and users cannot read it directly. 3-12. Using method of terminal AO Analog extension card supports one channel AO output.

  • Page 49: Function Parameters

    4. Function parameters 4-1. Function code list ‘○’: Parameters can be modified during operation. ‘×’: Parameters cannot be modified during operation. ‘—‘: Read only, user cannot change. Group P0: basic operation parameters Group P0: basic operation parameters Default Parameter Name Setting range Modify value...
  • Page 50 Group P0: basic operation parameters Default Parameter Name Setting range Modify value 0: A+B 1: A-B 2: max (A, B) 3: min (A, B) Auxiliary frequency source B 0: Relative to the maximum frequency ○ P0-06 range selection 1: Relative to the main frequency source A Auxiliary frequency source B ○...
  • Page 51 Group P1: first motor parameters Group P1: first motor parameters Default Parameter Name Setting range Modify value P1-00 Motor type selection 0: Common asynchronous motor × Model P1-01 Motor rated power 0.1kW~650.0kW × setting Model P1-02 Motor rated voltage 1V~1200V ×...
  • Page 52 Group P2: Input terminal function parameters Group P2: Input terminal function parameters Default Parameter Name Setting range Modify value Input terminal function 0: no function P2-00 × 1: FWD or run command selection 2: REV or fwd/rev direction Input terminal function P2-01 ×...

  • Page 53: P2-13 X1 Delay Time

    Group P2: Input terminal function parameters Default Parameter Name Setting range Modify value 42: switch between auxiliary frequency Y and preset frequency 43: frequency setting effective terminal 44: DC braking 45: deceleration DC braking 46: emergency stop 47: external stop terminal (only valid for panel control) 48: external terminal stop (according to deceleration time 4)
  • Page 54 Group P2: Input terminal function parameters Default Parameter Name Setting range Modify value percentage ○ P2-22 AI curve 2 min setting 0.00V~P2-24 0.00V curve setting ○ P2-23 corresponding frequency -100.0%~+100.0% 0.0% percentage ○ P2-24 AI curve 2 max setting P2-22~+10.00V 10.00V curve setting...
  • Page 55 Group P2: Input terminal function parameters Default Parameter Name Setting range Modify value percentage AI curve 5 inflection point 2 ○ P2-42 P2-40~P2-44 0.00V setting AI curve 5 inflection point 2 ○ P2-43 setting corresponding frequency -100.0%~+100.0% 0.0% percentage ○ P2-44 AI curve 5 max setting P2-42~+10.00V...
  • Page 56 Group P2: Input terminal function parameters Default Parameter Name Setting range Modify value ○ P2-70 PULSE filter time constant 0.00s~10.00s 0.10s Group P3: output terminal function parameters Group P3: output terminal function parameters Default Parameter Name Setting range Modify value 0: High speed pulse output ○...
  • Page 57 Group P3: output terminal function parameters Default Parameter Name Setting range Modify value 40: zero current state 41: this time of running time arrived ○ P3-06 Y1 output delay time 0.0s~3600.0s 0.0s (normal terminal) ○ P3-07 0.0s~3600.0s 0.0s output delay time ○...
  • Page 58 P4-02 Start frequency duration 0.0s~100.0s 0.0s × Percentage of starting DC braking P4-03 0%~100% × current and pre-excitation current DC braking time / pre-excitation P4-04 0.0s~100.0s 0.0s × time at start-up 0: No protection P4-05 Start protection selection × 1: Protection 0: Start from shutdown frequency P4-06 Speed tracking mode...
  • Page 59 Group P5: VF parameters Default Parameter Name Setting range Modify value P5-02 Multipoint VF voltage point V1 0.0~100.0% 0.0% × P5-03 Multipoint VF frequency point F2 P5-01~P5-05 0.00Hz × P5-04 Multipoint VF voltage point V2 0.0~100.0% 0.0% × P5-05 Multipoint VF frequency point F3 P5-05~P1-04 (motor rated frequency) 0.00Hz ×...
  • Page 60 Group P5: VF parameters Default Parameter Name Setting range Modify value setting 0: invalid P5-24 Overvoltage stall enable × 1: valid Over voltage stall suppression ○ P5-25 0~100 frequency gain Over voltage stall suppression ○ P5-26 0~100 voltage gain Limit of maximum rise frequency P5-27 0~50Hz ×...
  • Page 61 Group P7: Fault parameters Default Parameter Name Setting range Modify value 0: No fault 1: Accelerated over current 2: Deceleration over current 3: Constant speed over current 4: Acceleration overvoltage 5: Deceleration overvoltage P7-00 Third time (last) fault type 6: Constant speed overvoltage 7: Buffer resistance overload fault 8: Under voltage fault 9: Inverter overload...
  • Page 62 Group P7: Fault parameters Default Parameter Name Setting range Modify value terminal status Third time (last time) fault output P7-07 terminal status P7-08 Third time (last time) fault VFD status Third time (last time) fault power on P7-09 time Third time (last time) fault operation P7-10 time P7-13...
  • Page 63 Group P7: Fault parameters Default Parameter Name Setting range Modify value Action selection of fault relay during 0: no action ○ P7-42 automatic fault reset 1: action ○ P7-43 Interval time of automatic fault reset 0.1s~60.0s 1.0s ○ P7-44 Number of automatic reset of faults 0~20 Ones bit: motor overload (Err 10) 0: free stop...
  • Page 64 Group P7: Fault parameters Default Parameter Name Setting range Modify value 1: stop as stop mode Tens bit: user defined fault 2 (Err49) 0: free stop 1: stop as stop mode Hundreds bit: PID feedback lost in operation (Err50) 0: free stop 1: stop as stop mode Thousands bit: speed deviation too large (Err52)
  • Page 65 Group P7: Fault parameters Default Parameter Name Setting range Modify value non-stop Deceleration time of instantaneous stop P7-73 0 ~ 300.0s 20.0 × non-stop Group P8: keyboard and display Group P8: keyboard and display Parameter Name Setting range Default value Modify 0: Menu switching JOG/REV function...
  • Page 66 Group P8: keyboard and display Parameter Name Setting range Default value Modify 10: AI2 voltage 11: AI3 voltage 12: PULSE input pulse frequency, the unit is 0.01KHz 13: PULSE input pulse frequency, the unit is 1Hz 14: PID setting 15: PID feedback 16: load speed display 17: feedback speed, the unit is 0.1Hz 18: actual feedback speed...
  • Page 67 Group P8: keyboard and display Parameter Name Setting range Default value Modify P8-14 Product number P8-15 Software version Inverter module radiator P8-19 0.0℃~100.0℃ temperature ○ P8-20 Output power factor 0.00% ~ 200.0% 100.0 Group P9: communication parameters Group P9: communication parameters Parameter Name Setting range...
  • Page 68 Group PA: process control closed-loop parameters Default Parameter Name Setting range Modify value 1: AI1 2: AI2 3: AI3 4: PULSE pulse setting (X4) 5: communication setting 6: multi-segment command setting 0: AI1 1: AI2 2: AI3 ○ PA-02 Feedback channel selection 3: AI1-AI2 4: AI1+AI2 5: PULSE pulse setting (X4)
  • Page 69 Group PA: process control closed-loop parameters Default Parameter Name Setting range Modify value ○ PA-23 PID initial value 0.0%~100.0% 0.0% ○ PA-24 PID initial value holding time 0.00s~600.00s 0.00s PID operation mode (whether to 0: Not operation when stop ○ PA-25 operate when stop) 1: Operation during shutdown...
  • Page 70 Group PB: multi-speed and simple PLC operation parameters Default Parameter Name Setting range Modify value Simple PLC segment 0 operation ○ PB-17 0.0~6500.0s(h) 0.0s(h) time ○ PB-18 Simple PLC segment 0 acc/dec time Simple PLC segment 1 operation ○ PB-19 0.0~6500.0s(h) 0.0s(h) time...
  • Page 71 Group PB: multi-speed and simple PLC operation parameters Default Parameter Name Setting range Modify value Simple PLC segment 14 operation ○ PB-45 0.0~6500.0s(h) 0.0s(h) time ○ PB-46 Simple PLC segment 14 acc/dec time Simple PLC segment 15 operation ○ PB-47 0.0~6500.0s(h) 0.0s(h) time...
  • Page 72 Group PC: auxiliary operation parameters Default Parameter Name Setting range Modify value 0: max frequency The base frequency of acc/dec PC-10 1: setting frequency × time 2: 50Hz Switching frequency point ○ PC-11 between acceleration time 1 and 0.00Hz~max output frequency 0.00Hz acceleration time 2 Switching frequency point...
  • Page 73 Group PC: auxiliary operation parameters Default Parameter Name Setting range Modify value Current reached detection value 0.0%~300.0% (motor rated current) ○ PC-36 100.0% Current reached detection 2 0.0%~300.0% (motor rated current) ○ PC-37 0.0% range ○ PC-38 Zero current detection value 0.0%~300.0% (motor rated current) 5.0% Zero current detection delay...
  • Page 74 Group PC: auxiliary operation parameters Default Parameter Name Setting range Modify value ○ PC-62 Current detection compensation 0~100 ○ PC-65 Bus voltage reached value Unit is 0.1V 500.0 The bus voltage reached ○ PC-66 Unit is 0.1V 50.0 hysteresis value Model ○...
  • Page 75 Group PE: user optional parameters Parameter Name Setting range Default value Modify ○ PE-25 User optional parameters 25 Same to PE-00 P0.00 ○ PE-26 User optional parameters 26 Same to PE-00 P0.00 ○ PE-27 User optional parameters 27 Same to PE-00 P0.00 ○...
  • Page 76 Group A0: textile Parameter Name Setting range Default value Modify ○ A0-07 Jump frequency amplitude 0.0%~50.0% 0.0% ○ A0-08 Swing frequency period 0.1s~3600.0s 10.0s Triangular wave rise time of ○ A0-09 0.1%~100.0% 50.0% swing frequency Group A1: virtual IO Group A1: virtual IO Default Parameter Name...
  • Page 77 Group A1: virtual IO Default Parameter Name Setting range Modify value 0: connect with physical X1 inside Virtual Y1 output function A1-11 1~42: see group P3 physical Y output selection selection Virtual Y2 output function 0: connect with physical X2 inside ○...
  • Page 78 Group A2: second motor parameters Default Parameter Name Setting range Modify value setting 0.001Ω~65.535Ω (VFD power ≤55kW) Asynchronous motor stator Tuning A2-06 × 0.0001Ω~6.5535Ω (VFD power >55kW) resistance parameters 0.001Ω~65.535Ω (VFD power ≤55kW) Asynchronous motor rotor Tuning A2-07 × 0.0001Ω~6.5535Ω (VFD power >55kW) resistance parameters 0.01mH~655.35mH (VFD power ≤55kW)
  • Page 79 Group A2: second motor parameters Default Parameter Name Setting range Modify value ○ A2-46 Switching frequency 2 P6-05~max output frequency (P0-13) 10.00 Ones bit: integral separation ○ A2-47 Speed loop integral property 0: invalid 1: valid ○ A2-48 Slip gain of vector control 50%~200% 100% SVC speed feedback filter...
  • Page 80 Group AD: AIAO correction Parameter Name Setting range Default value Modify Factory ○ AD-06 AI2 measured voltage 2 6.000V~9.999V calibration Factory ○ AD-07 AI2 display voltage 2 6.000V~9.999V calibration AI3 measured voltage 1 (only AI3 Factory ○ AD-08 -9.999V~9.999V support negative voltage) calibration AI3 display voltage 1 (only AI3 support Factory...
  • Page 81 Group U0: monitor parameters Parameter Name Min unit U0-10 AI2 voltage (V)/current (mA) 0.01V/0.01mA U0-11 AI3 voltage (V) 0.01V U0-12 PULSE input frequency U0-13 PULSE input frequency (Hz) 0.01kHz U0-14 PID setting U0-15 PID feedback U0-16 Load speed display U0-17 Feedback speed (Hz) 0.01Hz U0-18...
  • Page 82 Group U0: monitor parameters Parameter Name Min unit U0-68 Communication extension version Display range Bit0: operation status Bit1: operation U0-69 DP card inverter status direction Bit2: fault U0-70 Speed of transmission DP card /0.01Hz 0.00 ~ max frequency U0-71 Speed of transmission DP card /RPM 0-65535 U0-72 Special current display for communication card...

  • Page 83: Parameter Explanation

    4-2. Parameter explanation 4-2-1. Group P0 basic operation parameter Parameter Name Setting range VF control No speed sensor vector control P0-01 First motor control mode selection (SVC) With speed sensor vector control (FVC) 0: VF control VF control is suitable for low-speed occasions where the control accuracy is not high, and can also be used for occasions where one inverter drives multiple motors.
  • Page 84 0: digital setting (power-off no memory) Set frequency in P0-10, and adjust by keyboard increase and decrease key (or up/down terminal), after power off and power on, the frequency will return to the value of P0-10. 1: digital setting (power-off memory) After setting the frequency in P0-10, press increase, decrease key through the keyboard, or after up/down adjustment, the frequency of the inverter will return to the adjusted value after power down.
  • Page 85 auxiliary frequency sources 0: A+B 1: A-B 2: max(A,B) 3: min(A,B) The using method of auxiliary frequency channel is similar to the main frequency input channel P0-03. Note: when the frequency source superposition is selected (P0-05 ones bit is 1), that is, when the VFD frequency is set by superposition of main and auxiliary frequency: (1) The auxiliary frequency input channel is digital setting (P0-04 = 0 or 1), and the preset frequency (P0-10) does not work any more.
  • Page 86 terminal) during operation, and whether the changed frequency is memorized during shutdown. When no memory is selected, the frequency will return to the set value of P0-10 (preset frequency) after shutdown. Note: when memory is selected, it is only applicable to normal shutdown. If power is cut off suddenly during operation, the frequency will not be memorized after power is turned on again.
  • Page 87 0.00 ~ 650.00 (PC-09=2) Acceleration time refers to the time required for the frequency converter to accelerate from 0Hz to the acceleration/deceleration base frequency (PC-10). Similarly, deceleration time refers to the time required for the frequency converter to decelerate from the acceleration/deceleration base frequency to 0Hz; As shown in the figure, T1 and T3 are the actual acceleration and deceleration time, T2 and T4 are the set acceleration and deceleration time.

  • Page 88: Group P1 First Motor Parameters

    Motor parameter group selection Motor parameter group 2 VH6 series inverter can save two groups of motor parameters, and select the current working motor parameter group through P0-25. Two motors can set their own name plate parameters, and need to complete their own parameter tuning before operation.
  • Page 89 parameter Name Range 0.001Ω~65.535Ω (VFD power≤55kW) P1-06 Asynchronous motor stator resistance 0.0001Ω~6.5535Ω (VFD power>55kW) 0.001Ω~65.535Ω (VFD power≤55kW) P1-07 Asynchronous motor rotor resistance 0.0001Ω~6.5535Ω (VFD power>55kW) Leakage inductance of asynchronous 0.01mH~655.35mH (VFD power≤55kW) P1-08 motor 0.001mH~65.535mH (VFD power>55kW) Mutual inductance of asynchronous 0.01mH~655.35mH (VFD power≤55kW) P1-09 motor...

  • Page 90: Group P2 Input Terminal Multi-Function Parameters

    4-2-3. Group P2 input terminal multi-function parameters VH6 series inverter is equipped with 6 multifunctional digital input terminals (X4 can be used as high speed pulse input terminal) and 32 analog input terminals. Table 4-1 provides a detailed description of each function.
  • Page 91 Setting Function Explanation value Set the inverter operation mode to three wire control mode through Three wire operation control this terminal. Please refer to the description of function code P2-10 ("terminal command mode") for details. Forward jog (FJOG) FJOG is forward jog operation, RJOG is reverse jog operation. Please refer to the description of function code PC-01 and PC-02 for Reverse jog (RJOG) jog operation frequency and jog acceleration and deceleration time.
  • Page 92 Setting Function Explanation value The inverter decelerates and stops, but all operating parameters are memorized. Such as PLC parameters, swing frequency parameters, Operation pause PID parameters. After the signal of this terminal disappears, the inverter will return to the running state before shutdown. PLC pauses in the process of execution.
  • Page 93 Setting Function Explanation value frequency source B and preset frequency (P0-10) frequency Frequency setting active When the terminal is valid, it is allowed to modify the frequency; If terminal it is invalid, it is forbidden to modify the frequency When the terminal is valid, the inverter will switch to DC braking DC brake state directly When the terminal is effective, the frequency converter first...
  • Page 94 command 7 Multi-segment PB-08 command 8 Multi-segment PB-09 command 9 Multi-segment PB-10 command 10 Multi-segment PB-11 command 11 Multi-segment PB-12 command 12 Multi-segment PB-13 command 13 Multi-segment PB-14 command 14 Multi-segment PB-15 command 15 When the frequency source is multi-speed, 100.0% of the function code PB-00 ~ PB-15 corresponds to the maximum frequency P0-13.
  • Page 95 As shown in the figure, in this control mode, K1 is closed and the frequency converter is running forward. K2 is closed and VFD is running reversed, K1 and K2 are closed or disconnected at the same time, and the inverter stops running.
  • Page 96 As shown in the figure, in the control mode, when SB1 button is closed, press SB2 button, the frequency converter rotates forward, and then press SB3 button, the frequency converter reverses, SB1 button is disconnected, and the frequency converter stops. During normal start-up and operation, SB1 button must be kept closed, SB2 and SB3 button commands will take effect at the closing action edge, and the operation state of frequency converter is subject to the last action of the three buttons.
  • Page 97 the filtering time will slow down the response of the X terminal. Parameter Name Range P2-13 X1 delay time 0.0s~3600.0s P2-14 X2 delay time 0.0s~3600.0s P2-15 X3 delay time 0.0s~3600.0s It is used to set the delay time of frequency converter when the state of X terminal changes. At present, only X1, X2 and X3 have the function of setting the delay time.
  • Page 98 Related setting (frequency/torque) 100% 0V(0mA) 10V(20mA) The functions of AI curve 2 (P2-22~P2-25) /AI curve 3 (P2-26~P2-29) are same to AI curve1. Parameter Name Range P2-30 AI curve 4 min input 0V~P2-32 AI curve 4 minimum input P2-31 -100.0%~+100.0% corresponding setting P2-32 AI curve 4 inflection point 1 input P2-30~P2-34...

  • Page 99: Ones Bit

    analog input corresponding set value 100% AI max input corresponding setting AI curve inflection point 1 corresponding AI curve inflection setting point 2 0V(0mA) AI curve inflection 10V(20mA) AI curve point 1 inflection point 2 corresponding setting AI min input corresponding setting -100%...

  • Page 100: Group P3 Output Terminal Multi-Function Parameters

    P2-58 AI3 filter time constant 0.00s~10.00s AI1 filtering time constant is used to set the software filtering time of AI1. When the on-site analog quantity is easy to be interfered, please increase the filtering time to make the detected analog quantity tend to be stable, but the larger the filtering time, the slower the response speed of analog quantity detection.
  • Page 101 P3-05 Relay 2 output function selection Setting Function Explanation value No output The output terminal has no function Indicates that the inverter is in operation state, with output Inverter in operation frequency (can be zero), output ON signal. Fault output (free stop fault) When the inverter fails and stops, the ON signal is output.
  • Page 102 Setting Function Explanation value circuit of the frequency converter is stable, and the frequency converter does not detect any fault information, and the frequency converter is in the operational state, the ON signal is output. the acquisition value of AI1 is greater than that of AI2, the AI1>AI2 ON signal is output When the value of analog input AI1 is greater than PC-43...

  • Page 103: Ones Bit

    Setting Function Explanation value When the starting time of the frequency converter exceeds Current run time arrival the time set by PC-29, the ON signal will be output. Bus voltage reached Refer to PC-65, PC-66 Parameter Name Range P3-06 Y1 output delay time 0.0~3600.0s P3-07 Y2 (normal terminal) output delay time...
  • Page 104 Counting value 0~max counting value Length 0~max setting length Parameter Name Range P3-15 AO1 zero bias coefficient -100.0~+100.0% P3-16 AO gain -10.00~+10.00 P3-17 AO2 zero bias coefficient -100.0~+100.0% P3-18 AO2 gain -10.00~+10.00 The above function codes are generally used to correct the zero drift of analog output and the deviation of output amplitude.

  • Page 105: Group P4 Startup Brake Parameters

    4-2-5. Group P4 startup brake parameters Parameter Name Range 0: direct start P4-00 Startup mode 1: Speed tracking restart 2: Pre-excitation start (AC asynchronous motor) 0: direct start Suitable for small inertia load 1: Speed tracking restart It is suitable for the case of instantaneous power loss and restart of large inertia load. At this time, the corresponding parameters of PA group should be set correctly;...
  • Page 106 Parameter Name Range 0: starting from the shutdown frequency P4-06 Speed tracking mode 1: starting from power frequency 2: Starting from maximum output frequency P4-07 Speed tracking speed 1~100 In order to realize the smooth and shock free starting of the rotating motor. The inverter first judges the speed and direction of the motor, and then starts the motor with the tracking frequency.
  • Page 107 Parameter Name Range 0: deceleration stop P4-22 Stop mode 1: free stop Starting frequency of DC braking P4-23 0.00Hz~max output frequency P0-06 during shutdown P4-24 DC braking time during shutdown 0.0s~100.0s Percentage of DC braking current at P4-25 0%~100% shutdown DC brake waiting time during P4-26 0.0s~100.0s...

  • Page 108: Group P5 Vf Parameters

    4-2-6. Group P5 VF parameters Parameter Name Range Line VF Multi-point VF Square VF The 1.2nd power VF The 1.4th power VF P5-00 VF curve setting The 1.6th power VF The 1.8th power VF Reserved VF complete separation mode VF half separation mode 0: line VF Suitable for common constant torque load.
  • Page 109 Voltage % F1 F2 Note: V1 ~ V3: voltage percentage of section 1 ~ 3 of multipoint VF curve. F1 ~ F3: frequency point of section 1 ~ 3 of multipoint VF curve. Parameter Name Range 0.0％ (auto torque boost) P5-07 Torque boost 0.1％~30.0％...
  • Page 110 quantity, multi-section instruction, PLC, PID or communication. When non digital setting is used, 100% of each setting corresponds to the rated voltage of the motor. When the percentage of analog output setting is negative, the absolute value is taken as the effective setting value. Parameter Name Range...
  • Page 111 Output voltage P5-12 Output frequency P0-19 1: When the voltage decreases to zero, the frequency begins to decrease The output voltage of VF separation first decreases to 0V according to the voltage drop time (P5-12), then the frequency decreases to 0Hz according to the deceleration time (P0-19). Output voltage P5-12...
  • Page 112 Parameter Name Range P5-15 Slip compensation time constant 0.1~10.0s The smaller the response time value of slip compensation is set, the faster the response speed is. Parameter Name Range P5-16 VF over excitation gain 0—200 In the process of inverter deceleration, the over excitation gain can inhibit the rise of bus voltage, but the larger the over excitation gain is, the larger the output current will increase.
  • Page 113 Overcurrent stall action current Note: (1) 150% of over-current stall action current means 1.5 times of rated current of frequency converter; (2) The carrier frequency of high-power motor is below 2kHz. Due to the increase of pulsating current, the wave by wave current limiting response precedes the over-current stall to prevent action starting, resulting in insufficient torque.

  • Page 114: Group P6 Vector Parameters

    4-2-7. Group P6 vector parameters Parameter Name Range P6-00 Speed loop proportional gain 1 1~100 P6-01 Speed loop integral time 1 0.01s~10.00s P6-02 Speed loop proportional gain 2 1~100 P6-03 Speed loop integral time 2 0.01s~10.00s P6-04 Switching frequency 1 0.00~P6-05 P6-05 Switching frequency 2...
  • Page 115 Parameter Name Range P6-08 SVC speed feedback filter time 0.000s~1.000s The speed feedback filtering time of SVC takes effect only when P0-01 = 0. Increasing P6-08 can improve the stability of the motor, but the dynamic response becomes weak. On the contrary, the dynamic response becomes stronger, but too small will cause the motor vibration.

  • Page 116: Group P7 Fault And Protection

    4-2-8. Group P7 fault and protection Parameter Name Fault code P7-00 Third (last) fault type P7-01 Second fault type 0~54 P7-02 First fault type Record the latest three fault types of frequency converter, 0 is no fault. For the possible causes and solutions of each fault code, please refer to the relevant fault description.
  • Page 117 Output terminal state of the first P7-27 fault P7-28 VFD state of the first fault P7-29 The time of the first fault P7-30 The time of the first fault Parameter Name Range Motor overload protection mode 0: forbidden P7-33 selection 1: Allowed P7-34 Motor overload protection gain...
  • Page 118 current. Motor overload protection gain: P7-34=2÷ 5=0.4 Note: the user needs to set the value of P7-34 correctly according to the actual overload capacity of the motor. If the parameter is set too large, it is easy to cause the motor overheating damage and the frequency converter does not alarm and protect in time! Parameter Name...
  • Page 119 Parameter Name Range P7-43 Interval time of automatic fault reset 0.1s~60.0s This parameter is used as the wait time from the fault occurrence to the automatic reset of the fault. Parameter Name Range P7-44 Fault automatic reset times 0~20 This parameter is used as the times of automatic reset after the failure of the frequency converter, and the frequency converter maintains the failure state after exceeding the set value.
  • Page 120 Parameter Name Range 1: stop as stop mode Tens bit: user defined fault 2 (Err49) 0: free stop 1: stop as stop mode Hundreds bit: PID feedback lost in operation (Err50) 0: free stop 1: stop as stop mode Thousands bit: speed deviation too large (Err52) 0: free stop 1: stop as stop mode...

  • Page 121: Group P8 Keyboard And Display

    When the frequency converter detects that the actual speed of the motor deviates from the set frequency, the deviation is greater than the detection value P7-65, and the duration is greater than the detection time P7-66, the frequency converter fault alarms Err52 and it shall be handled according to the action mode of fault protection. When the detection time of speed deviation is 0.0s, the fault detection of excessive speed deviation is cancelled.
  • Page 122 3: Reverse jog through the multi-function key to achieve reverse jog. Parameter Name Range 0: Only in keyboard operation mode, STOP/REST key P8-01 STOP/REST function shutdown function is effective 1: In any operation mode, the STOP/REST key is effective Parameter Name Range 0: no operation...
  • Page 123 07: X input status 23: main frequency A display 08: Y output status 24: auxiliary frequency B display 09: AI1 voltage 25: communication setting value 10: AI2 voltage 26: voltage before AI1 correction 11: AI3 voltage 27: voltage before AI2 correction 12: PULSE input pulse frequency, the unit is 0.01KHz 28: voltage before AI3 correction 13: PULSE input pulse frequency, the unit is 1Hz...

  • Page 124: Group P9 Communication Protocol

    This parameter is only used by the user to view the factory model, and cannot be changed. 1: It is suitable for constant torque load with specified rated parameters. 2: It is applicable to variable torque load (fan and water pump load) with specified rated parameters. Parameter Name Range...

  • Page 125: Group Pa Pid Parameters Of Process Control

    the communication timeout, the system will report a communication timeout (Err44). Usually, it is set to invalid. Parameter Name Range P9-05 MODBUS response delay 0~20ms Response delay: it refers to the interval between the end of data receiving of frequency converter and the sending of data to upper computer.
  • Page 126 Parameter Name Range PA-05 PID value setting 0.0%~100.0% When PA-01 is set to 0, this parameter needs to set. Parameter Name Range PA-06 PID setting change time 0.00s~300.00s The given change time of PID refers to the time required for the given value of PID to change from 0.0% to 100.0%.
  • Page 127 adjustment intensity. The integral time means that when the deviation between PID feedback and given quantity is 100.0%, the integral regulator continuously adjusts the time and the adjustment quantity reaches the maximum frequency. Differential time D: Determine the strength of PID regulator deviation change rate. The longer the differential time is, the stronger the regulation is.
  • Page 128 Same to PA-10~PA-12, the second set of PID parameters. Parameter Name Range PA-19 PID action direction 0: positive action 1: negative action Positive action: when the feedback signal of PID is less than the given quantity, the output frequency of frequency converter rises.

  • Page 129: Group Pb Multi-Speed And Simple Plc

    It is used to select whether the PID continues to calculate in PID shutdown state. In general application, PID should stop operation in shutdown state. Parameter Name Range Ones bit: integral separation 0: invalid 1: valid PA-26 PID integral attribute Tens bit: whether to stop integration after output to limit value 0: continue to integral...
  • Page 130 PB-11 Multi-segment command 11 -100.0% ~ +100.0% PB-12 Multi-segment command 12 -100.0% ~ +100.0% PB-13 Multi-segment command 13 -100.0% ~ +100.0% PB-14 Multi-segment command 14 -100.0% ~ +100.0% PB-15 Multi-segment command 15 -100.0% ~ +100.0% 0: PB-00 setting 1: AI1 2: AI2 PB-16 Multi-segment 0 command setting mode...
  • Page 131 Parameter Name Range PB-45 Simple PLC segment 14 operation time 0.0~6500.0s(h) PB-46 Simple PLC segment 14 acc/dec time PB-47 Simple PLC segment 15 operation time 0.0~6500.0s(h) PB-48 Simple PLC segment 15 acc/dec time Parameter Name Range 0: stop at the end of single operation 1: Keep the final value at the end of single PB-49 Simple PLC operation mode...

  • Page 132: Group Pc Auxiliary Function

    Ones bit: power-off memory 0: not memory Simple power-off memory 1: memory PB-51 selection Tens bit: stop memory 0: not memory 1: memory PLC power down memory refers to memorizing the operation stage and frequency of PLC before power down, and continuing to run from the memory stage when next power on.
  • Page 133 Switching frequency point between PC-11 acceleration time 1 and acceleration 0.00Hz~max frequency time 2 Switching frequency point between PC-12 deceleration time 1 and deceleration 0.00Hz~ max frequency time 2 When controlling motor 1, you can choose different acceleration and deceleration time. Note: when using this function, the multi-function terminal function cannot select the acceleration and deceleration time switching.
  • Page 134 multi-function Y terminal of the frequency converter outputs ON signal. This parameter is used to set the detection range of frequency, which is the percentage relative to the maximum frequency. The figure below is the schematic diagram of frequency arrival. Output frequency Detection...
  • Page 135 When the output frequency of the frequency converter is within the positive and negative detection range of frequency detection value, the multi-function Y outputs the ON signal. VH6 provides two groups of frequency reached detection parameters, setting frequency value and frequency detection range respectively.
  • Page 136 PC-36 Current reached detection value 2 0.0%~300.0% (motor rated current) PC-37 Current reached detection 2 range 0.0%~300.0% (motor rated current) When the output current of the frequency converter is within the set positive and negative detection width of current arrival, the multi-function Y outputs ON signal. VH6 provides two groups of arrival current and detection width parameters.
  • Page 137 It is used to set the voltage value of inverter overvoltage fault. The factory value of 380V voltage level inverter overvoltage point is 810V, and the factory value of 220V voltage level inverter overvoltage point is 400V. Parameter Name Range 100~537V (380V models) PC-45 Under voltage point...
  • Page 138 Parameter Name Range 1: Optimization mode 1 PC-51 SVC optimization selection 2: Optimization mode 2 The SVC optimization mode of asynchronous motor, it does not need to be adjusted generally. Parameter Name Range 0: No compensation PC-52 Dead area compensation mode 1: Compensation mode 1 Parameter Name...
  • Page 139 PC-60 Dormancy delay time 0.0s~6500.0s This set of parameters is used to realize the sleep and wake-up function in water supply application. During the operation of the inverter, when the set frequency is less than or equal to the sleep frequency of PC-58, after the delay time of PC-60, the inverter enters the sleep state and stops automatically.

  • Page 140: Group Pe User Optional Parameters

    When PC-68 is 1, when the operating process of the inverter detects that the temperature of its radiator is high, the carrier frequency will be automatically reduced to reduce the temperature rising of the converter. When the temperature of the radiator is detected to be low, the carrier frequency will automatically return to the set value. 4-2-14.

  • Page 141: Group Pf Torque Control

    PLC reads the parameters of the converter, it can read all the discontinuous parameters through one instruction, which can simplify the PLC communication instruction and improve the communication efficiency. 4-2-15. Group PF torque control Parameter Name Range 0: speed control PF-00 Torque control 1: torque control...

  • Page 142: Group A0 Fixed Length, Counting And Swing Frequency

    Given signal specification of pulse: voltage range 9V-30V, frequency range 0kHz-500kHz. Pulse setting can only be input from the multifunction input terminal X4. The relationship between input pulse frequency and corresponding setting of terminal X4 is set through P2-66-P2-69. The corresponding relationship is the linear correspondence of 2 points. The pulse input corresponds to the percentage of PF-02.
  • Page 143 A0-02 Pulse per meter 0.1~6553.5 The above parameters are used for fixed length control. In the application, it is necessary to set the corresponding input terminal function as "length counting input" (function 20). When the pulse frequency is high, the X4 port must be used. The actual length A0-01 can be calculated by dividing the number of pulses sampled by terminals and A0-02.

  • Page 144: Group A1 Virtual Io

    Triangle wave rise time (s) = swing period A0-08 × rise time coefficient of triangular wave A0-09; Triangle wave falling time (s) = swing period A0-08 × (1 - triangular wave rise time coefficient A0-09). 4-2-17. Group A1 virtual IO Parameter Name Range...
  • Page 145 completed: after the inverter is powered on, it will automatically enter the operation state. The following setting method can be adopted: Set the function of virtual X1 to "forward running" (A1-00=1); Set the valid status mode of virtual X1 terminal as function code (A1-05=xxx1); Set the virtual X1 terminal status to be valid (A1-06=xxx1);...

  • Page 146: Group A2 Second Motor Parameters

    input states of physical X1 ~ X5 on the control board. At this time, virtual Y corresponds to physical X. When the virtual Y output function is not 0, the function setting and use method of virtual YI are the same as those of P3 group Y output.
  • Page 147 Parameter Name Range selection 1: acceleration and deceleration time 1 2: acceleration and deceleration time 2 3: acceleration and deceleration time 3 4: acceleration and deceleration time 4 0.0%: Automatic torque boost A2-38 Motor 2 torque boost 0.1%~30.0% Motor 2 oscillation A2-40 0~100 suppression gain...

  • Page 148: Group Ad Aiao Correction Parameters

    4-2-19. Group AD AIAO correction parameters Parameter Name Range AD-00 AI1 measured voltage 1 0.500V~4.000V AD-01 AI1 display voltage 1 0.500V~4.000V AD-02 AI1 measured voltage 2 6.000V~9.999V AD-03 AI1 display voltage 2 6.000V~9.999V AD-04 AI2 measured voltage 1 0.500V~4.000V AD-05 AI2 display voltage 1 0.500V~4.000V AD-06...

  • Page 149: Group U0 Monitor Parameters

    AD-19 AO2 measured voltage 2 6.000V~9.999V This group of function codes is used to correct the AO of analog output to eliminate the influence of bias and gain of analog output. This group of function parameters have been corrected before leaving the factory, and when the factory value is restored, it will return to the factory corrected value.
  • Page 150 Parameter Name Min unit U0-35 Target torque (%) 0.1% U0-36 Torque upper limit 0.01% U0-37 Synchronous motor rotor position U0-38 Rotation position U0-39 ABZ position U0-40 Motor temperature 1⁰C U0-41 Power factor angle 0.1° U0-42 Setting frequency (%) 0.01% U0-43 Operation frequency (%) 0.01% U0-44...

  • Page 151: Emc

    5. EMC 5-1. EMC compliant installation guidelines The output of the inverter is PWM wave, which will produce electromagnetic noise when it works. In order to reduce the interference of the inverter to the outside world, this section introduces the installation method of EMC in noise suppression, field wiring, grounding, leakage current, power filter use and so on.

  • Page 152: Field Wiring And Grounding

    the frequency converter as possible. The signal line should use shielded wire, the shielding layer should be single ended grounding, and should be as far away from the inverter and its input and output lines as possible. If the signal wire must intersect with the strong current cable, the two should be kept orthogonal.

  • Page 153: Model And Dimension

    6. Model and dimension 6-1. VH6 series VFD electrical specification Device Input power Input current Output current Matched Voltage level VFD model code capacity (KVA) motor (kW) VH6-45P5-B 14.6 13.0 VH6-47P5-B 11.0 20.5 17.0 VH6-4011-B 17.0 26.0 25.0 11.0 Three phase...
  • Page 154  VH6-4011-B/VH6-4015-B Unit: mm 1.安装、运行前请务必阅读使用说明书,否则会有电击危险！ 2.在通电状态下和切断电源15分钟以内，请勿拆下盖板！ 3.进行维护、检查及接线时，请在切断输入侧和输出侧电源后，等待15分钟， 15 min 待电源指示灯彻底熄灭后开始作业。 MENU/ESC ENT/DATA STOP REST  VH6-4018-B/VH6-4022-B/VH6-4030-B Unit: mm 1.安装、运行前请务必阅读使用说明书,否则会有电击危险！ 2.在通电状态下和切断电源15分钟以内，请勿拆下盖板！ 3.进行维护、检查及接线时，请在切断输入侧和输出侧电源后，等待15分钟， 待电源指示灯彻底熄灭后开始作业。 15 min MENU/ESC ENT/DATA STOP REST...

  • Page 155: Accessories Selection Guide

     Dimension drawing of operation panel mounting bracket The gray area is the hollowed out part, and the middle hollowed out area is 84.6× 101.5mm. The diameter of the four corner hollowed out area is 4.34 circle, and M4 screws and nuts are put in to fix the bracket on the panel. 6-3.

  • Page 156: Cable Selection

    6-3-2. Cable selection Power cable  The size of input power cable and motor cable shall comply with local regulations;  The input power cable and motor cable must be able to withstand the corresponding load current;  The maximum rated temperature margin of motor cable under continuous working condition should not be lower than 70℃;...
  • Page 157 For low-voltage digital signal, it is better to choose double layer shielded cable, but single shielded or unshielded twisted pair can also be used, but for frequency signal, shielded cable must be used. Relay cables need to be shielded with metal braid. The keyboard needs to use network cable.

  • Page 158: Selection Guidance Of Circuit Breaker, Contactor And Fuse

    Insulation inspection Before operation, please check the insulation of motor and motor cable (1) Make sure that the motor cable is connected to the motor, and then remove the motor from the output terminal UVW of the inverter. (2) Use a 500VDC megger to measure the insulation resistance between each phase conductor and the protective grounding conductor.

  • Page 159: Reactor Selection Guide

    50m, the output reactor must be added at the output side of the frequency converter.  VH6 series frequency converters with power of 18.5kw and above have built-in DC reactors. DC reactor can improve the power factor, avoid the damage of rectifier bridge caused by excessive input current of frequency converter due to large capacity transformer, and avoid the damage of rectifier circuit caused by grid voltage mutation or harmonic caused by phase controlled load.
  • Page 160 U × U / R = Pb U --- Braking voltage of system stable braking (different system U values are different, the default braking voltage of VH6 series inverter is 700V, which can be adjusted through P7-59), Pb ---Braking power.
  • Page 161 Note: (1) The values in the table are guidance data. Users can choose different resistance values and power according to the actual situation (but the resistance value must not be less than the recommended value in the table, and the power can be larger). The selection of braking resistance needs to be determined according to the power generated by the motor in the practical application system, which is related to the system inertia, deceleration time, energy of potential energy load, etc, Customers need to choose according to the actual situation.

  • Page 162: Fault And Solution

    7. Fault and solution 7-1. Fault alarm and solution When the inverter is abnormal, the LED tube will display the function code and its content of the corresponding fault, the fault relay will act, and the inverter will stop output. In case of fault, if the motor is rotating, it will stop freely until it stops rotating.
  • Page 163 Code Name Reason Solution 3. The deceleration time is too short resistor 4. There is no additional brake unit and 3. Increase deceleration time brake resistor 4. Add brake unit and resistor 1. High input voltage 1. Adjust the voltage to the normal Constant speed 2.
  • Page 164 Code Name Reason Solution fault according to the nameplate according to the name plate 2. Parameter tuning process timeout 2. Check the lead from inverter to motor 1. Encoder model mismatch 1. Set encoder type correctly 2. Encoder connection error 2.

  • Page 165: Fault Record Query

    Code Name Reason Solution lost in operation value P7-27 to an appropriate value In the process of inverter operation, change Switch the motor after the frequency Switch motor in Err51 the current motor selection through the converter stops operation terminal 1.

  • Page 166: Vfd Common Fault Analysis Of Frequency Converter

    7-4. VFD common fault analysis of frequency converter 7-4-1. Motor not rotate Motor not rotate Whether the output Keyboard side empty Close contactor display? contactor is closed Check Operation normal no Find reason as fault Display normal VFD fault error info fault info voltage...

  • Page 167: Motor Vibration

    7-4-2. Motor vibration Motor vibration or abnormal noise Motor parameters and type ok? Set correct motor parameters Carry out parameter self-learning? Carry out parameter self-learning Is VF oscillation parameter set Set correct parameters normally? Whether the given frequency Check the frequency setting fluctuates abnormally? Is the load abnormal fluctuation? Check the load...

  • Page 168: Motor Overheat

    7-4-4. Motor overheat Motor overheat Set correct Motor parameter correct? parameters Parameter self- Do Parameter self-learning? learning Is the frequency converter always running at low speed Is it a variable frequency Use variable motor frequency motor Load too large? Reduce the load Motor 3-phase balance? Replace the motor Is the carrier frequency too...

  • Page 169: Over Current

    7-4-5. Over current Over current UVW short circuit to the Eliminate the short circuit to ground? ground fault Motor short circuit to the Replace the motor ground? Motor type and parameters Set correct parameters and correct? types Do self-learning? Self-learning Acceleration time too Adjust the acc time short?

  • Page 170: Vfd Overheat

    7-4-6. VFD overheat VFD overheat Load too large? VFD Enlarge capacity, reduce the load capacity too small? Ambient temperature too Installation of cooling device or high derating of frequency converter Whether the fan of frequency converter VFD fault makes abnormal noise Is the radiator blocked Clean the radiator Is the carrier frequency...

  • Page 171: The Motor Stalls During Acceleration And Deceleration

    7-4-7. The motor stalls during acceleration and deceleration The motor stalls during acceleration and deceleration Increase the acc/dec Acc/dec time too short time Thicken the motor cable, shorten the Test the motor terminal wiring distance and adjust the voltage of voltage is in the range? output reactor Is the motor load or inertia...

  • Page 172: Maintenance

    8. Maintenance The change of the operating environment of the inverter, such as the influence of temperature, humidity, smoke, etc., and aging of the internal components of the converter, may lead to various faults of the inverter. Therefore, the inverter must be checked daily during storage and use, and regular maintenance should be carried out. 8-1.

  • Page 173: Warranty Of Frequency Converter

    Fuse 10 years The service conditions for the replacement time of the above inverter components are as follows: (1) Ambient temperature: annual average 30℃. (2) Load factor: below 80%. (3) Running time: less than 12 hours per day. 8-3. Warranty of frequency converter The company will provide warranty service in case of the following conditions: (1) The warranty scope only refers to the inverter body;...

  • Page 174: Appendix

    Appendix Appendix A. Extension card VH6 series frequency converter can support abundant fieldbus and encoder types by connecting abundant expansion cards. This chapter describes the installation and use of each expansion card. Slot C Slot A Fieldbus Standard IO card:...

  • Page 175: Appendix A-2. Extension Card Installation

    Appendix A-2. Extension card installation Note: (1) There will be an ABCD letter mark under each card slot of the inverter to identify the card slot type, which corresponds to the ABCD on the expansion card. Only when the letters on the expansion card and under the card slot of the inverter are the same, can they be installed and used normally.

  • Page 176: Appendix A-3-2. Vh6-B100 (Slot B Io Card)

    Type Terminal Name Function output current 200mA. Cannot use for other ways, only for X terminal power supply. 10V-GND +10V power supply Supply +10V power supply, max output current 20mA. X1-COM Input terminal 1 Optocoupler isolation input; compatible with bipolar input;...

  • Page 177: Appendix A-4. Communication Extension Card

    VH6-CC100 is an expansion interface card specially designed for EtherCAT protocol by Xinje company, which is suitable for Xinje inverter. Xinje inverter can be connected to the international standard EtherCAT network and exist as a slave station with this card.

  • Page 178: Appendix A-4-2. Vh6-Cn100 (Canopen Communication Card)

    VH6-CN100 is an expansion interface card specially designed for CANopen protocol by Xinje company, which is especially suitable for Xinje inverter. Through this card, Xinje inverter can be connected to CANopen network of international standard and exist as a slave station.
  • Page 179 5V power supply LED status VH6-DM100 expansion card has two LED lights to display the current expansion card status, and its functions are shown in the table below: Status Function LED1 Always ON PG card system normal PG card operation Always PG card system is abnormal, stop working light green...

  • Page 180: Appendix A-5-2. Vh6-Dm200 (Simple Incremental

    The user needs to define the signal pin connection of encoder according to the following core color and pin number: CN1 encoder signal input Color Function Color Function Yellow White 5V power supply Yellow black Gray Green Gray black Green black Blue black Blue Wide...
  • Page 181 Encoder input interface DB15 female port Frequency division Not support Pin definition CN1 encoder signal input Name Name 5V power supply PG card wiring VH6-DM200 PG card has one 10-core cable when out of factory, which is convenient for users to connect the field encoder signal and PG card.

  • Page 182: Appendix B. Communication Protocol

    Appendix B. Communication protocol Appendix B-1. Communication protocol overview VH6 series frequency converter provides the general RS485 communication interface in industrial control to users. The communication protocol adopts MODBUS standard communication protocol. The converter can be used as slave and communicate with the upper computer with the same communication interface and the same communication protocol (such as PLC controller and PC) to realize centralized monitoring of the frequency converter.

  • Page 183: Appendix B-3-2. Communication Data Structure

    (1－8－1, even parity) Start Even Stop parity (1－8－1, no parity) Start Stop Appendix B-3-2. Communication data structure RTU mode START Keep no input signal at least 10ms Address Communication address: 8-bit binary address Function Function code: 8-bit binary address DATA（n-1） Data content: N*8-bit data, N<=8, max 8 bytes ……………...

  • Page 184: Appendix B-3-3. Communication Protocol Parameter Address

    (2) Function code 06H: write into the register For example, write 50.00Hz in the inverter address 1000H. RTU mode: Format of inquiry information Format of response information Address Address Function code Function code Register address Register address Data contents Data contents CRC CHECK Low CRC CHECK Low CRC CHECK High...
  • Page 185 of group P0, and 10 represents the hexadecimal data format of function code 16 in function group. A0-15 function parameter, communication address is 0xA00F, A0 represents A0 group function parameter, 0F represents hexadecimal data format of function code in function group serial number 15. ...
  • Page 186 Definition Modbus address Function Note 0006H: constant speed over voltage 0007H: buffer resistance overload fault 0008H: under voltage fault 0009H: inverter overload 000AH: motor overload 000BH: input phase missing 000CH: output phase missing 000DH: radiator overheating 000EH: contactor fault 000FH: current detection fault 0010H: motor tuning fault 0011H: code disk failure 0012H: motor short circuit to ground...
  • Page 187 WUXI XINJE ELECTRIC CO., LTD. 4th Floor Building 7, Orignality Industry park, Liyuan Development Zone, Wuxi City, Jiangsu ProAInce 214072 Tel: 400-885-0136 Fax: (510) 85111290 www.xinje.com...
