Clevertronics L10 Ultrablade Pro LUBPRO-SM Series Installation & Maintenance Instructions

Testing:
Once connected to the 240V mains supply, the unit must be allowed to charge the battery for at least 24
hours. Conduct the following tests:
•
For the first test, the emergency lamp must remain illuminated for at least 2 hours after
disconnection from the mains supply.
•
Subsequent tests require the unit to illuminate for at least 90 minutes. The results of all tests are
required to be recorded in a service logbook, which is to be kept on-site at all times. If the unit fails
to remain illuminated for the requisite time, remedial action must be taken to repair the situation and
once completed, the unit must pass a subsequent test. For more specific information, please refer
to the current edition of the AS 2293.3 Standard.
Ultrablade Maintenance:
LED Lamp Replacement:
•
Use only the LED Strip recommended in the
Spares Parts list of this instruction.
•
Disconnect battery from LED driver.
•
Remove the screw holding the driver PCA.
Remove the PCA.
•
Remove the 4 screws holding the battery
bracket. Remove the bracket with the
battery.
•
Disconnect the signal cable from LED strip.
•
Remove 4 self-tapping screws and unclip
the LED strip.
•
Install the new LED strip following the
above procedure in reverse.
Battery Replacement:
•
Use only the battery recommended in the
Spares List on this instruction.
•
Remove the battery from battery
compartment, un-plug the lead from the
battery connector remove the old battery.
•
Plug the new battery into the battery
connector.
•
Secure the battery into the battery
compartment
Rated Emergency Lumen Output in accordance with AS2293.1 (refer to
spacing tables for installation positions), not Included –TH version:
C0=E6.3 (8m) C90=E6.3 (8m)
Caution:
On many building sites, power circuits may be cut off in an uncontrolled and repetitive basis during
construction. As a result, any Exit & Emergency Units, on these circuits, will have their batteries
discharged or "cycled". The battery in this fitting has been selected to give excellent long-life
performance in a controlled AS2293 testing environment. Excessive battery cycling will reduce through-
life performance and may lead to premature battery failure. Battery warranty claims, as a result of such
abuse, are specifically EXCLUDED from Clevertronics warranty terms.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms-conditions-sale-australia-nz
Trouble Shooting:
Below are a list of common problems and their
possible causes.
Fault: The Green LED Test Switch
indicator is not illuminated.
Check: A.C. is connected and is turned on.
Battery is connected
Test Switch for damage.
Fault: Lamp does not illuminate in
emergency mode.
Check: A.C. is connected.
Lamp is correctly inserted.
Battery is connected
Fault: Lamp illuminates in emergency
mode, but only stays on for a short
period.
Check: Battery has been allowed to charge for
at least 24 hours.
Battery for damage.
™
L10 Ultrablade Pro Surface Mount LED Exit
Installation & Maintenance Instruction Leaflet
Designed in Australia to comply with the
requirements of AS2293.3:2005 and AS/NZ CISPR:15
NOTE: Standard product codes with this symbol
are enabled with Clevertest Plus capability. Please
refer to the operation guide supplied with the product
for details.
Models: LUBPRO-SM-ww-xx-yy-zz
Testing:
Manual Test xx = Blank
Zoneworks xx = ZW
Z/W DATA xx = DATA
DALI Comp. xx = DALI
Clevertest xx = CT
(NOTE: -CT Products supplied with the Clevertest Plus Symbol
capability. Please refer to the operation guide supplied with the product for details).
Spare Parts:
1530030 – Battery, 3.3 Volt 2.5Ah Li-ion
8002178 – PCA: UBP LED strip PCB Assy
8002940 - PCA: LUBPRO #CT10142-L8 CTP
Important:
It is illegal for anyone, except for a licensed electrician to install or maintain this product. Before installation,
ensure that the electricity supply has been switched off and isolated. Installation must be carried out in
accordance with the relevant Australian and International Standards.
Victoria (Head Office & Manufacturing)
195 Chesterville Rd
Moorabbin VIC 3189
Phone: +61 3 9559 2700
Fax: +61 3 9559 2799
New South Wales
Phone: +61 2 8805 6400
Fax: +61 2 8805 6444
Queensland
Phone: +61 7 3442 9700
Fax: +61 7 3442 9777
South Australia/Northern Territory
Phone: +61 8 8301 8800
Fax: +61 8 8351 8286
Western Australia
Phone: +61 8 9248 3720
Fax: +61 8 9248 3725
New Zealand
Phone: +64 800 548 448
Options:
Black zz = BLK
Theatre ww = TH
yy = R
Running Man
Running Man Left Arrow yy = RL
Running Man Right Arrow yy = RR
Double Side Running Man yy = DS-R
Double Side Running Man with Arrow yy = DS-RAOW
Special Purpose Sign yy = SP
are activated with Clevertest PLUS
1943052 V1.3 June 2019
