  • Page 1 AMPAK AP6356SDXX Evaluation Kits User manual Version 1.0 Revision History Date Revision Content Revised By Version 2015/12/28 Initial released Aron AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 2 Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 3 Radiation Exposure Statement: The product comply with the FCC portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available.
  • Page 4 Industry Canada statement: This device complies with ISED’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Le présent appareil est conforme aux CNR d’...
  • Page 5 1) Le module émetteur peut ne pas être coïmplanté avec un autre émetteur ou antenne. Tant que les conditions ci-dessus sont remplies, des essais supplémentaires sur l'émetteur ne seront pas nécessaires. Toutefois, l'intégrateur OEM est toujours responsable des essais sur son produit final pour toutes exigences de conformité supplémentaires requis pour ce module installé.
  • Page 6 The end user manual shall include all required regulatory information/warning as show in this manual. Manuel d'information à l'utilisateur final L'intégrateur OEM doit être conscient de ne pas fournir des informations à l'utilisateur final quant à la façon d'installer ou de supprimer ce module RF dans le manuel de l'utilisateur du produit final qui intègre ce module.
  • Page 7 5470 350 MHz et de à 5725 MHz doit être conforme à la limite de la p.i.r.e; (iii) le gain maximal d'antenne permis (pour les dispositifs utilisant la bande de 5 725 à 5 850 MHz) doit être conforme à la limite de la p.i.r.e. spécifiée pour l'exploitation point à point et l’exploitation non point à...
  • Page 8 第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均 不得擅自變更頻率、加大功率或變更原設計之特性及功能。 第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干 擾現象時，應立即停用，並改善至無干擾時方得繼續使用。 前項合法通信，指依電信法規定作業之無線電通信。 低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設 備之干擾。 1. 本模組於取得認證後將依規定於模組本體標示審驗合格標籤。 2. 系統廠商應於平台上標示 「本產品內含射頻模組： XXXyyyLPDzzzz-x」 字樣。...
  • Page 9 9. J10: GPIO_2 (input/output) and GPIO_3 (input/output) 10. J11: WL_VIO power path for 1V8 or 3V3 selection. 11. A1: I-PEX connector let RF signal in/out path, you could connect with RF cable or AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information...
  • Page 10 Note to the VDDIO voltage level should be the same with GPIO voltage level of Host CPU. (VDDIO 3.3V or 1.8V selection by jump J11)  Pull High J4 are necessary . WiFi software setup: Please follow up software guideline of Ampak official released. AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 11 Connects an external antenna at I-PEX connector on the evaluation board.  Note to the VDDIO voltage level should be the same as GPIO voltage level of Host CPU. USB： Figure5. Bluetooth verification connection interface to Host USB AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 12 Host USB control interface.  Connects an external antenna at I-PEX connector on the evaluation board. WiFi and Bluetooth software setup: Please follow up software guideline of Ampak official released. AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information...
  • Page 13 正基科技股份有限公司 SPECIFICATION SPEC. NO.： REV： DATE： 09. 07.2015 PRODUCT NAME： AP6356SDXX Customer APPROVED Company Representative Signature REVIEW PREPARED APPROVED DCC ISSUE AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 14 AMPAK AP6356SDXX 2x2 WiFi + Bluetooth4.1 Module Spec Sheet AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 15 2015/03/18 Dora - Pin map and physical dimension modified 2015/05/12 -Add Part Number Description Dora 2015/06/29 -Add Packet type and total pins Dora 2015/09/07 -Modify label quantity and MSL Dora AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 16: Table Of Contents

    11. Recommended Reflow Profile ................. 32 12. Package Information ..................33 12.1Label ......................33 Label C Inner box label ..................33 Label D Carton box label .................. 33 12.2 Dimension ....................34 AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 17 12.3 MSL Level / Storage Condition ..............36 AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 18: Introduction

    1. Introduction AMPAK Technology would like to announce a low-cost and low-power consumption module which has all of the WiFi and Bluetooth functionalities. The highly integrated module makes the possibilities of web browsing, VoIP, Bluetooth headsets applications. With seamless roaming capabilities and advanced security, also could interact with different vendors’...

  • Page 19: Features

    Adaptive frequency hopping (AFH) for reducing radio frequency interference. A simplified block diagram of the module is depicted in the figure below. VDDIO VBAT Switch PCIe Discrete WLAN UART Switch WLAN Discrete PCM/I2S RTC_CLK 32.768KHz Ref_CLK AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 20: Deliverables

    Agency certified pre-tested report with the adapter board. 3.2 Regulatory certifications The product delivery is a pre-tested module, without the module level certification. For module approval, the platform’s antennas are required for the certification. AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 21: General Specification

    Input supply Voltage -0.5 VDDIO Digital/Bluetooth/SDIO/ I/O Voltage -0.5 4.2.2 Recommended Operating Rating The module requires two power supplies: VBAT and VDDIO. Min. Typ. Max. Unit Operating Temperature deg.C VBAT VDDIO AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 22: Wifi Rf Specification

    PER @ -75 dBm, typical - MCS=0 PER @ -90 dBm, typical SISO Receive Sensitivity (11n,20MHz) - MCS=1 PER @ -87 dBm, typical @10% PER - MCS=2 PER @ -85 dBm, typical AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 23 - MCS=0, NSS1 PER @ -89 dBm, typical SISO Receive - MCS=1, NSS1 PER @ -86 dBm, typical Sensitivity (11ac,20MHz) @10% - MCS=2, NSS1 PER @ -85 dBm, typical - MCS=3, NSS1 PER @ -81 dBm, typical AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 24 - MCS=7, NSS1 PER @ -71 dBm, typical - MCS=8, NSS1 PER @ -67 dBm, typical - MCS=9, NSS1 PER @ -65 dBm, typical - MCS=0, NSS2 PER @ -86 dBm, typical AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 25: 5Ghz Rf Specification

    PER @ -76 dBm, typical - 54Mbps PER @ -72 dBm, typical - MCS=0 PER @ -89 dBm, typical SISO Receive Sensitivity (11n,20MHz) @10% PER - MCS=1 PER @ -86 dBm, typical AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 26 - MCS=0, NSS1 PER @ -87 dBm, typical SISO Receive Sensitivity - MCS=1, NSS1 PER @ -85 dBm, typical (11ac,20MHz) @10% PER - MCS=2, NSS1 PER @ -83 dBm, typical AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 27 - MCS=6, NSS1 PER @ -71 dBm, typical - MCS=7, NSS1 PER @ -70 dBm, typical - MCS=8, NSS1 PER @ -65 dBm, typical - MCS=9, NSS1 PER @ -64 dBm, typical AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 28 - MCS=0, NSS2 PER @ -81 dBm, typical - MCS=9, NSS2 PER @ -56 dBm, typical Maximum Input Level 802.11a/n : -30 dBm Antenna Reference Small antennas with 0~2 dBi peak gain AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 29 Band (GHz) frequencies(MHz) Numbers 5180 5200 5.15GHz~5.25GHz 5220 5240 5260 5280 5.25GHz~5.35GHz 5300 5320 5500 5520 5540 5560 5580 5.5GHz~5.7GHz 5600 5620 5640 5660 5680 5700 5745 5765 5.725GHz~5.825GHz 5785 5805 AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 30: Bluetooth Specification

    GFSK (1Mbps) Sensitivity @ BER=0.01% -80 dBm for π/4-DQPSK (2Mbps) Sensitivity @ BER=0.01% -78 dBm for 8DPSK (3Mbps) GFSK (1Mbps):-20dBm π/4-DQPSK (2Mbps) :-20dBm Maximum Input Level 8DPSK (3Mbps) :-20dBm AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 31: Pin Assignments

    < TOP VIEW > 7.2 Pin Definition Name Type Description － No connect － No connect 1: SPROM is present JTAG_TDI_GPIO4 0: SPROM is absent (default). Applicable in PCIe HOST mode AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 32 PCIe host indication to reset the device － Ground connections PCIE_RCLK_N PCI Express differential clock input-Negative PCIE_RCLK_P PCI Express differential clock input-Positive － Ground connections PCIE_TX_N PCI Express transmit data-Negative PCIE_TX_P PCI Express transmit data-Positive AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 33 It can be used as WL_LED BT_I2S_DI I2S data line input BT_I2S_CLK I2S data line clock － Ground connections USB_DM USB serial differential data Negative USB_DP USB serial differential dataPositive － Ground connections AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 34 － Ground connections － Ground connections － Ground connections － Ground connections － Ground connections － Ground connections － Ground connections － Ground connections － Ground connections － Ground connections AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 35: Dimensions

    8. Dimensions 8.1 Physical Dimensions (Unit: mm) < TOP VIEW > TOP VIEW > AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 36: Layout Recommendation

    8.2 Layout Recommendation (Unit: mm) < TOP VIEW > AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 37: External Clock Reference

    SDIO Pin Description SD 4-Bit Mode DATA0 Data Line 0 DATA1 Data Line 1 or Interrupt DATA2 Data Line 2 or Read Wait DATA3 Data Line 3 Clock Command Line AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 38: Host Interface Timing Diagram

    BT section. Low asserting reset for Bluetooth. This pin has no effect on WLAN and does not control any PMU functions. This pin must be driven high or low (not left floating). WLAN=ON, Bluetooth=ON AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 39 WLAN=OFF, Bluetooth=OFF WLAN=ON, Bluetooth=OFF WLAN=OFF, Bluetooth=ON AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 40: Sdio Default Mode Timing Diagram

    10.2 SDIO Default Mode Timing Diagram AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 41: Sdio High Speed Mode Timing Diagram

    10.3 SDIO High Speed Mode Timing Diagram AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 42: Sdio Bus Timing Specifications In Sdr Modes

    10.4 SDIO Bus Timing Specifications in SDR Modes Clock timing(SDR Modes) Card Input timing (SDR Modes) AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 43 Card output timing (SDR Modes up to 100MHz) Card output timing (SDR Modes 100MHz to 208MHz) AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 44: Sdio Bus Timing Specifications In Ddr50 Mode

    10.5 SDIO Bus Timing Specifications in DDR50 Mode Data Timing AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 45: Recommended Reflow Profile

    11. Recommended Reflow Profile Referred to IPC/JEDEC standard. Peak Temperature : <250°C Number of Times : 2 times 250℃ ° C/sec 40~70 sec 2.5℃/sec AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 46: Package Information

    12. Package Information 12.1Label Label A Anti-static and humidity notice Label B MSL caution / Storage Condition Label C Inner box label . Label D Carton box label . AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 47: Dimension

    12.2 Dimension AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 48 Humidity indicator Desiccant AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 49 12.3 MSL Level / Storage Condition ※NOTE : Accumulated baking time should not exceed 96hrs AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
