AMPAK Technology Inc.
i
Doc. NO:
Ampak
AP6234AL
Evaluation Kits

User manual

Version 1.2
Revision History
Revision Content
Initial released
Modify figure1
Modify figure1
www.ampak.com.tw
Revised By Version
Dora
Dora
Dora
Proprietary & Confidential Information
1.0
1.1
1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AP6234AL and is the answer not in the manual?

Questions and answers

Related Manuals for Ampak AP6234AL

Summary of Contents for Ampak AP6234AL

  • Page 1: User Manual

    Ampak AP6234AL Evaluation Kits User manual Version 1.2 Revision History Date Revision Content Revised By Version 2012/12/26 Initial released Dora 2013/03/07 Modify figure1 Dora 2013/06/06 Modify figure1 Dora AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 2: Important Note

    Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 3 This device is intended only for OEM integrators under the following conditions: 1) The transmitter module may not be co-located with any other transmitter or antenna, 2) For all products market in US, OEM has to limit the operation channels in CH1 to CH11 for 2.4G band by supplied firmware programming tool.

  • Page 4: Industry Canada Statement

    Industry Canada statement: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

  • Page 5: Note Importante

    Radiation Exposure Statement: The product comply with the Canada portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available.
  • Page 6 Plaque signalétique du produit final Le produit final doit être étiqueté dans un endroit visible avec l'inscription suivante: "Contient des IC: 11956A-AP6234A". Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module.
  • Page 7 해당 무선설비는 전파혼신 가능성이 있으므로 인명안전과 관련된 서비스는 할 수 없음 해당 무선 설비는 5150-5250MHz 대역에서 실내 에서안 사용만 수 있웅. (Translation: the service related to human safety is not allowed because this device may have the possibility of the radio interference.) For RF device using 5150-5250MHz, this device shall be used for indoor only.
  • Page 8 802.11b/802.11g/BT 警語： 第十二條→經型式認證合格之低功率射頻電機，非經許可，公司，商號或使用者均不得擅自變更頻率、加大功率或 變更 原設計之特性及功能。 第十四條→低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應 立即停用，並改善 至無干擾時方得繼續使用。 前項合法通信，指依電信法規定作業之無線電通信。 低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻 射性電機設備之干擾。 802.11a 警語： 無線傳輸設備 (UNII) 在 5.25-5.35 秭赫頻帶內操作之無線資訊傳輸設備，限於室內使用。 (4.7.5) 無線資訊傳輸設備忍受合法通信之干擾且 不得干擾合法通信；如造成干擾，應立即停用，俟無干擾之虞，始得繼續 使用。 (4.7.6) 無線資訊傳設備的製造廠商應確 保頻率穩定性，如依製造廠商使用手冊上所述正常操作，發射的信號應維持於操作 頻帶中。(4.7.7) 模組請加註 本模組於取得認證後將依規定於模組本體標示審驗合格標籤 CCAFXXLPXXXXTX) 系統廠商應於平台上標示「本產品內含射頻模組: 」字樣...
  • Page 9 6. J6: VBAT / WL_VIO / BT_VIO for main system I/O power path. 7. J7: 5V DC mini USB input connector. 8. J8: Standard SDIO interfaces for Wi-Fi performance measured. AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 10 Note to the VDDIO voltage level should be the same with GPIO voltage level of Host CPU. (VDDIO 3.3V or 1.8V selection by jump J11) WiFi software setup: Please follow up software guideline of Ampak official released. AMPAK Technology Inc. www.ampak.com.tw Proprietary &...
  • Page 11  Note to the VDDIO voltage level should be the same as GPIO voltage level of Host CPU. WiFi and Bluetooth software setup: Please follow up software guideline of Ampak official released. AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information...
  • Page 12 Full support for power savings modes (standard sniff, deep sleep modes) • ECI - enhanced coexistence support, ability to coordinate BT SCO transmissions around WLAN receives A simplified block diagram of the module is depicted in the figure below. AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 13 Agency certified pre-tested report with the adapter board. 3.2 Regulatory certifications The product delivery is a pre-tested module, without the module level certification. For module approval, the platform’s antennas are required for the certification. AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 14: General Specification

    Input supply Voltage -0.5 VDDIO Digital/Bluetooth/SDIO/ I/O Voltage -0.5 4.2.2 Recommended Operating Rating The module requires two power supplies: VBAT and VDDIO. Min. Typ. Max. Unit Operating Temperature deg.C VBAT VDDIO AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 15: Wifi Rf Specification

    - MCS=7 PER @ -70 dBm, typical Receive Sensitivity (11g) 6Mbps PER @ -89 dBm, typical @10% PER 9Mbps PER @ -88 dBm, typical - 12Mbps PER @ -86 dBm, typical AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 16 Small antennas with 0~2 dBi peak gain 5GHz Channel table Operating Channel Channel center Band (GHz) frequencies(MHz) Numbers 5180 5200 5.15GHz~5.25GHz 5220 5240 5260 5280 5.25GHz~5.35GHz 5300 5320 5.5GHz~5.7GHz 5500 5520 5540 5560 5580 5600 5620 AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 17: Bluetooth Specification

    GFSK (1Mbps) Sensitivity @ BER=0.01% -86 dBm for π/4-DQPSK (2Mbps) Sensitivity @ BER=0.01% -80 dBm for 8DPSK (3Mbps) GFSK (1Mbps):-20dBm π/4-DQPSK (2Mbps) :-20dBm Maximum Input Level 8DPSK (3Mbps) :-20dBm AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...

  • Page 18: Pin Assignments

    Floating (Don’t connected to ground) VBAT Main power voltage source input XTAL_IN Floating (Don’t connected to ground) XTAL_OUT Floating (Don’t connected to ground) WL_REG_ON Internal regulators power enable/disable WL_HOST_WAKE WLAN to wake-up HOST AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
  • Page 19 UART_TXD Bluetooth UART interface UART_RXD Bluetooth UART interface UART_CTS_N Bluetooth UART interface － Floating (Don’t connected to ground) － Floating (Don’t connected to ground) － Floating (Don’t connected to ground) AMPAK Technology Inc. www.ampak.com.tw Proprietary & Confidential Information Doc. NO:...
