M
ake sure to read the Important Precautions before using the product.
Keep the User's Guide(CD) in an accessible place for furture reference.
S
ee the label attached on the product and quote this information to your
dealer when you require service.
User's Guide
M1510S
M1710S
M1910S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M1510S and is the answer not in the manual?

Questions and answers

Related Manuals for LG M1510S

Summary of Contents for LG M1510S

  • Page 1 Important Precautions before using the product. Keep the User's Guide(CD) in an accessible place for furture reference. ee the label attached on the product and quote this information to your dealer when you require service. User’s Guide M1510S M1710S M1910S...

  • Page 2: Important Precautions

    Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential eletrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing.
  • Page 3 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.

  • Page 4: Unfolding The Stand Base

    Unfolding the stand base Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Unfolding the stand base Place the monitor with its front facing downward on a cushion or soft cloth.

  • Page 5: Connecting The Display

    Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Using the Computer Connect the signal cable. When attached, tighten the thumbscrews to secure the connection.
  • Page 6 If you want to adjust the monitor while in use, or wish to manually run this function once again, push the ‘AUTO/SELECT’ button on the front panel of the monitor.

  • Page 7: Control Panel Functions

    Screen Display(OSD). This will automatically adjust your display image to the ideal settings for the current screen resolution size (display mode). The best display mode is 15 inch monitor : 1024x768 17 inch monitor : 1280x1024 19 inch monitor : 1280x1024 A6 A6...

  • Page 8: Front Panel Controls And Functions

    Control Panel Functions Front Panel Controls Control VOLUME Buttons Buttons MENU Button MUTE Button Function Use these buttons to decrease or increase the volume level. Use these buttons to select or adjust functions in the On Screen Display. Lightview hot key This feature lets you easily select the best desired image condition optimized to the environment NIGHT...

  • Page 9: On Screen Display (Osd) Control Adjustment

    On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. The following section is an outline of the available adjustments and selections you can make using the OSD.
  • Page 10 On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu BRIGHTNESS PICTURE CONTRAST GAMMA PRESET COLOR GREEN BLUE HORIZONTAL POSITION VERTICAL CLOCK TRACKING PHASE VOLUME AUDIO TREBLE BASS BALANCE LANGUAGE SETUP...

  • Page 11: On Screen Display(Osd) Selection And Adjustment

    Menu. Press the MENU Button, then the main menu of the OSD appears. Menu Name Icons Sub-menus NOTE OSD (On Screen Display) menu languages on the monitor may differ from the manual.
  • Page 12 BRIGHTNESS To adjust the contrast of the screen. CONTRAST GAMMA Set your own gamma value. : -50/0/50 On the monitor, high gamma values display whitish images and low gamma values display high contrast images. Select the screen color. PRESET • 6500K: Slightly reddish white.
  • Page 13 POWER Use this function to set the power INDICATOR indicator on the front side of the monitor to ON or OFF. If you set OFF, it will go off. If you set ON at any time, the power indicator will automatically be turned on.

  • Page 14: Troubleshooting

    Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the display connected? Is the power indicator light on? Is the power on and the power indicator blue or green? Is the power indicator amber? Do you see an "OUT OF RANGE"...

  • Page 15: Display Image Is Incorrect

    Troubleshooting Display image is incorrect Display Position is incorrect. On the screen background, vertical bars or stripes are visible. Any horizontal noise appearing in any image or characters are not clearly portrayed. The screen color is mono or abnormal. The screen blinks. Press the AUTO/SELECT button to automatically adjust your display image to the ideal setting.

  • Page 16: Have You Installed The Display Driver

    Troubleshooting Have you installed the display driver? Have you installed the display driver? Do you see an "Unrecognized monitor, Plug&Play (VESA DDC) monitor found" message? Audio function No sound. Sound is too high pitched or too low piched. Sound level is too low.

  • Page 17: Specifications

    Specifications Display 15 inches (38.1cm) Flat Panel Active matrix-TFT LCD Anti-Glare coating 15 inches viewable 0.297 mm pixel pitch Sync Input Horizontal Freq. Vertical Freq. Input Form Video Input Signal Input Input Form Resolution Recommend Plug&Play DDC 2B Power On Mode Consumption Sleep Mode Off Mode...
  • Page 18 Specifications Display 17 inches (43.2cm) Flat Panel Active matrix-TFT LCD Anti-Glare coating 17 inches viewable 0.264 mm pixel pitch Horizontal Freq. Sync Input Vertical Freq. Input Form Video Input Signal Input Input Form Resolution Recommend Plug&Play DDC 2B On Mode Power Sleep Mode Consumption...
  • Page 19 Specifications Display 19 inches (48.18cm) Flat Panel Active matrix-TFT LCD Anti-Glare coating 19 inches viewable 0.294 mm pixel pitch Sync Input Horizontal Freq. Vertical Freq. Input Form Video Input Signal Input Input Form Resolution Recommend Plug&Play DDC 2B Power On Mode Sleep Mode Consumption Off Mode...

  • Page 20: Preset Modes (Resolution)

    Specifications Preset Modes (Resolution) 15 inch Display Modes (Resolution) 640 x 350 720 x 400 640 x 480 VESA 640 x 480 VESA 640 x 480 VESA 640 x 480 VESA 800 x 600 VESA 800 x 600 VESA 800 x 600 VESA 800 x 600 832 x 624...
  • Page 21 Specifications Preset Modes (Resolution) 19 inch Display Modes (Resolution) 640 x 350 720 x 400 640 x 480 VESA 640 x 480 VESA 800 x 600 VESA 800 x 600 832 x 624 VESA 1024 x 768 VESA 1024 x 768 1152 x 870 VESA 1152 x 900...
  • Page 22 How to Install the Rack wall mounting This monitor can be mounted on the VESA standrad wall mounting rack. Please the monitor on a piece of cloth or other soft surface with the front side facing downward and remove the rear cap.
  • Page 23 Digitally yours...
