Page 1: Table Of Contents
Table of Contents Safety Precautions Installation Accessories Name and Function of the Parts Connection Connecting to External Devices Connecting to your PC Watching VIDEO/DVD Watching HDTV (480p/720p/1080i) Watching DVD (480i) Watching TV Name of the Buttons in the screen Adjustment Unit Input OSD (On Screen Display) Screen Tracking Order Selection...
Page 2: Safety Precautions
10cm from the wall) - If you install the monitor too close to the wall, it may be deformed or fire can break out due to internal heat. Do not block the ventilation hole of the monitor by a tablecloth or curtain.
Page 3 - You may be electrocuted due to excess moisture. If you don’t intend to use the monitor for a long time, unplug the power cable from the monitor. - Covering dust can cause a fire, or insulation deterioration can cause electric leakage, electric shock or fire.
Page 4 Do not dispose the product-packing box. Use it when you move. Make the panel face forward and hold it with both hands to move. - If you drop the monitor, the damaged monitor can cause electric shock or fire. Contact with the service center for repair.
Page 5: Accessories
Please check the accessories in the product package. * The monitor and the accessories can be different from the figures shown here. Display P&D cable Colorific CD/ user's Manual/ Color Card Diskette/Cards Power Cord S-Video Cable Accessories Media Station Remote control /...
Page 6: Name And Function Of The Parts
Operational at the TV mode only Sound Mode Select Select the sound mode : MONO/STEREO/SAP Video Operation Button Applicable for LG products only Power On/Off Button Sleep Button When watching AV/DVD/HDTV/TV - The monitor will be automatically turned off after a certain period of time.
Page 7 Remote Control • Input Select Button If you press the button once, the following Input Signal Window will appear. Select the signal type you want using the button. DSUB ANALOG VIDEO DVD YPbPr PIP (Picture in Picture) Button The sub-screen moves to the next mode whenever you press this button. : SMALL ->...
Page 8 Name and Function of the Parts Swap Button You can swap the main screen and the sub-screen when the PIP/POP function is used.. When the signal of SOURCE 1 is supplied to the main-screen, the sub-screen receives the signal of SOURCE 2 only.
Page 9: Operating With The Remote Control
About 30° in each direction of the front of the remote sensor. Do not expose the sensor of remote control in the monitor to a strong light source such as direct sunlight or illumination. If so, may not be able to operate the monitor with the remote control.
Page 10: Connecting To External Devices
Power cut-off switch of the monitor Connect various cables and the power cord and turn on before using the monitor. Please turn the switch off if you intend not to use it for an extended period of time to reduce power consumption.
Page 11: Connecting To Your Pc
Connecting to your PC Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices are turned off. Connect the P&D (Plug and Display) cable. When attached, tighten the thumbscrews to secure the connection.
Page 12 Connecting to External Devices Connect the power cord into a proper power outlet that is easily accessible and close to the display. Media Station Rear Turn the media station power on. Media Station Rear Select an input signal. Press the SOURCE button on the remote control to select an input. When connecting D-SUB signal cable •...
Page 13 Connecting the Speakers Connect the audio cable.
Page 14: Watching Video/Dvd
Connecting to External Devices Watching VIDEO/DVD When connecting RCA cable Connect the each audio/video output jack of the VIDEO/DVD to the corresponding input port as shown on the Display (or Media station). Media Station Rear When connecting S-Video cable If you connect the S-Video input port to external equipment, you can have an improved definition image.
Page 15: Watching Hdtv (480P/720P/1080I)
Watching HDTV (480p/720p/1080i) Connect both HDTV cable (Y/Pb/Pr) and audio cable (Audio L/R) to the Display (or Media station) jack and the Set-top box jack. Media Station Rear White Blue Green Select an input signal. Press the SOURCE button on the remote control to select an input. •...
Page 16: Watching Dvd (480I)
Connecting to External Devices Watching DVD (480i) Take these connection steps if the DVD player has a RCA jack and the output is 480i only. Connect RCA jack. White Blue Green Select an input signal. Press the SOURCE button on the remote control to select an input. •...
Page 17: Watching Tv
Watching TV Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices are turned off. Connect the antenna. Media Station Rear Antenna (not included) Select an input signal. Press the SOURCE button on the remote control to select an input.
Page 18: Name Of The Buttons In The Screen Adjustment Unit
Selecting and Adjusting the Screen Name of the button in the Screen Adjustment Unit Control Source Selection: Use this button to select an input signal. • DSUB ANALOG: 15-pin D-sub analog signal DSUB ANALOG • DVI-D DIGITAL: DVI-D digital signal •...
Page 19 Control Use this button to enter or exit the On Screen MENU Button Display. • Bring up Contrast and Brightness adjustment. It is available to the PC signal inputs only. CH. - / CH. + • Use these buttons to go up and down the channel when the TV source is available.
Page 20: A19
Selecting and Adjusting the Screen OSD (On Screen Disply) Screen Tracking Order Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. The following section is an outline of the available adjustments and selections you can make using the OSD.
Page 21 The following table indicates all the On Screen Display control, adjustment, and setting menus. Using the computer Main menu Sub menu CONTRAST CONTRAST BRIGHTNESS BRIGHTNESS PRESET 9300K COLOR ADJUSTMENT 6500K R/G/B(User Color) HORIZONTAL IMAGE POSITION VERTICAL AUTO TRACKING CLOCK PHASE MUTE AUDIO VOLUME...
Page 22 Selecting and Adjusting the Screen Using the VIDEO/DVD/TV/HDTV Main menu Sub menu CHANNEL CHANNELSETUP ADD/DEL CH. AUTO CHANNEL SELECT FINE TUNE ADJUSTMENT CONTRAST BRIGHTNESS SHARPNESS COLOR TINT SOUND AUDIO VOLUME BBE EFFECT BASS TREBLE LANGUAGE SETUP IMAGE SIZE OSD POSITION TRANSPARENCY COLOR CAPTION...
Page 23: When Connected To Your Pc
You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. When Connected to your PC To adjust the brightness and contrast of the screen OSD Adjust To customize the color of the screen OSD Adjust...
Page 24 Selecting and Adjusting the Screen To improve the clarity and stability of the screen OSD Adjust AUTO CLOCK PHASE To adjust the audio function OSD Adjust MUTE VOLUME USER EFFECT To adjust uneven sound volumes across all channels or signals automatically to the most appropriate level.
Page 25 If you want to move the zooming point, use the H/V POSITION function in the sub-menu. However, if the monitor turns off when zooming in and out the screen, the monitor will be returned to original screen. Description To choose the language in which the control names are displayed.
Page 26 Selecting and Adjusting the Screen To adjust the PIP(Picture in Picture) of the screen OSD Adjust To adjust the PIP MODE submenu function, Press the OK --> button on the remote control After selecting ON in the PIP ON/OFF menu, the following menu items can be adjusted. To select an input signal for PIP.
Page 27 To adjust the POP(Picture out Picture) of the screen OSD Adjust To adjust the POP MODE submenu function, Press the OK --> button on the remote control After selecting ON in the POP ON/OFF menu, the following menu items can be adjusted. POP SOURCE To select an input signal for POP.
Page 28: When Watching Video/Dvd/Hdtv/Tv
Selecting and Adjusting the Screen When watching VIDEO/DVD/HDTV/TV To select TV channel settings and adjust the channel quality OSD Adjust CHANNEL CHANNEL SETUP CHANNEL ADD/DEL CH. ADD/DEL CH. AUTO CHANNEL CABLE SELECT AUTO CHANNEL SELECT FINE TUNE Description To change the channel. To add / delete the selected channels.
Page 29 To improve the clarity and stability of the screen OSD Adjust USER CONTRAST BRIGHTNESS SHARPNESS COLOR TINT To adjust the audio function OSD Adjust SOUND SOUND VOLUME USER EFFECT BASS TREBLE Description Select a picture mode of your choice among DYNAMIC, STANDARD, MILD and GAME, or select 'USER' and adjust the values of CONTRAST, BRIGHTNESS, SHARPNESS, COLOR and TINT.
Page 30 Selecting and Adjusting the Screen To customize the screen status for a user's operating environment OSD Adjust LANGUAGE IMAGE SIZE CAPTION PARENTAL FULL You can enjoy the picture (format of 4:3) or general TV in 16:9 mode. This picture format is 4 to 3 of general TV SPECTACLE This function provides different areas of the screen with a varied ratio, so that the ratio at the central area is close to 4:3 and near the edges it exceeds 16:9.
Page 31 To customize the screen status for a user's operating environment OSD Adjust To adjust the CATION MODE submenu function, Press the OK -- > CAPTION control PARENTAL CAPTION/TEXT Use the buttons to select caption mode. Text services give a wide variety of information on all kind of subjects(ex. captioned program lists, weather forecasts, stock exchange topics, news for hearing-impaired...) on up to half of the TV screen.
Page 32 Selecting and Adjusting the Screen V-CHIP rating and categories - Rating guidelines are provided by broadcast station. Most television programs and television movies can be blocked by TV rating and/or individual categories. Movies that have been shown at the theaters or direct-to-video movies use the Movies Rating System(MPAA) only. For movies previously shown in theaters.
Page 33: Setting A Password
setting a password PARENTAL PASSWORD LOCK ON/OFF You control access to the parental controls with a password. The default passworld is '7777'. You can change the password to any four-digit number. Open the OSD. -> Press the buttons to select the SETUP menu, then press SET to open the menu.
Page 34: Closed Captions
Selecting and Adjusting the Screen Closed Captions Closed captioning is a process which converts the audio portion of a television program into written words which then appear as subtitles on the television screen. Closed captions allow viewers to read the dialogue and narration of television programs. Using Closed Captions Captions are the subtitles of the dialogue and narration of television programs.
Page 35 To adjust the PIP(Picture in Picture) of the screen OSD Adjust After selecting ON in the PIP ON/OFF menu, the following menu items can be adjusted. To select an input signal for PIP. PIP SOURCE To adjust the size of the PIP screen: SMALL/LARGE PIP SIZE To adjust the position of PIP screen.
Page 36 Selecting and Adjusting the Screen To adjust the POP(Picture out Picture) of the screen OSD Adjust To adjust the POP MODE submenu function, Press the OK --> button on the remote control After selecting ON in the POP ON/OFF menu, the following menu items can be adjusted. POP SOURCE To select an input signal for POP.
Page 37: Troubleshooting
Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the display connected? Is the power indicator light When the power is on with the power indicator lighting blue, does the screen appear dark? (Display:blue, Media station:blue)
Page 38: Display Image Is Incorrect
Troubleshooting Display image is incorrect Display Position is incorrect. Display size is not correct in the PC mode. On the screen background, vertical bars or stripes are visible. Any horizontal noise appearing in any image or characters are not clearly portrayed. The screen color is mono or abnormal.
Page 39 Do you see an "Unrecognized monitor, Plug&Play (VESA DDC) monitor found" message? “IMAGE SIZE” function on OSD menu does not work. “IMAGE SIZE” function on OSD menu does not work? Check if the ZOOM value is set at ‘0’. In case the ZOOM value is set at ‘0’, the H/V position will not be...
Page 40: Audio Function
“CONTROLS UNLOCKED” will appear. It is not possible to configure this function with the remote control buttons. You can only do so from the monitor. Check the channel system and make sure you chose the correct channel system. Check the AUTO CHANNEL function to automatically search the available channels.
Page 41 “ZOOM” function on OSD menu does not work. Do you see a "NOT SUPPORTED" message on the screen? Check the current resolution on your PC. If the resolution is higher than 1280x768, the "Zoom" function will not be supported.
Page 42: Specifications
Specifications 23 inches (58.4cm) Flat Panel Active matrix-TFT LCD Display Anti-Glare coating 23 inches viewable 0.258mm pixel pitch Horizontal Freq. Sync Input Vertical Freq. Input Form Signal Input Video Input Input Form Resolution Recommend Plug&Play DDC 2B Display Power Input Input Media station Input...
Page 43 Temperature Humidity VESA wall mounting Connected to another object (stand type and wall- mounted type. This monitor accepts a VESA- compliant mounting interface pad.- optional) For further information, refer to the VESA Wall Mounting Instruction Guide. 58.75cm / 23.13 inches 44.65 cm / 17.58 inches...
Page 44 Specifications Display Modes (Resolution) PC mode Display Modes (Resolution) 640 x 350 640 x 480 VESA 640 x 480 720 x 400 VESA 800 x 600 VESA 800 x 600 832 x 624 VESA 1024 x 768 VESA 1024 x 768 VESA 1280 x 768 VESA...
Page 45: Signal Connector Pin Assignment
Signal Connector Pin Assignment DVI-D Connector Signal T. M. D. S. Data2- T. M. D. S. Data2+ T. M. D. S. Data2/4 Shield T. M. D. S. Data4- T. M. D. S. Data4+ DDC Clock DDC Data Analog Vertical Sync. T.
