  • Page 1 [i-Nova2 Series] [User Manual] Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 2: Table Of Contents

    5. TECHNICAL DATA I-NOVA2 (STANDARD / ZOOM / COMPACT / MOTOR) ......14 5.1. D ....................................14 IMENSIONS 5.1.1. i-Nova2 Standard model ............................14 5.1.2. i-Nova2-Zoom model ..............................15 5.1.3. i-Nova2 Compact model(Sony Sensor) ......................16 5.1.4. Nova2 Compact model (On-Semi Sensor) .....................17 Copyright ©2022_Ver.1 NOVITEC Co., Ltd.
  • Page 3 7.1.2.4. Bracket Tab ..............................38 7.1.2.5. i-Nova2 tab ..............................39 7.1.2.6. i-Nova2-Zoom ..............................41 7.1.2.7. i-Nova2-Motor ..............................42 7.1.2.8. General Button .............................43 7.2. N ................................43 OVITEC AMERA IEWER 7.2.1. Main UI ...................................43 7.2.2. Detailed Configuration ............................44 7.2.2.1. Menu .................................44 Copyright ©2022_Ver.1 NOVITEC Co., Ltd.
  • Page 4 9.3. V ....................................52 IDEO SETUP 9.3.1. Video ....................................52 9.3.2. RTSP View ..................................55 9.3.3. JPEG View ..................................56 9.4. N ....................................56 ETWORK SETUP 9.4.1. Ethernet ..................................56 9.5. V ................................57 ERSION INFORMATION 9.5.1. Firmware Version, Serial Number ........................57 Copyright ©2022_Ver.1 NOVITEC Co., Ltd.
  • Page 5 10.8.2. If the value set in the web page is not set properly ................66 11. APPENDIX ............................67 11.1. C ..................................67 AMERA SPECIFIC 11.1.1. i-Nova2 Standard Camera ...........................67 11.1.2. i-Nova2-Zoom Camera ............................68 11.1.3. i-Nova2 Compact Camera (Sony Sensor) ....................69 Copyright ©2022_Ver.1 NOVITEC Co., Ltd.
  • Page 6 11.2.2. i-Nova2 Standard (IMX392) / i-Nova2 Compact / i-Nova2-Motor ..........73 11.2.3. i-Nova2-Motor (AR0234CS) ..........................73 12. IMAGE TABLE OF CONTENTS ...................... 74 13. TABLE OF CONTENTS ........................76 14. REVISION HISTORY ........................76 15. CONTACT ............................77 Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 7: About This Document

    1. About this document 1.1. Purpose of the document An explanatory document for the i-Nova2 Series. For information necessary for programming, please refer to the software API document, which is a separate document, and the Example project provided as a sample.

  • Page 8: Important Information

    - Do not disassemble the front flange. - Clean the case with a soft, dry cloth. - Do not use the cleaners which contain benzene, thinner, or alcohol. Also do not use the spray cleaners. Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 9: Installation

    2.2.6. Using a C-Mount adaptor ring All i-Nova models are compatible with CS-mount lenses. However, if a C-Mount lens adaptor (extension ring) is attached, C-mount lenses can be used. <Image> 1. i-Nova mount (CS) and extension ring (CS to C) Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 10: Camera Introduction

    Sony (IMX392) 6-22mm i-Nova2-Motor iN2M-23SC-5M50 Sony (IMX392) 5-50mm i-Nova2-Motor iN2M-23OC-6M22 On-Semi (AR0234) 6-22mm i-Nova2-Motor iN2M-23OC-5M50 On-Semi (AR0234) 5-50mm <Table> 1. i-Nova2 simple specifications For detailed specifications for each camera and sensor, refer to Chapter 11. Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 11: About I-Nova2

    30FPS for JPEG, H.264 and at 15FPS for YUV420 output. 3.2. i-Nova2 Software Concept Using TCP/UDP communication, you can control the camera and acquire video frames using Novitec Protocol. There is no need to install a separate driver and there are no restrictions on the operating system and language being used as long as TCP/IP is available.

  • Page 12: Windows

    - i-Nova2 models are shipped with DHCP enabled in default, so it is not a static IP when first connected. - When you run a viewer program such as ClientCSharp, you can check the IP as shown below. Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 13: Image> 7. C# Client Viewer

    If the network does not have a DHCP server, the IP address range of the PC's network adapter must be changed to match the camera in order to connect to the camera. Network connections are described in detail in Chapter 10. Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 14: Technical Data I-Nova2 (Standard / Zoom / Compact / Motor)

    Standard is a basic model with no built-in lenses. You can set any C or C-Mount lenses and DC iris can be used. It also supports PoE (Power over Ethernet). Front View Back View Side View Top View <Image> 8. i-Nova2 Standard dimension view Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 15: I-Nova2-Zoom Model

    The Zoom, Focus and Iris are controllable remotely with our API. Front View Back View Side View Bottom View <Image> 9. i-Nova2-Zoom dimension view Power or I/O connectors are standard. Please be sure to check the model and the other one. Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 16: I-Nova2 Compact Model(Sony Sensor)

    Compact does not include an IR-Cut Filter, it is the smallest among i-Nova2 models and contains essential functions among the functions that users need. Front View Back View Side View Top View <Image> 10. i-Nova2 Compact (Sony Sensor) dimension view Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 17: Nova2 Compact Model (On-Semi Sensor)

    Compact does not include an IR-Cut Filter, it is the smallest among i-Nova2 models and contains essential functions among the functions that users need. Front View Back View Side View Top View <Image> 11. i-Nova2 Compact (On-Semi Sensor) dimension view Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 18: I-Nova2-Motor Model (Focal Length: 6 ~ 22 Mm)

    The i-Nova2-Motor model has a built-in motorized zoom lens, so there is no need to manually handling the lens when adjusting the zoom and focus. Front View Back View Side View Top View <Image> 12. i-Nova2-Motor (6~22) dimension view Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 19: I-Nova2-Motor Model (Focal Length: 5 ~ 50 Mm)

    This model has the same specification with the above model except the range of the zoom focal length is different and it has the different camera dimensions. Front View Back View Side View Top View <Image> 13. i-Nova2-Motor (5~50) dimension view Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 20: Connectors

    <Image> 15. Network connector (RJ45 type) 5.2.1.3. GPIO connector <Image> 16. 4Pin mini clamp socket connector GPIO internal circuit is as below, Strobe signal output port can be changed using Novitec protocol in i-Nova viewer. (Default is EXT-OUT1 port) Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 21: Dc Iris Connector

    [i-Nova2 Series] <Image> 17. i-Nova2 standard GPIO circuit 5.2.1.4. DC iris connector Common DC iris connector and is controlled by an OP AMP output. <Image> 18. DC iris connector Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 22: I-Nova2-Zoom, Compact, Motor Model

    5.2.2.3. GPIO connector Trigger IN, Strobe OUT (light), etc. on the back of the camera There is a GPIO port (5Pin Screw terminal block) for control. Out port can be controlled separately using Novitec protocol. <Image> 21. GPIO connector GPIO internal circuit is as shown below, Strobe signal output port can be changed using...

  • Page 23: Image> 22. Gpio Circuit

    [i-Nova2 Series] Novitec protocol. (Default is EXT-OUT1 TTL port) <Image> 22. GPIO circuit Port 2 and 3 are for TTL signal. If you are using a light system with TTL flash signal input, you can use these ports. To drive the signal with open collector, you need to use ports 4 and 5. In this case, to clearly indicate the HIGH signal and the LOW signal, a pull-up resistor must be used.

  • Page 24: Filter

    735nm band pass filter installed. It can also use other band- pass filters. Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 25: Using The Viewer

    [i-Nova2 Series] For other accessories, please contact sales@novitec.co.kr. 7. Using the Viewer 7.1. C Sharp Client Here we explain how to use our C# viewer. Please note that the C++/MFC viewer also follows the same UI configuration as C#. 7.1.1. Main Window ①...

  • Page 26: Connection Information

    Please refer to the API Manual for details on the difference between TCP/UDP. ◼ 7.1.1.4. Image Data Information <Image> 23. C # Viewer in SDK ④ Information about the video stream displayed on the screen is displayed. TCP Stream ◼ Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 27: Other Controls

    <Image> 26. Show Intensity and Setting You can see the color information on the clicked part in the video. ◼ The size of pixels to get the information, letter the color can be changed by pressing the setting ◆ button. Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 28: Image> 27. Focus Helper And Setting

    The red bar indicates how far away from the previous focus, it disappears after a certain amount of ◼ time. The area used for focus calculation can be changed by pressing the setting button. ◆ The focus is relative to the environment. For reference only. ◆ Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 29: Image> 28. Show Alc Area

    Resize the image to fit the viewer or display it at its original size. ◼ Save image ◼ Save the last acquired image. ◼ The storage location is saved in My Pictures/ i-Nova_(i-Nova IP address ) folder. ◼ Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 30: Camera Control Screen

    If the Gain value is set too high, the noise is also amplified, so an appropriate value should be used. ◼ Exposure time adjustment ◼ <Image> 28. Camera General control tab ② Exposure Time: You can adjust the exposure time. It can be set by changing the value used by the ◼ Copyright ©2022_Ver.1 NOVITEC Co., Ltd.
  • Page 31 It is the value before Gamma is applied, so it may be brighter than the actual brightness value. ALC Area ◼ <Image> 28. Camera General control tab ④ This specifies the ROI area to which LC is applied. Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 32: Code Tab

    JPEG bit rate. If you adjust the slider after checking, you can stabilize the FPS by setting the output bandwidth that matches the value and correcting the JPEG Quality value. When CBR is On, the JPEG Quality slider bar is disabled and not used. Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 33: Trigger / Flash Tab

    Free run mode ◼ Free running mode is a mode that continuously acquires images according to the frame rate set by the user. In this state, there is no need to separately control the startup. Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 34: Image> 32. Frame Grab On Free-Run

    - Flash Off, On, and Auto. Also, you can adjust the timing by adjusting the On/Off delay. Flash Off mode ◼ This mode turns off the lighting operation. Even when an image is acquired, the lighting does not ◆ work. Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 35: Image> 35. Strobe Signal - Flash Off

    Control Filter Switch: If checked, the camera turns off the filter in Night mode Control Color Mode: If checked, the camera turns into Monochrome mode in Night mode. information about Auto Flash, see Novitec You can check it at the technical Additional support cafe.

  • Page 36: Image> 38. Polarity Of Signal

    When a signal is received in One Shot Trigger Mode, the image is acquired 4 times. Image grab Grab signal <Image> 39. Image grab signal on image grab count 4 This setting cannot be used simultaneously with Bracket Mode. Minimum trigger pulse ◼ Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 37: Image> 40. Trigger Chattering

    Active and Inactive time vary depending on the environment, you can set it up according to your environment through testing. If it does not work as desired, check if the Trigger Polarity setting is correct. iN2-32SC and iN2Z-32SC-6Z210 Models does not support Minimum Trigger pulse settings. Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 38: Bracket Tab

    Bracket Mode, you can acquire up to 4 images with preset Exposure, Analog Gain, and Digital Gain values applied in order. Image acquisition works as follows. Image grab Grab signal <Image> 42. One shot trigger using bracket mode Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 39: I-Nova2 Tab

    Available for all models except i-Nova2 Compact Model. Monochrome ◼ Color / Mono image settings. Uncompressed YUV420 Video ◼ Change to transmit uncompressed video data in YUV420 format instead of JPEG. When using the video Copyright ©2022_Ver.1 NOVITEC Co., Ltd.
  • Page 40 Manual: Regardless of the current situation, you can adjust the white balance manually by setting the ◼ preset color temperature (C Temp) and additional R and B gains. (The same settings can be made on the web page as well.) Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 41: I-Nova2-Zoom

    ① - Focus / ② - Zoom Set : You can set the values of Zoom and Focus to the desired values. Get: You can check the current Zoom and Focus position. Zoom setting ◼ Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 42: I-Nova2-Motor

    Adjusts the zoom of the lens mounted on the Nova2 Motor. The degree of opening and closing of the iris is controlled through the number buttons in 18 steps, “1” means fully closed and “18” means fully open. Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 43: General Button

    Initializes the camera settings to the factory defaults, and all settings including the IP address are initialized. Restart camera ◼ Reboot the camera. 7.2. Novitec Camera Viewer For i-Nova2, it is recommended to use Novitec SDK 1.7.3 Version or later. 7.2.1. Main UI <Image> 47. Novitec Camera Viewer main UI Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 44: Detailed Configuration

    [i-Nova2 Series] 7.2.2. Detailed Configuration 7.2.2.1. Menu ① <Image> 47. Novitec Camera Viewer main UI in Name Description File Connect camera, screenshot, exit program Tools Overlay text, histogram, firmware update, viewer settings View Image display size, such as Zoom-In/Out, console window...

  • Page 45: Status Bar

    [i-Nova2 Series] 7.2.2.5. Status bar ⑤ <Image> 47. Novitec Camera Viewer main UI in Displays current camera status information such as FPS, Image information, Bitrate, Exposure, Gain, etc. 7.2.3. Camera connection ② <Image> 47. Novitec Camera Viewer main UI in Click the Connect button to display the camera selection window.

  • Page 46: Overlay

    7.2.4. Overlay Available when selecting Tools -> Overlay in the Toolbar. <Image> 49. Novitec Camera Viewer Overlay Overlay Capability A feature that allows you to draw lines, squares, and text above the screen. (The function is only visible in the viewer itself, not in the image output using other programs such as the RTSP viewer (such as the VLC Player) ①...

  • Page 47: Histogram

    7.2.6. Scripts The script function is a function that allows you to control the camera using Lua Script. The example code for the script exists in the Novitec Camera SDK\scripts folder within the Documents folder. <Image> 51. Novitec Camera Viewer Script Open folder Click Scripts –...

  • Page 48: Rtsp/Onvif Streaming

    [i-Nova2 Series] <Image> 52. Novitec Camera Viewer Script enable Click on the loaded script to activate the script. 8. RTSP/ONVIF Streaming If you use a program that can check RTSP Streaming such as VLC media player, you can check H.264 or MJPEG video.

  • Page 49: Onvif

    <Image> 54. ONVIF Login via ONVIF Device Manager As shown in the picture above, you must log in at the top to access the camera, and ONVIF only allows partial control of the camera. Functions provided by Novitec protocol can be controlled using Viewer and SDK.

  • Page 50: Web Page

    You can edit the login information required for web access. ID set by default: user, password: inova. You must change the password, as you cannot use the camera's functions until you change it. 9.1.3. Time Camera's SNTP server information and time zone information. Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 51: Update

    Idle. (When SET is selected, White Balance continues to change like in AUTO mode, but White Balance used at idle is the value at the time SET is set as described above.) Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 52: Image

    You can set the Color bar for testing or the camera title OSD. 9.3. Video setup 9.3.1. Video A page where you can set detailed settings for H.264 and MJPEG video transmitted by the camera. Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 53: Image> 58. I-Nova2 Browser Page (Video)

    Available when Bitrate Control OFF or VBR is set. - GOP: You can set the interval from H.264 to the next i-Frame after i-Frame is acquired. - FPS: You can set the FPS. Copyright ©2022_Ver.1 NOVITEC Co., Ltd.
  • Page 54 10% to 30%. When using CVBR, it is recommended to use a bitrate of 1 to 4 Mbps. - Bitrate: You can set the baud rate of Bitrate Control. There is. Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 55: Rtsp View

    /jpeg profile can be selected. After selecting the desired setting, click the Update button. <Image> 59. i-Nova2 browser page (RTSP View) RTSP View can only be executed in Internet Explorer. Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 56: Jpeg View

    <Image> 61. i-Nova2 browser page (Ethernet) To use static IP, you can set the IP after changing DHCP to UNUSE. Additions regarding static IP settings, For details, see Novitec technical support You can check it out at the cafe Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 57: Version Information

    <Image> 62. i-Nova2 browser page (Model, FW Ver. & Serial No.) 9.6. Still cut 9.6.1. JPEG image still cut http://” Camera I P”/still.jpg You can get Still Cut images from that camera by typing. <Image> 63. i-Nova2 still cut Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 58: Trouble Shooting

    The camera is set to receive IP from the DHCP server, but if the user sets to use static IP, IP will not be assigned automatically. In this case, the IP area fixed by the user instead. The IPv4 address of the Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 59: Multiple Lan Ports As Fixed

    10.1.4. If the IP address keeps changing Fixed IP address to i-Nova, you must access the i-Nova web page. Because it is in DHCP (dynamic allocation) mode at the time of shipment, The IP address may change depending on the situation. Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 60: Firewall Problems Such As Ip Search Not Working (Windows)

    PC and i -Nova are 1:1 connected, IP of i-Nova may not be searched due to firewall problem. The IP of the receiving i -Nova may not be retrieved. Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 61: Image> 67. Firewall Settings Confirmation Window

    Settings” in Control Panel - > All Control Panel Items -> Windows Defender (Firewall) and run it again. The rule name defaults to ClientCSharp for C# viewers and IpSDKSample for C++ (MFC) viewers. ② ① ③ <Image> 68. Reset the viewer-related settings of the firewall Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 62: Web Player Does Not Run

    VLC plug-ins cannot be used in browsers other than Internet Explorer, which is the default browser in Windows, RTSP videos cannot be viewed in Chrome, Whale, Edge, Firefox, etc. <image> 70. Browser player unavailable screen Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 63: Flash Light Does Not Work

    Line 2 (EXT-Out1) Strobe type LVTTL signal for lighting control is output. ◼ ◆ By default, it is synchronized with the Sensor exposure timing. Line 3 (GPIO) can output a control LVTTL signal that can be directly controlled by the user. ◼ <Image> 71. Circuit example Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 64: Lights Out Of Sync

    10.6. LED does not light up LED on the back of the camera does not light up, an RMA is received through the person in charge. See contact information on the last page. Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 65: Problem With Video Suddenly Not Appearing

    If you update the firmware while streaming, Streaming is paused to avoid interfering with firmware uploads. 10.8. Entered value is not set There can be several reasons for the entered value not being set. 10.8.1. If the value set in the viewer is not set properly Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 66: If The Value Is Not Set Properly Without Rebooting

    Enter key, the save setting is completed only by pressing the Save Setting button. 10.8.2. If the value set in the web page is not set properly Submit button after selecting an option, the setting value is not applied. Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 67: Appendix

    IR-cut filter (Controllable) / DC iris supported Image processing Motion detection, Gamma, White balance, Sharpness, Flip Protocol RTSP (MJPEG, H.264), Novitec Protocol (JPEG, YUV420), ONVIF Viewer and example code for Novitec Protocol (C#, C++, Python) Certificate <Table> 5. i-Nova2 detailed specifications Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 68: I-Nova2-Zoom Camera

    Image processing Motion detection, Gamma, Sharpness, White balance Protocol RTSP (MJPEG, H.264), Novitec Protocol (JPEG, YUV420), ONVIF Viewer and example code for Novitec Protocol (C#, C++, Python) Certificate KC, CE <Table> 6. i-Nova2-Zoom detailed specifications Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 69: I-Nova2 Compact Camera (Sony Sensor)

    Image processing Motion detection, Gamma, White balance, Sharpness, Flip Protocol RTSP (MJPEG, H.264), Novitec Protocol (JPEG), ONVIF Viewer and example code for Novitec Protocol (C#, C++, Python) Certificate <Table> 7. i-Nova2 Compact (Sony Sensor) detailed specifications Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 70: I-Nova2 Compact Camera (Sony Sensor)

    Image processing Motion detection, Gamma, White balance, Sharpness, Flip Protocol RTSP (MJPEG, H.264), Novitec Protocol (JPEG), ONVIF Viewer and example code for Novitec Protocol (C#, C++, Python) Certificate <Table> 8. i-Nova2 Compact (On-Semi Sensor) detailed specifications Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 71: I-Nova2-Motor Camera (Sony Sensor)

    Image processing Motion detection, Gamma, White balance, Sharpness, Flip Protocol RTSP (MJPEG, H.264), Novitec Protocol (JPEG), ONVIF Viewer and example code for Novitec Protocol (C#, C++, Python) Certificate KC, CE <Table> 9. i-Nova2-Motor (Sony Sensor) detailed specifications Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 72: I-Nova2-Motor Camera (On-Semi Sensor)

    Image processing Motion detection, Gamma, White balance, Sharpness, Flip Protocol RTSP (MJPEG, H.264), Novitec Protocol (JPEG), ONVIF Viewer and example code for Novitec Protocol (C#, C++, Python) Certificate KC, CE <Table> 10. i-Nova2-Motor (ON-Semi Sensor) detailed specifications Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 73: Sensor Detailed Properties

    Sensor Model ON-Semi AR0234CS Color Technology CMOS Optical format 1/2.6” Optical diagonal 6.8 mm Resolution 1920 x 1080 Pixel size 3.0 µm x 3.0 µm Shutter mode Global Shutter <Table> 13. Image sensor specifications (AR0234CS) Copyright ©2022_Ver.1 NOVITEC Co., Ltd.

  • Page 74: Image Table Of Contents

    <image> 34. Frame grab on pseudo trigger mode with H.264 ..................34 <Image> 35. Strobe signal - Flash Off............................. 35 <Image> 36. Strobe signal - Flash On ............................. 35 <Image> 37. Auto flash settings ................................ 35 Copyright ©2022_Ver.1 NOVITEC Co., Ltd.
  • Page 75 <Image> 49. Novitec Camera Viewer Overlay ..........................46 <Image> 50. Novitec Camera Viewer Histogram ........................47 <Image> 51. Novitec Camera Viewer Script Open folder ...................... 47 <Image> 52. Novitec Camera Viewer Script enable ......................... 48 <Image> 53. RTSP stream via VLC player ............................48 <Image>...

  • Page 76: Table Of Contents

    13. table of contents <Table> 1. i-Nova2 simple specifications ............................10 <Table> 2. Pull-up Resistor Table ............................... 24 <Table> 3. Novitec Camera Viewer Menu list ..........................44 <Table> 4. Novitec Camera Viewer tool bar ..........................44 <Table> 5. i-Nova2 detailed specifications ............................ 67 <Table>...

  • Page 77: Contact

    15. contact • Address : Baekje Gobun-ro 39 - gil, Songpa-gu, Seoul 39 Gil 30-18 • Tel : +82-70-7122-1000 • Fax : +82-70-7159-1315 • Website : http://www.novitec.co.kr •E-mail : Technical Support– support@novitec.co.kr Sales Inquiries – sales@novitec.co.kr Copyright ©2022_Ver.1 NOVITEC Co., Ltd.
