Systembuild Evolution 7531096COM Manual page 13

STEP 7
Quick
Assembly
Tip
LOCK
13
1 ×4 ×4
Proper orientation of CAM LOCK
7.1 Attach (A) to sub-assembly B/C/D/F from previous step with (1) as illustrated.
7.2 Cover cam lock hole with (13) as illustrated.
13
1
A
C
D
B
F
13
