Hard Wall Aluminium Sukkah - 3x3m
Assembly Instructions
SAFETY WARNING - Please read before use
1. Your Sukkahmart Sukkah and / or Rain Roof
is intended for use in a protected garden or
yard. Do not install your Sukkah in an open
area which is exposed to high winds which
may blow your Sukkah over.
2. If you are installing a Sukkah in an open area,
we recommend that you use the Super
Sukkah ONLY.
3. Wherever you place your Sukkah, it is vital
that you anchor your Sukkah down so that
it cannot lift off the ground. If wind lifts the
Sukkah off the ground, the Sukkah may
collapse upon landing. This is especially
important when using a Sukkah Roof.
4. You can weigh your Sukkah down, by
placing sandbags or heavy objects on the
bottom horizontal beam, or, for a Hard-
Walled Sukkah on the anchoring brackets
supplied. The Hard-Walled Sukkah also
comes with adaptors which can be used
to tie-down the Sukkah, or to fix the
Sukkah to your house.
1
Advertisement
Table of Contents
Related Manuals for SUKKAHMART Hard Wall Aluminium 3x3m
Summary of Contents for SUKKAHMART Hard Wall Aluminium 3x3m
- Page 1 Hard Wall Aluminium Sukkah - 3x3m Assembly Instructions SAFETY WARNING - Please read before use 1. Your Sukkahmart Sukkah and / or Rain Roof 3. Wherever you place your Sukkah, it is vital is intended for use in a protected garden or that you anchor your Sukkah down so that yard.
- Page 2 Hard Wall Aluminium Sukkah - 3x3 Assembly Instructions The basic Sukkah kit is 3x3 Meters with a door and a window. Any size larger than this will come with separate 'extension' kits of 2 x 1 running meters or 2 x 2 running meters. VERY IMPORTANT The beams and panels are different sizes and it is crucial that you use the correct beams and panels in the correct places.
- Page 3 Sukkah Elements Door (do NOT construct these yet) Door beams and panels – (put these aside for your door) Hinge Beams (2 beams joined together with hinges) - 1 Handle Beam (beam with handle and latch on) - 1 Hook Beam (beam with hook for latch on) - 1 Door Crossbeams (white sticker) - 3 3 Meter Wall...
- Page 4 How the beams join together Inset the lock into the slot Ensure they are flush against each other Use the supplied tool to turn the bolt The lock will lock the beam in place. To build a 3x3m Sukkah Step 1 - Start with the bottom and upright beams first. NB - Ensure that both sides of the hinges are facing outwards...
- Page 5 Step 2 – Insert the first row of panels into the slots Pic 1 – Panel going in On a 2 meter wall, use a 2-slot upright beam between the two panels NB: Panels are not exactly square. Make sure you insert the panels long side up.
- Page 6 Step 3 – Place a crossbeam on top of the panel, insert a second panel on top of the crossbeam and close the top off with a 1 or 2 meter crossbeam. Leave a gap for your window. Step 4 – To complete the door, place the white panel with the green sticker at the bottom, a 1 meter crossbeam on top of it, followed by the white panel with the red sticker and another 1 meter crossbeam.
- Page 7 Step 6 – Place top supports ontop of your Sukkah for added strength (Pink Stickers). 3m x 3m ARIAL VIEW Joiner (4 x 4 cm)
- Page 8 Step 7 – Use remaining supports to anchor your sukkah. Use Rings to fix to wall or tie down Upright Pole Sandbag over a foot Foot Place a sandbag or heavy item ontop of foot...
