Summary of Contents for Motion SMD 4.0 Series
- Page 1 SMD4MAN.WRI 06-98 SMD 4.0 STEP MOTION DRIVE SYSTEM TST 4.0 STEP MOTOR POWER FEED DSD 4.0 DIGITAL SERVO SYSTEM OPERATION AND INSTALLATION MANUAL SECTION 1: SMD DRIVER CASE SECTION 2: MS DRIVER CARD FOR QUICK REFERENCE - REFER TO THE APPENDIX SECTIONS...
- Page 2 General Description. The SMD, TST, and DSD 4.0 series units are identical to the 2.0 series with the following exceptions: The units support 4 amps of motor current; factory pre-set is 4 amps. The units may require additional cooling or mounting of the system to a larger metal surface if bottom lid or motor is too hot to touch (75 C).
