Summary of Contents for Clifford 22CX
-
Page 3: Limited Consumer Warranty
Limited Consumer Warranty For a period of one calendar year from the date of purchase of this auto-security device, Directed Electronics, Inc. promises to the ORIGINAL PURCHASER to repair or replace (with a comparable reconditioned model), free of cost, any electronic control module which proves to be defective in workmanship or material under normal use, SO LONG AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A PROFESSIONAL AUTO INSTALLER, AND REMAINS IN THE CAR IN WHICH THE SYSTEM WAS ORIGINALLY... - Page 4 TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WARRANTIES ARE EXCLUD- ED BY THE MANUFACTURER AND EACH ENTITY PARTICIPATING IN THE STREAM OF COM- MERCE THEREWITH. THIS EXCLUSION INCLUDES BUT IS NOT LIMITED TO THE EXCLU- SION OF ANY AND ALL WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WAR- RANTY OF FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL WARRANTY OF NON-INFRINGEMENT OF PATENTS, IN THE UNITED STATES OF AMERICA AND/OR ABROAD.
- Page 5 2004 Directed Electronics, Inc. ©...
-
Page 6: Table Of Contents
Table of Contents Limited Lifetime Consumer Warranty What Is Included ..........3 Important Information . - Page 7 2004 Directed Electronics, Inc. ©...
-
Page 8: What Is Included
What is Included ■ A control module ■ Two 3-button remote transmitters ■ A zone 2 impact sensor on-board the control module ■ A high-powered siren ■ A fault-proof starter interrupt on-board the control module ■ An LED Blue system status indicator ■... -
Page 9: Your Warranty
when using the remote transmitter. To access the battery for replacement, remove the rear cover of the remote with a small, flat-blade screwdriver. Your Warranty Your warranty card must be returned and the barcode serial num- ber must not be removed. If the warranty card is not returned, no warranty will be honored on your unit. -
Page 10: Transmitter Functions
Transmitter Functions This system is programmable, making it possible to assign any trans- mitter button to any specific receiver function. The remote initially comes programmed with Standard Configuration, but may also be customized by an authorized dealer. The buttons in all of the instruc- tions in this manual correspond to a Standard Configuration remote. -
Page 11: Using Your System
Using Your System The transmitter buttons indicated in this manual correspond to a standard configuration transmitter, unless otherwise specified. Arming You can arm the security system by pressing When the system arms, you will hear a short siren sound (chirp) and the parking lights will flash once. -
Page 12: Disarming
time a sensor is triggered during the Passive Arming countdown, the countdown starts over. Arming your security system protects your vehicle to the following degrees: ■ Light impacts trigger a warn-away response, causing the siren to chirp and the parking lights to flash for a few seconds. ■... -
Page 13: Disarming Without A Transmitter
disarming indicates Tamper Alert, which is described in the Diagnostics section of this guide. Disarming Without a Transmitter If your transmitter is lost or damaged, you can manually disarm your vehicle security system. To disarm the system without a trans- mitter, you must have the vehicle's ignition key and know where the Valet switch is located. -
Page 14: Remote-Controlled Silent Arm/Disarm
Remote-Controlled Silent Arm/Disarm Use remote-controlled silent arm/disarm to temporarily turn off the arm or disarm chirps by briefly pressing arming or disarming. The confirmation chirp(s) will then be elimi- nated for that one operation only. To permanently turn off the arm and disarm chirps, contact your installation dealer. -
Page 15: Remote-Controlled Valet
entering Valet Mode and will turn off if you are exiting Valet Mode. Remote-Controlled Valet You can also enter or exit Valet Mode by using the remote transmitter: 1. Open any vehicle door. 2. Press 3. Press 4. Press again. The LED system status indicator will light solidly if you have entered Valet Mode and will turn off if you have exited Valet Mode. -
Page 16: Diagnostics
over. This ensures that a sensor that is continually being triggered will remain bypassed. The vehicle doors are protected differently by NPC rity system is triggered by an open door for three, full 30-second cycles (one and one half minutes), the system will bypass the doors until the trigger ceases. -
Page 17: Disarming Diagnostics
system ignores the input that was active when the system was armed, until that input ceases. Three seconds after that input ceases, the system will resume normal monitoring. For example, if your vehicle has an interior light exit delay and you arm the sys- tem before the light turns off, you may hear a Bypass Notification chirp. -
Page 18: Stealth Coding Technology
ments are listed in the following table, along with spaces to write in any optional sensors or switches that you have had installed. ZONE (Number of DESCRIPTION LED Flashes) Instant trigger for optional sensor, hood or trunk pins A heavier impact detected by the on-board impact sensor Door switch trigger Ignition trigger... -
Page 19: High Frequency
several times within range of the vehicle. The system will auto- matically resynchronize and the transmitter will respond normally. High Frequency Your system transmits and receives at 434 MHz. This provides a cleaner spectrum with less interference and a more stable signal. Enjoy a phenomenal increase in range, even in areas with high radio interference. -
Page 20: Security & Convenience Expansions
grammed on or off. ■ Ignition controlled door lock feature, on or off. With this fea- ture on, the doors will lock three seconds after the ignition key is turned on, and unlock when the ignition is turned off. The system also prevents the doors from locking when the ignition is turned on while any vehicle door is open. - Page 21 sequence. Power Locks: This system offers lock outputs that can control some manufacturers' power door lock systems. For other systems, additional parts may be required. Power Trunk Release: The output of the system can operate a factory power release for the vehicle's trunk or hatch. An optional relay is required.
-
Page 22: Installation Options
Installation Options Installation options may require additional parts or labor. Please consult your dealer. Interior Light Illumination: The interior domelight can be con- figured to illuminate for 30 seconds after the alarm is disarmed. If the system is rearmed during that 30-second period, the interior light illumination will terminate until the alarm is disarmed again. - Page 23 Input: Any physical connection to the security system. An input can be provided through a sensor, pinswitch or by existing systems in the vehicle, such as ignition or courtesy lights. LED: A red light mounted inside the vehicle, at a location deter- mined by the installer.
-
Page 24: Quick Reference Guide (Removable)
QUICK REFERENCE GUIDE To arm using your remote: ■ Press on your transmitter for one second. When the system arms, you will hear a short siren sound, or chirp, and see the parking lights flash once. If the vehicle's power door locks are controlled by the sys- tem, the doors will lock. - Page 25 The company behind this system is Directed Electronics, Inc. Since its inception, DEI ® has had one purpose, to provide consumers with the finest vehicle security and car stereo products and accessories available. The recipient of nearly 100 patents and Innovations Awards in the field of advanced electronic technology, DEI is ISO 9001 registered.
