- Page 1 User Manual | P1 ECL202/ECL202e www.ibspe.com...
-
Page 2: Table Of Contents
ESETTING FFSET ETPOINT UTTON ANALOGUE OUTPUT SIGNAL NTERPRETING THE UTPUT OLTAGE HANGE IN GAP CALCULATION REMOTE OFFSET AND SETPOINT SETPOINT SWITCH OUTPUT BANDWIDTH SELECTION (ECL202 ONLY) MAXIMISING PERFORMANCE 10.1 E XTENSION ABLES 10.2 P ROBE OUNTING 10.3 U NGROUNDED ARGETS 10.4 M... -
Page 3: Approvals And Safety Considerations
Use of the equipment in any other manner may impair the safety and EMI protections of the equipment. Helpful Technical Support Documents Online The IBS Precision Engineering’s website has a large selection of technical documents (TechNotes and Application Notes) in the Technical Library. These documents provide detailed descriptions of the operation and use of the products of IBS Precision Engineering. -
Page 4: Ecl202 And Ecl202E
2022-06-13 ECL202 and ECL202e The ECL202e is identical to the ECL202 except that the ECL202e resolution is never better than 0.2 μm. For this reason, the ECL202e does not require an export license. This manual will only refer to the ECL202, but all instructions apply to the ECL202e except where noted. -
Page 5: Front Panel Controls And Indicators
Hold the Offset button for four seconds to remove any output DC shift. Setpoint Button The ECL202 provides an adjustable setpoint at which a switched output activates. The output switch closes when the output voltage is more positive (larger gap) than the user-adjusted setpoint. Pressing the Setpoint button will set the threshold voltage to the current output voltage. -
Page 6: Analogue Output Signal
30VAC/60VDC. The output is a solid state switch closure and can conduct AC or Bandwidth selection (ECL202 only) A jumper wire on the bandwidth connector selects sensor bandwidth. To select a bandwidth, connect the desired bandwidth terminal to the Bandwidth Select contact. -
Page 7: Maximising Performance
CAUTION: It is critical that each ECL202 be connected to the probe indicated on the “USE PROBE S/N” label on the front of each ECL202. -
Page 8: Connecting To The Ecl202
Power Ground Output Signal Ground Reference for output signal voltage Output Signal Output signal voltage 0-10 VDC Bottom-Rear Connector: Bandwidth (ECL202 Only) Bandwidth Selected Common point for bandwidth selection jumper 100Hz, 1kHz, 10kHz Bandwidth selection, connected to None = 15 kHz Bandwidth Selected www.ibspe.com... -
Page 9: Specifications
¹Actual values depend on probe and range and are listed on the calibration certificate shipped with the product. Contact Lion Precision for replacement certificates. ²In High EMI environments (10 V/m), output noise levels may rise to 30 mV causing resolution to be reduced to 0.3%. IBS Precision Engineering • Eindhoven • NL • +31 40 290 1270... - Page 10 User Manual | P10 Last update: 2022-06-13 Parameter Specification Notes U3 Probe ±0.04% F.S./°C U5 Probe ±0.1% F.S./°C U8 Probe U12 Probe Nonferrous U18 Probe ±0.04% F.S./°C U25 Probe U38 Probe Temperature U50 Probe Over 15°C to 50°C Coefficient U3 Probe ±0.08% F.S./°C Temperature range Driver...
-
Page 11: Mechanical Detail
User Manual | P11 Last update: 2022-06-13 Mechanical detail IBS Precision Engineering • Eindhoven • NL • +31 40 290 1270...
