Mart BR-11 User Manual

V. Repair and maintenance

All repairs of the BISTABLE RELAY BR‑ 11
any maintenance.
The manufacturer guarantees the correct operation of the
36 months from the date of sale. The warranty is extended by the time of repair. Warranty repairs are
performed by the manufacturer free of charge after the AUTOMAT is delivered to the manufacturer. Improper
use of the device or independent modifications to it will void the warranty.
www.mart-electronics.eu
RoHS
The BISTABLE RELAY BR‑ 11
- Directive LVD 2014/35/EU - Low Voltage Directive of 26 February 2014
- Directive EMC 2014/30/EU - Eletromagnetic Compatibility Directive of 26 February 2014
In order to protect the environment, do not throw away used electrical appliances
and electronics together with municipal waste. Used equipment should be delivered to
collection points for recycling free of charge. Any information on this can be obtained
at sellers, distributors, manufacturer or on the Internet. The product's packaging is made of
ecological materials. The PVC packaging tape will be used while stocks last.
are performed by the manufacturer. The device does not require

VI. Warranty Card

BISTABLE RELAY BR‑ 11 . The warranty period is
Made in Europe
meets the requirements of the European Union Directives
BISTABLE RELAY
RoHS
BISTABLE RELAY BR-11 performs two functions, the activation method of which can be selected:
> function I - triggered by an impulse in the range of 40 ms ... 2 s - switching the receiver on or off with the
impulse switch. Each subsequent switching on causes a change in the state of the executive relay. If the
receiver was turned on, the momentary switching on of the impulse switch turns the receiver off and vice versa.
> function II - triggered by an impulse longer than 2 s - switching the receiver on for a specified time set by the
potentiometer. After this time, the receiver will be automatically turned off. The adjustment range of the switch-
off delay time is adjustable in the range: 1 s ... 60 min
>> the method of starting a given function can be changed with the TEST - MODE button:
> starting function I - with a pulse longer than 2 s
> starting function II - impulse within the range of 40 ms ... 2 s
> the switch-off delay time can be set in one of three time periods:
> 1 s ... 60 s
> 1 s ... 6 min
> 1 s ... 60 min
Setting to 0 in each range means 1s.
BISTABLE RELAY BR-11 enables switching the receiver on and off with many parallel connected impulse
switches, which means that the receiver can be turned on or off in any place. BISTABLE RELAY BR-11 can
work with an unlimited number of impulse switches without backlight and a limited number of switches with
backlight, connected in parallel.
BISTABLE RELAY BR-11 can be used in "intelligent" electrical installations.

II. Properties of the BR-11 BISTABLE RELAY

>> short response time to pressing < 40 ms
>> short standby time for the next press > 200 ms
>> switch-off delay time adjustable in the following ranges: 60 s, 6 min, 60 min
>> high switching power - 16 A (4000 W), 250 VAC
>> high inrush current - resistance to 100 A surge current
>> freedom of connections:
> executive relay contacts (one normally open contact - NO, one normally closed contact - NC) galvanically
separated, which allows connections in various configurations
>> indication light (LED):
> Green LED - indication of 230 VAC supply voltage on N-L terminals
> Red LED - signalling that contacts 1-2 are closed, information during programming
> Blue LED - signalling that contacts 2-3 are closed, information during programming
>> mounting on 35 mm DIN rail.
>> TEST - MODE button, for selecting the appropriate operation option of the BISTABLE RELAY BR-11.
The BISTABLE RELAY BR-11 uses a specialized OMRON G2RL-1-E-HR relay, designed to switch various
types of lighting lamps. The special design of the relay enables effective switching of lamps with an inrush
current up to 100 A.
MADE IN EUROPE
BR-11
3-YEAR
WARRANTY
User manual

I. Purpose
