HM/E01
Specifications and Features
Operating frequencies: (Frequency usage varies by country)
Block 470 470.100 - 495.600
Block 19 486.400 - 511.900
Block 20 512.000 - 537.500
Block 21 537.600 - 563.100
Block 22 563.200 - 588.700
Block 23 588.800 - 614.300
Block 24 614.400 - 639.900
Block 25 640.000 - 665.500
Block 26 665.600 - 691.100
Block 27 691.200 - 716.700
Block 28 716.800 - 742.300
Block 29 742.400 - 767.900
Block 30 768.000 - 793.500
Block 31 793.600 - 819.100
Block 32 819.200 - 844-700
Block 33 844.800 - 861-900
Block 606 606.000 - 631.500
(100 kHz Steps)
Frequency range:
Channel Spacing:
Frequency selection:
RF Power output:
Compatibility Modes
Pilot tone:
Frequency stability:
Deviation:
Spurious radiation:
Equivalent input noise:
Input level:
If set for dynamic mic:
If set for electret lavaliere mic:
Line level input:
Input impedance:
Input limiter:
Gain control range:
Modulation indicators:
Controls:
Low frequency roll-off:
14
256 frequencies in 100 kHz steps
for one 25.5 MHz wide block
100 kHz
Control panel mounted membrane
switches
50 mW (nominal)
Digital Hybrid Wireless
and IFB
™
25 to 32 kHz; 3 kHz deviation
(in Digital Hybrid mode)
± 0.002%
± 50 kHz max. (in 400 Series Mode)
60 dB below carrier
–125 dBV, A-weighted
0.5 mV to 50 mV before limiting.
Greater than 1 V with limiting.
1.7 uA to 170 uA before limiting.
Greater than 5000 uA (5 mA) with
limiting.
17 mV to 1.7 V before limiting.
Greater than 50 V with limiting.
300 Ohms
Soft limiter, 30 dB range
45 dB (Firmware rev. 1.3)
55 dB (Firmware rev. 1.5)
Dual bicolor LEDs indicate modulation
of –20, -10, 0, +10 dB referenced to
full modulation.
Control panel with LCD and four
membrane switches.
Selectable; -3dB at 35, 50 or 70 Hz.
Audio Frequency Response:
Signal to Noise Ratio (dB):
(overall system, 400 Series mode)
SmartNR
No Limiting
w/Limiting
OFF
103.5
108.0
NORMAL
107.0
111.5
FULL
108.5
113.0
Total Harmonic Distortion:
Audio Input Jack:
Phantom Power:
Antenna:
Batteries:
Battery Life:
Weight:
Overall Dimensions:
Emission Designator:
Specifications subject to change without notice.
35 Hz to 20 kHz, +/-1 dB (The low
frequency roll-off is adjustable)
The dual envelope "soft"
limiter provides exceptionally
good handling of transients
using variable attack and release
time constants. The limiter reduces
30 dB of dynamic range into 4.5 dB,
which reduces the measured figure
for SNR without limiting by 4.5 dB.
0.2% typical (400 Series mode)
3-pin Female XLR
5V @ 18 mA max., 15V @ 15 mA
max. and 48 V @ 4 mA max., plus
"OFF"
Housing and attached microphone
form the antenna
Two 1.5 Volt AA lithium or
rechargeable NiMH recommended
4.5 hours (alkaline); 12 hours
(lithium), 8 hours with 2500mAh NiMH
6.7 oz (190 grams) without batteries
4.25x1.62x1.38 inches
180KF3E
LECTROSONICS, INC.
