Download
Share
Print this page
Fineco Electric EM535 Series User Manual
  1. Manuals
  2. Brands
  3. Fineco Electric Manuals
  4. Measuring Instruments
  5. EM535 Series
  6. User manual

Fineco Electric EM535 Series User Manual

Three phase active energy meter
Hide thumbs

Advertisement

Quick Links

Download this manual
User Manual
Revision 2.001
English
EM535 series
Three phase active energy meter
Shanghai fangqiu electric CO.,LTD.
Shanghai fangqiu electric CO.,LTD.
User Manual EM535 series
Document code: Fineco535-1-1.1 Revision2.001
Benefits and Main Features
● Three phase metering , Standard DIN rail Format (DIN43880)
● IEC62053-21 Class 1.0
● LCD display, 6 integer 1 decimal
● Large clear backlight display
● Internal transformer
● Direct metering up to 65A,transformer metering 1.5(6)A
● 27 CT rate can be selected
● Optional single-phase model
● Smart communication port, RS485&M-bus can selected
● Can be set through front panel or via communications
● Isolate pulse output (DIN43864)
● Memory back-up (EEprom)
● 5 DIN modules
● CE approval
Email:
antsmw@163.com

Advertisement

loading

Related Manuals for Fineco Electric EM535 Series

Summary of Contents for Fineco Electric EM535 Series

  • Page 1 User Manual EM535 series Document code: Fineco535-1-1.1 Revision2.001 User Manual Revision 2.001 English Benefits and Main Features EM535 series ● Three phase metering , Standard DIN rail Format (DIN43880) Three phase active energy meter ● IEC62053-21 Class 1.0 ● LCD display, 6 integer 1 decimal ●...

  • Page 2: Safety Notice

    Document code: Fineco535-1-1.1 Revision2.001 Index: 1. Safety notice The smart energy meter of EM535 series does not require special mechanical or electrical Safety notice tools for its installation. Mounting position (with any angle of tilt) has no effect on the Content of delivery measurement functions of the meter.

  • Page 3: Technical Description

    3. Technical description International standard EN50470-3 &IEC62053-21 3.1 Survey of types/Ordering numbers Accuracy class CI.1 The EM535 series is labeled as follows: Protection against penetration of dust and water IP51 EM535 . 3 . Ⅱ Insulating encased meter protective class...
  • Page 4 User Manual EM535 series Document code: Fineco535-1-1.1 Revision2.001 Direct connected meters Transformer connected meter Dimensions and sealing points Power consumption of < 0.01 < 0.01 current circuits(VA) Power consumption of < 1.3W < 1.3W voltage circuits(W) General data Frequency (Hz)
  • Page 5 User Manual EM535 series Document code: Fineco535-1-1.1 Revision2.001 Neutral Wiring diagrams test pulse output contact (23－,20+) Note: the following types of wiring diagrams show the energy meter, 20 &23 include terminals for pulse output the communication interface 5.1.2 535.3.2 diagram RS-485.However,depending on the ordering number of the energy meter only some...
  • Page 6 User Manual EM535 series Document code: Fineco535-1-1.1 Revision2.001 5.1.3 535.3.3 diagram L1 in & out L1 in & out L2 in & out L2 in & out L3 in & out L3 in & out 2/5/8/10 UL1,UL2,UL3,N Neutral test pulse output contact(23－,20+) 20 &23...
  • Page 7 User Manual EM535 series Document code: Fineco535-1-1.1 Revision2.001 5.2.2 535.4.2 diagram 5.2.3 535.4.3 diagram L1 in & out L2 in & out L1 in & out L3 in & out L2 in & out 2/5/8/10 UL1,UL2,UL3,N L3 in & out test pulse output contact(23－,20+)
  • Page 8 User Manual EM535 series Document code: Fineco535-1-1.1 Revision2.001 5.3 single phase diagram 5.3.1 Direct connected meters Meter reading the view angle Operator-meter should be up to 45 5.3.2 Transformer connected meter Meter operation Consumption indication On the EM535’S front panel, there are five LED, respectively, for the Active energy pulse light, current reverse ,Phase L1/L2/L3 .
  • Page 9 User Manual EM535 series Document code: Fineco535-1-1.1 Revision2.001 nameplate of the meter. 7.2 Reading the meter The smart energy meter is equipped with 6+1 LCD display, which is used as recording consumption and can’t be reset to zero. The number system is based on units of 10. And CT rate: unit is kWh.
  • Page 10 User Manual EM535 series Document code: Fineco535-1-1.1 Revision2.001 com，RS485 or M-bus. RS485 output M- bus output Protocol Modbus RTU EN13757-3,EN1434-3 Data format 8 data bit,Even,1 stop bit 8 data bit,Even,1 stop bit Baud rate 1200(option),2400,4800,9600 300,2400(option),9600 Address range 1-256 User settable 1-250 User settable 7.3 Pulse output...
  • Page 11 User Manual EM535 series Document code: Fineco535-1-1.1 Revision2.001 Please remember well the Password, you can only reset the Password to default Type 535.3.2 &535.4.2 series meters , default baud rate will be 1200bps (8888) by opening the meter and short connect the “CLEAR” on PCB board.
  • Page 12 User Manual EM535 series Document code: Fineco535-1-1.1 Revision2.001 2,after the CT ratio setup, the energy consumption display will be reset to 0.  Password setting： The meter will display the current password after enter the password setup interface, press the “SET” to change the password. Use “page dow” and “page up”...
