- Page 1 SX-PCEAC2 Installation Instructions for NVIDIA’s Jetson Nano Application Note...
- Page 2 SX-PCEAC2 Hardware Installation Instructions for NVIDIA Jetson Nano Table of Contents Contents Introduction ............................3 What you will need? ..........................3 Setup the Hardware ..........................3 About Silex Technology America, Inc....................6 Revision History ............................7...
- Page 3 SX-PCEAC2 Hardware Installation Instructions for NVIDIA Jetson Nano Introduction The purpose of this document is to provide instructions to install the silex’s SX- PCEAC2 Wireless LAN Module, the SX-PCEAC2-M2, into Jetson Nano-EVK (from a hardware installation perspective). What you will need? •...
- Page 4 SX-PCEAC2 Hardware Installation Instructions for NVIDIA Jetson Nano Insert the SX-PCEAC2-M2 module in the M.2 slot shown below. You can screw the SX-PCEAC2- M2 into the platform for secure hold. You can put the heat sink back after the module installation.
- Page 5 SX-PCEAC2 Hardware Installation Instructions for NVIDIA Jetson Nano 3. To add the SD card that has the software image needed for evaluation, please inset it into the SD card slot at the back of the Jetson Nano board. See below.
- Page 6 SX-PCEAC2 Hardware Installation Instructions for NVIDIA Jetson Nano About Silex Technology America, Inc. Silex Technology builds on more than 40 years of hardware and software connectivity know-how and IP, custom design development experience, and in-house manufacturing capabilities, bringing value to customers with a foundation of technical expertise. With...
- Page 7 SX-PCEAC2 Hardware Installation Instructions for NVIDIA Jetson Nano Revision History Revision Date Notes...
