- Page 1 MODEL 99810-1139 BORDEAUX & GRAPHITE : WWW.BESTAR.CA : 1-888-8BESTAR (1 888 823-7827) 99810-1169 CHOCOLATE : WWW.BESTAR.CA : 1-888-8BESTAR (1 888 823-7827) 99810-1176 COGNAC CHERRY : WWW.BESTAR.CA : 1-888-8BESTAR (1 888 823-7827) LEFT ASSEMBLY INSTRUCTIONS RIGHT ASSEMBLY INSTRUCTIONS INSTRUCTIONS D’ASSEMBLAGE DROIT...
- Page 2 Thank you for choosing a BESTAR product. Your total satisfaction is our #1 priority. Customer Service and warranty information do not call to the place of purchase Please call our customer service department for immediate assistance using the following toll free number: www.bestar.ca...
- Page 3 PARTS PIEZAS CODE / CÓDIGO QTY / QTÉ / CANT. CODE / CÓDIGO QTY / QTÉ / CANT. CODE / CÓDIGO QTY / QTÉ / CANT. CODE / CÓDIGO QTY / QTÉ / CANT. Moldings molduras HARDWARES QUINCALLAS CODE / CÓDIGO QTY / QTÉ...
-
Page 4: Important Notice
IMPORTANT NOTICE / NOTA IMPORTANTE Asegúrese de completar correctamente la etiqueta. Duly complete the self-adhesive sticker. / MODEL 00000-0000 COLOR : : COLOUR WWW.BESTAR.CA : 1-888-8BESTAR (1 888 823-7827) To better serve you! LEFT ASSEMBLY INSTRUCTIONS Model Production Number RIGHT ASSEMBLY INSTRUCTIONS... - Page 5 Important/Importante 2 possibilities / 2 posibilidades If you prefer the right assembly, refer to pages 6 to 11. 99400 or o 99610 Si prefiere el ensamble derecho, not included vea las páginas 6 a 11. no se incluye If you prefer the left assembly, refer to pages 12 to 17.
-
Page 6: Hardware Installation
IMPORTANT NOTICE / NOTA IMPORTANTE Main hardware system / Sistema principal de quincalla Make sure to properly tighten each cam to ensure furniture solidity. Otherwise, parts could be damaged or the user could be injured. tighten Asegúrese de apretar bien cada arandela para garantizar la insert tools required solidez del mueble.De lo contrario, podría provocarse daño... - Page 7 HARDWARE INSTALLATION / INSTALACIÓN DE LAS QUINCALLAS Return / Modulo lateral H-36 insert insertar PA-844 remove the screws to be used in step 3. sacar los tornillos que servirà para la etapa 3. H-03 Code / Código Qty / Qté / Cant. x 10 : 1-888 8BESTAR (1-888 823-7827) ERVICE...
- Page 8 HARDWARE INSTALLATION / INSTALACIÓN DE LAS QUINCALLAS Return / Modulo lateral Assemble the parts in a upright position important / importante Coloque el mueble en posición vertical Assembling sequence Secuencia de ensamblaje Parts / / Piezas: tighten 70 30 RE40G apretar insert insertar...
-
Page 9: Dismantling-Installation
DISMANTLING-INSTALLATION / DESMONTAJE-INSTALACIÓN Moldings / Molduras 99400 not included no se incluye 99610 not included no se incluye Important/Importante loosen aflojar remove retirar important / importante tighten apretar insert insertar : 1-888 8BESTAR (1-888 823-7827) ERVICE ERVICIO... - Page 10 HARDWARE INSTALLATION / INSTALACIÓN DE LAS QUINCALLAS Return / Modulo lateral Assembling sequence EQ-143 Secuencia de ensamblaje Parts / / Piezas: RE40G EQ-143 + VR-212 99400 or o 99610 VR-210 RE40G 99400 or o 99610 not included no se incluye VR-212 two people are required to assemble and move this model.
-
Page 11: Installation
INSTALLATION / INSTALACIÓN Moldings / Molduras 99400 or o 99610 not included no se incluye RE40G Molding moldura Molding moldura Important/Importante RU-420 Remove paper on one side only of RU-420. Retire el papel de sólo uno de los costados del RU-420. Code / Código Qty / Qté... - Page 12 IMPORTANT NOTICE / NOTA IMPORTANTE Main hardware system / Sistema principal de quincalla Make sure to properly tighten each cam to ensure furniture solidity. Otherwise, parts could be damaged or the user could be injured. tighten Asegúrese de apretar bien cada arandela para garantizar la insert tools required solidez del mueble.De lo contrario, podría provocarse daño...
- Page 13 INSTALACIÓN DE LAS QUINCALLAS HARDWARE INSTALLATION / Return / Modulo lateral H-36 insert insertar PA-844 remove the screws to be used in step 3. sacar los tornillos que servirà para la etapa 3. H-03 Code / Código Qty / Qté / Cant. x 10 : 1-888 8BESTAR (1-888 823-7827) ERVICE...
- Page 14 INSTALACIÓN DE LAS QUINCALLAS HARDWARE INSTALLATION / Return / Modulo lateral Assemble the parts in a upright position important / importante Coloque el mueble en posición vertical Assembling sequence Secuencia de ensamblaje Parts / / Piezas: tighten 70 30 RE40G apretar insert insertar...
- Page 15 DISMANTLING-INSTALLATION / DESMONTAJE-INSTALACIÓN Moldings / Molduras 99610 not included no se incluye 99400 not included no se incluye Important/Importante loosen aflojar remove retirar important / importante tighten apretar insert insertar : 1-888 8BESTAR (1-888 823-7827) ERVICE ERVICIO...
- Page 16 INSTALACIÓN DE LAS QUINCALLAS HARDWARE INSTALLATION / Return / Modulo lateral Assembling sequence EQ-143 Secuencia de ensamblaje Parts / / Piezas: EQ-143 + VR-212 RE40G 99400 or o 99610 VR-210 RE40G 99400 or o 99610 not included no se incluye VR-212 two people are required to assemble and move this model.
- Page 17 INSTALLATION / INSTALACIÓN Moldings / Molduras 99400 or o 99610 not included no se incluye RE40G Molding moldura Molding moldura Important/Importante RU-420 Remove paper on one side only of RU-420. Retire el papel de sólo uno de los costados del RU-420. Code / Código Qty / Qté...
-
Page 18: Product Care
ADJUSTMENT / AJUSTE Important/Importante For future reference and to better serve you, please complete and apply the self-adhesive RE40G sticker in an accessible space such as under the part RE40G. Para uno mejor servicio en caso de necesidad, ponar la etiqueta en un lugar de fácil acceso como por ejemplo la parte inferior de la pieza RE40G. -
Page 19: Problems And Solutions
It is very important to install the hinges and hinge plates on the correct parts while respecting the instruction manual. For the installation and adjustment of the doors, please refer to your instruction manual or log on to the BESTAR internet site (www.bestar.ca). - Page 20 The new logo shows an open and radiant person. It also evokes the past of BESTAR, the fact that we were the first manufacturer of ready-to-assemble furniture to design U-Shape furniture. Finally, if you take the logo in its simplest form, it shows that BESTAR is there for its employees, for its customers...
