- Page 1 MODEL 99625-2139 BORDEAUX & GRAPHITE : WWW.BESTAR.CA : 1-888-8BESTAR (1 888 823-7827) 99625-2169 CHOCOLATE : WWW.BESTAR.CA : 1-888-8BESTAR (1 888 823-7827) 99625-2176 COGNAC CHERRY : WWW.BESTAR.CA : 1-888-8BESTAR (1 888 823-7827) ASSEMBLY INSTRUCTIONS INSTRUCTIONS D’ASSEMBLAGE INSTRUCCIONES DE ENSAMBLAJE...
- Page 2 Thank you for choosing a BESTAR product. Your total satisfaction is our #1 priority. Customer service and warranty information do not call to the place of purchase Please call our customer service department for immediate assistance using the following toll free number: www.bestar.ca...
-
Page 3: Tools Required
PARTS CODE / CÓDIGO QTY / QTÉ / CANT. CODE / CÓDIGO QTY / QTÉ / CANT. CODE / CÓDIGO QTY / QTÉ / CANT. CODE / CÓDIGO QTY / QTÉ / CANT. Moldings tools required two people are required to assemble and move this model. - Page 4 HARDWARES CODE / CÓDIGO QTY / QTÉ / CANT. CODE / CÓDIGO QTY / QTÉ / CANT. CODE / CÓDIGO QTY / QTÉ / CANT. CODE / CÓDIGO QTY / QTÉ / CANT. runners 406 mm (16” REAL SIZE CODE / CÓDIGO QTY / QTÉ...
-
Page 5: Important Notice
IMPORTANT NOTICE / Duly complete the self-adhesive sticker. / MODEL 00000-0000 COLOR : WWW.BESTAR.CA : 1-888-8BESTAR (1 888 823-7827) To better serve you! ASSEMBLY ASSEMBLY Model INSTRUCTIONS INSTRUCTIONS INSTRUCTIONS INSTRUCTIONS D’ASSEMBLAGE D’ASSEMBLAGE Production Number INSTRUCCIONES DE INSTRUCCIONES DE ENSAMBLAJE ENSAMBLAJE... -
Page 6: Hardware Installation
HARDWARE INSTALLATION / Mobile Pedestal / H-36 VR-207 RL-125 side / “A” side / “B” H-03 Code / Código Qty / Qté / Cant. x 16 : 1-888 8BESTAR (1-888 823-7827) ERVICE ERVICIO... - Page 7 HARDWARE INSTALLATION / Mobile Pedestal / VR-207 SE-686 H-36 H-03 CO-249 Use these holes / Push plastic lever and slide out piece to be used for parts CA09A & CA01A in step 5 VE-244 Code / Código Qty / Qté / Cant. x 12 : 1-888 8BESTAR (1-888 823-7827) ERVICE...
- Page 8 IMPORTANT NOTICE / Main hardware system / Make sure to properly tighten each cam to ensure furniture solidity. Otherwise, parts could be damaged or the user could be injured. tighten insert tools required important ASSEMBLY / Mobile Pedestal / Assemble on the back edge Assembling sequence Parts / : 1-888 8BESTAR (1-888 823-7827)
- Page 9 HARDWARE INSTALLATION / Drawers / important / importante VR-213 RL-125 tighten insert CL81B CL81B CL-745 Molding EC-744 H-03 Important H-04 Molding screw in Code / Código Qty / Qté / Cant. : 1-888 8BESTAR (1-888 823-7827) ERVICE ERVICIO...
- Page 10 HARDWARE INSTALLATION / Drawers / VR-207 CA01A side / “A” left side CR-141 side / “B” CA01A left side CA01A right side CA09A right side CO-249 VR-207 CA09A left side CL09A screws Code / Código Qty / Qté / Cant. x 16 : 1-888 8BESTAR (1-888 823-7827) ERVICE...
- Page 11 ASSEMBLY / Drawer / Assembling sequence Parts / CA05A CA01A CA01A bottom + CA05A 66 left side CA01A VR-212 CA05A VM-601 bottom / CA01A right side CA05A Code / Código Qty / Qté / Cant. : 1-888 8BESTAR (1-888 823-7827) ERVICE ERVICIO...
- Page 12 ASSEMBLY / Drawer / Assembling sequence Parts / EX-681 + CA09A EX-702 + CA09A EX-702 bottom EX-681 + CL81B EX-702 EX-681 right side CA09A VM-601 bottom / CA09A left side CL81B VR-212 filing / rangement / orden CA09A CA09A CA09A CA09A Letter / Legal /...
-
Page 13: Installation
INSTALLATION / Drawers / Important/Importante Ball bearings must be on front part of slider when installing drawers. CO-249 : 1-888 8BESTAR (1-888 823-7827) ERVICE ERVICIO... - Page 14 INSTALLATION / For future reference and to better serve you, Important/Importante please apply the self-adhesive sticker in an accessible space such as inside a drawer. To better serve you! Model Production Number Customer Service 1-888-823-7827 PRODUCT CARE / Avoid placing the furniture in the sunlight or near a source of heat. Use a soft dry cloth for dusting. To clean heavy dirt, use a cloth dipped in a solution of mild detergent and water.
-
Page 15: Problems And Solutions
It is very important to install the hinges and hinge plates on the correct parts while respecting the instruction manual. For the installation and adjustment of the doors, please refer to your instruction manual or log on to the BESTAR internet site (www.bestar.ca). - Page 16 The new logo shows an open and radiant person. It also evokes the past of BESTAR, the fact that we were the first manufacturer of ready-to-assemble furniture to design U-shaped furniture. Finally, if you take the logo in its simplest form, it shows that BESTAR is there for its employees, for its customers...
