Setup

To set up the O3 Edge using the Proviso app, you must have Bluetooth
mobile device . For best performance, your device should support Bluetooth Low Energy (BLE) version 5.0 or
later.

Connecting to the O3

1. Open the Proviso app and select Bluetooth for your connectivity method.
Note: Select NFC only when you want to factory reset your device. To reset your device, select
then select Reboot hub. A confirmation appears. To continue, select Yes, reboot hub.
2. Select an O3 to initiate a connection. Nearby O3 devices are listed by their Bluetooth MAC address.
The selected O3 plays a sound and the light ring flashes blue.
3. If this is the correct device, select Yes, connect. Data loads from the O3 and the status changes to
Connected. You can now view device information and sensor data from the O3 in the Diagnostics tab. This
data is transferred securely over Bluetooth from the O3 to your mobile device.

Configuring the O3

1. After connecting to the O3, go to Settings > Network. If you want to assign a static IP address, select
select Static, enter the IP settings, then select Save. Otherwise, leave it as DHCP. The IP address must be
unique for each O3.
2. Configure a network connection: IP, Ethernet, or Secure Connect.
Note: You cannot enable Ethernet or IP at the same time, but you can enable Secure Connect as a second port. The O3 will not route
between interfaces. That is, you cannot route Secure Connect to Ethernet, Secure Connect to IP, etc.
• To connect BACnet UDP/IP, next to BACnet UDP/IP, select
default UDP port number to activate the IP protocol. Select Save.
• To connect BACnet Ethernet, next to BACnet ethernet, select
Ethernet protocol. Select Save.
• To connect BACnet Secure Connect, next to BACnet SC, select
Auto config URL from your enteliWEB site. Select Save.
3. Next to Security, select
Save. If you have migrated from the O3 Setup app, you must use the same PIN to access the hub in Proviso.
4. Select Apply settings to hub. After the settings are applied, the status shows Configured and a green
check mark appears next to each applied setting.

Calibrating the O3

1. After connecting to the O3, go to Settings > Calibration and select
2. Measure the temperature below the O3 at occupant height, enter the temperature in the Actual
temperature field, then select Save.
3. If you plan to use the O3 for lighting control, adjust the lighting in the space to the desired brightness,
record the current reading in the Hub reading at desired light level field, then select Save. This setpoint
will be used by the control system as a baseline for control loops.
4. Select Apply settings to hub.
Upgrading the firmware (requires internet connection)
1. After connecting and applying settings to the O3, in the Proviso app, select
the screen, then select Upgrade firmware.
2. Under Firmware upgrade method, select Select version from list.
3. Select the firmware version you want to upgrade to, then select Apply firmware upgrade.
4. Click OK to continue. The light ring is orange while the upgrade is in progress.
Note: Do not power off or reboot the O3 while the light ring is orange. If the light ring flashes red three times, there was an error during
the upgrade process. Check your network connections and settings.
The information in this document is subject to change without notice.
, enter a 6-digit PIN to secure BLE read/write access to the hub, then select
and location services enabled on your
®
in the upper right corner of the screen,
. Select enable Network, then enter the
. Select enable Network to activate the
. Select enable Network, then enter the
.
in the upper right corner of
,
