INSTRUCTION SHEET
#358983
OPERATING/INSTALLATION INSTRUCTIONS
INSPECT CONTENTS IMMEDIATELY AND FILE CLAIM WITH DELIVERING CARRIER FOR ANY DAMAGE.
YOU ARE RESPONSIBLE FOR DAMAGE TO YOUR UNIT IF RETURNED IMPROPERLY PACKED.
THIS MANUAL IS TO BE READ AND UNDERSTOOD BY ALL PERSONS USING OR INSTALLING THIS APPLIANCE.
THIS UNIT WAS CAREFULLY INSPECTED AND PACKAGED BEFORE LEAVING THE FACTORY. UPON RECEIPT, INSPECT UNIT FOR VISIBLE AND
CONCEALED DAMAGE. IF YOU NOTICED ANY DAMAGE, NOTIFY THE TRANSPORTATION COMPANY IMMEDIATELY AND FILE A DAMAGE CLAIM
WITH THEM.
Eagle Foodservice Equipment, Eagle MHC, and SpecFAB
Countertop Gas Hot Plates
SAVE YOUR BOX AND ALL PACKING MATERIALS.
NOTE: INTENDED FOR OTHER THAN HOUSEHOLD USE. THIS COMMERCIAL APPLIANCE
MUST BE INSTALLED WITHIN SURROUNDINGS AND VENTILATION REQUIREMENTS AS
DICTATED BY NATIONAL AND/OR LOCAL CODE.
IMPORTANT: KEEP THIS MANUAL WITH THE APPLIANCE ALL THE TIME.
• 100 Industrial Boulevard, Clayton, Delaware 19938-8903 U.S.A.
• Phone: 302/653-3000 • 800/441-8440
• Fax: 302/653-2065 • www.eaglegrp.com
CAUTION
are divisions of Eagle Group. ©2022 by the Eagle Group
®
(continued on Page 2)
EG10054
Revised 08/22
