HIT-NOT Proximity System
RF Module
User's Manual v1.0
FREDERICK ENERGY PRODUCTS, LLC
1769 Jeff Road
Huntsville, AL 35806
1.800.489.6915
US7,420,471; US8,169,335; US8,232,888; US5,939,986;
US6,810,353; AU2005289704; ZA2007/02919; ZA2008/02673;
1
ZA2010/06816, ZA2010/09068 Patent Pending

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HN-RF and is the answer not in the manual?

Questions and answers

Related Manuals for Hit-Not HN-RF

Summary of Contents for Hit-Not HN-RF

  • Page 1 Exhibit: 9 HIT-NOT Proximity System RF Module User’s Manual v1.0 FREDERICK ENERGY PRODUCTS, LLC 1769 Jeff Road Huntsville, AL 35806 1.800.489.6915 US7,420,471; US8,169,335; US8,232,888; US5,939,986; US6,810,353; AU2005289704; ZA2007/02919; ZA2008/02673; ZA2010/06816, ZA2010/09068 Patent Pending...
  • Page 2 Table of Contents 1. Overview ......................3-5 Theory of Operation ................3 Frequency of Operation… ............... 3 Label Information ................... 3 FCC/IC Information ................4-6 2. Operation ......................7-8 Installation Information… ................ 7 2.1.1 Interoperability Warning ..............7 Charging… ....................7 Alerts…...
  • Page 3 Devices. 1.1 Theory of Operation The Radio Transceiver Module (model HN-RF) is a modular device that mounts inside the Magnetic Field Generator (MFG). The module mounts via a 16-pin header and is secured in place with a through hole screw and nylon insert nut. A whip antenna mounted to the lid of the MFG connects to the antenna port of the RF module allowing it to send and receive messages to other HitNot Devices.
  • Page 4 1.4 FCC/IC Information The FCC ID for the RF Module is QUI-RF and complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received including interference that may cause undesired operation.
  • Page 5 --Branchez l'appareil dans une prise sur un circuit différent de celui auquel le récepteur est connecté. --Consulter le vendeur ou un technicien radio / expérimenté. Les changements ou modififications à cet appareil sans expressément approuvée par la partie responsable de conformité pourraient annuler l’autorité de l’utilisateur de faire fonctionner cet équipement.
  • Page 6 L’antenne à utiliser avec ce dispositif est un Linx ANT-916-WRT-UFL. La puissance maximale transmise avec cette antenne est -2.76 dBm avec une impédance exigée de 50 ohms. US7,420,471; US8,169,335; US8,232,888; US5,939,986; US6,810,353; AU2005289704; ZA2007/02919; ZA2008/02673; ZA2010/06816, ZA2010/09068 Patent Pending...
  • Page 7 Operation 2.1 Installation Information The RF Module comes pre-installed into all MFG units from the factory and do not require further modification from the end user. 2.1.1 Inoperability Warning There are no inoperability warnings. 2.2 Charging The RF Module does not require charging. It gets power supplied directly from the MFG when powered on. 2.3 Alerts The RF Module does not directly give any alerts.
  • Page 8 2.7 RF Module Specifications Part Number: HN-RF Size: 1.5” x 1.75” / 3.8cm x 4.4cm Weight: 1oz / 28 g Input Voltage: 5V Operating Temperature Range: -30°C to + 70°C ; -22°F to 158°F Revision History 3.1 Version 1.0 – December 22, 2021 Original Release.
