HTC Desire 510 Quick Start Manual

HTC Desire 510

Inserting your micro SIM and storage cards

IMPORTANT:
Do not cut a regular SIM and insert it into the micro SIM
slot, since the card may get stuck in the slot. If you're
using a nano SIM card with a card adapter, never insert
the adapter when it's empty. This may damage the card
slot.
cut-off
corner
1. With the phone facing
down, open the back cover
from the small opening at
the bottom.
2. Remove the battery.
3. Remove the placeholder
card from the SIM slot.
Note: Make sure NOT
to use the placeholder
card as a
adapter.
gold
4. With your micro SIM card's
contacts
gold contacts facing down
and cut-off corner facing
in, insert the micro SIM into
the SIM slot and push it
into place.
gold
5. With your microSD™ card's
contacts
gold contacts facing down,
insert the microSD card
into the storage card slot
and push it into place.
nano SIM card
