Polywood RT248 Assembly Instructions

MODEL: 1910
- (2) Side frames RH/LH
- (1) Seat assembly
- (1) Back assembly
- (1) Medallion brace
- (1) Front brace
- (1) Hardware pack

TOOLS NEEDED

4MM T-HANDLE HEX KEY
(INCLUDED)
QTY DESCRIPTION
A - 1/4-20 X 1-3/4 WAFER SHCS
6
B - .27 X 3 SOCKET WAFER "A"
4
C - .27 X 4 SOCKET WAFER "A"
2
ASSEMBLY INSTRUCTIONS
STEP 1
Attach braces into pockets on side frames
using (4) 3" screws
Do not tighten screws until last step.
STEP 2
Attach seat assembly to side frames using
(2) 4" screws for front legs and (2) 1-3/4 bolts
for back legs.
C
A
Rear
ALL HARDWARE IS STAINLESS STEEL
B
B
Front
STEP 3
Attach back assembly to side frames
using (4) 1-3/4 bolts.
Tighten all screws.
C
A
B
B
A
A
12/3/2012
