Model:
CDD200, CDD201, CDD202
__(1) CHAIR
__(2) ARM ASMB (RH/LH)
__(1) HARDWARE PACK

TOOLS NEEDED

4mm Hex Key (included)
Qty.
Description
A -1/4-20 X 1-3/4 WAFER SHCS
4
1
HDWPK-#8 SCREW PLUGS, 4X (EXTRAS)
ASSEMBLY INSTRUCTIONS
Step 1
Attach back of arm by threading
the attached dowel screw into the pilot hole
until the arm is snug against the back leg.
CLOCKWISE
PILOT HOLE
Step 2
Attach (4)1-3/4 bolts thru the seat
frame into the insert nuts
on the arm supports
INSERT
NUTS
ALL HARDWARE IS COATED STAINLESS STEEL
ROTATE
A
CDD200
ROTATE
CLOCKWISE
CDD201
CDD202
