Summary of Contents for Folio ZERO40

  • Page 1 ZERO .ZERO40 U S E R M A N U A L USER MANUAL trasformatore remoto so tto/parete Remote power supply ceiling / wall...
  • Page 2 Installation of frame ZERO ® panel installation FOLIO Electrical connection ® panel fixing FOLIO Cloth positioning Power supplies WARNING Handling Cleaning Damaged appliances Dismantlement Telo Profilo PVC Cloth Profilo di alluminio Seal ZERO.55 panel ® FOLIO Folio panel Zero.40 Aluminum structure...
  • Page 3 .COMPONENTS Inside the packing crate you will find: FOLIO LIGHTING PANEL ® ZERO PROFILE S CORNERS WIDTHS CLOTH (with or without print) CORNERS LIGHTING PANEL FOLIO ® ZERO80 PROFILES WIDTHS CLOTH (PRINTED)
  • Page 4 .COMPOSITION OF ZERO FRAME Positon the profiles at 45° and connect the angles, screwing the corners. Tighten the grains in all four corners until creating the frame ZERO.
  • Page 5 .COMPOSITION OF ZERO FRAME Pierce the profile ZERO channel for the next wall fixing. For the installation of the FRAME, use only 6/8 mm diameters screws. DON’T use dif- ferent fixing systems, like whashers, because could be visible once finished the installa- tion.
  • Page 6 .INSTALLATION OF ZERO FRAME Fix the frame on the wall with the appropriated screws (screws are not given by us). Ceiling fixing follows the same procedure.
  • Page 7 .INSTALLATION OF ZERO FRAME After fixing the ZERO frame, verify if it is symmetrical and squared. Pass the 24V 6 electric cable (previously installed by you) into the ZERO frame.
  • Page 8 .INSTALLATION OF ZERO FRAME Extend the extension of electric cables by fixing them according to the cables output of the FOLIO lighting panel(s) Clean the residual particle inside the duct of ZERO profile. .
  • Page 9 Widths supplied by us and already equipped with double-sided adhesive for panel application. Position the FOLIO panel(s) inside the ZERO frame, inserting from the bottom. Pay attention to not crush the cables and to not flex the panel during the handling...
  • Page 10 FOLIO® panel, with an exit current of 24V and with al consumo del pannelo FOLIO ® , con tensione di uscita 24 V e con uscita al consumo del pannelo FOLIO ® , con tensione di uscita 24 V e con uscita SELV exits EN 61347-2-13 compliant.
  • Page 11 .FOLIO PANEL FIXING Place the width at the point where the panels will be joined and fix the light panel with appropriated screws (screws not supplied). Be careful not to over tighten the screws.
  • Page 12 .FOLIO PANEL FIXING Proceed with the installation of the remaining panel(s) in the same way.
  • Page 13 .CLOTH POSITIONING Position the fabric with the eventual print to the outside.
  • Page 14 .CLOTH POSITIONING Insert the seal in all four sides of ZERO frame and tense the fabric.
  • Page 15: Power Supplies

    Use class II drivers with adequate absorption with regards to the consumption of the FOLIO® panel, with an exit current of 24V and with SELV exits EN 61347-2-13 compliant. It is recommended to connect maximum 4/5 FOLIO® panels to one driver.
  • Page 16 • The FOLIO® panel must be installed in a place accessible for maintenance. • Do not connect the FOLIO® panel directly to the mains. The FOLIO® panel must always be connected to a driver, which will be successively connected to the mains.
  • Page 17 .HANDLING Remove the FOLIO® folio panel from the wooden case, not from the edges but from the middle, prevent bending and curving and carry it vertically. Carry the FOLIO® panel vertically to prevent every possibility of bending and curving. Pay attention not to pull the power cables.
  • Page 18 • The parts influencing the performance of the light (such as white acrylic sheets, marbles or glass) should be cleaned following the instructions below. • The cleaning of EXTERNAL parts and SURFACES which are part of the FOLIO® panel can be executed in according to the following table:...
  • Page 19 Verify that the supply voltage is compatible with the voltage and current necessary for the regular functioning of the appliance you are about to install: the primary factor to consider is the data on the FOLIO® LED panels’ label.
  • Page 20 .DISMANTLEMENT Dismantlement of the appliance must be commissioned to qualified internal or external personnel.Dismantlement operations must be carried out in accordance with current regulations, considering that some of the materials used are not recyclable and some others may be harmful. In accordance with Italian LEGISLATIVE DECREE 14 March 2014, no.
