- Page 1 .LINE WALL USER MANUAL Remote power supply...
- Page 2 .LINE Index Components Installation of fixing system Electrical connection ® LINE installation FOLIO Power supplies WARNING Handling Cleaning Damaged appliances Dismantlement...
-
Page 3: Fixing System
.COMPONENTS Inside the crate you can find: • FOLIO ® LIGHTING PANEL(S) LINE • FIXING SYSTEM Unscrew the fixing screw to open the crate FIXING SYSTEM LINE... - Page 4 .INSTALLATION OF FIXING SYSYEM Positioning the wall FIXING SYSTEM by passing the 24V cable (by you previously installed) through the central hole. Install the FIXING SYSTEM to the wall by usign appropriate screws. Hole for electric cable (24V)
-
Page 5: Electrical Connection
220 V cable and power the system. Use class II transformers with adequate absorption with regards to the consumption of the FOLIO ® panel, with an exit current of 24V and with SELV exits EN 61347-2-13 compliant. It is recommended to connect maximum 4/5 Folio panels to one driver. - Page 6 .FOLIO LINE INSTALLATION ® After the cables connection, fix the LINE WALL to the FIXING SYSTEM with the safety screws (from both sides).
-
Page 7: Power Supplies
Use class II drivers with adequate absorption with regards to the consumption of the FOLIO ® panel, with an exit current of 24V and with SELV exits EN 61347-2-13 compliant. It is recommended to connect maximum 4/5 FOLIO ® panels to one driver. - Page 8 .WARNING Consult the company Cifralluminio s.r.l. before intervening in any way on the FOLIO® panels. For any doubts on the functioning of the device or on its mainte- nance consult Cifralluminio s.r.l.. • Do not open or tamper with the FOLIO ®...
- Page 9 .HANDLING Remove the FOLIO ® folio panel from the wooden case, not from the edges but from the middle, prevent bending and curving and carry it vertically. Carry the FOLIO ® panel vertically to prevent every possibility of bending and curving.
-
Page 10: Safety Notice
• The parts influencing the performance of the light (such as white acrylic sheets, marbles or glass) should be cleaned following the instructions below. • The cleaning of EXTERNAL parts and SURFACES which are part of the FOLIO ® panel can be executed in according to the following table:... - Page 11 Verify that the supply voltage is compatible with the voltage and current necessary for the regular functioning of the appliance you are about to install: the primary factor to consider is the data on the FOLIO ® LED panels’ label.
- Page 12 .DISMANTLEMENT Dismantlement of the appliance must be commissioned to qualified internal or external personnel. Dismantlement operations must be carried out in accordance with current regulations, considering that some of the materials used are not recyclable and some others may be harmful. In accordance with Italian LEGISLATIVE DECREE 14 March 2014, no.
- Page 13 Via R.Gessi, 10 - 25135 Brescia (BS) - Italy Phone: +39 030 3363047 - +39 030 3363819 Fax: +39 030 3363048 E-Mail: info@foliopanel.it - cifralluminio@cifralluminio.com www.foliopanel.it Cod.Fiscale e P.IVA 03212940179 Cap. Soc. € 61.200,00 i.v. Registro Imprese di Bs Num. 03212940179 R.E.A.
