LOW VOLTAGE
FLOOD/PATHWAY LIGHT
model no. 29002
Part
Description
A
Light Head
B
Connection Tube
C
Ground Stake
D
Wire
E
Connector
Read all instructions before assembly. Failure to do so may result in incorrect
Assembly or possible injury.
A
B
C
D
E
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fusion 29002
Summary of Contents for Fusion 29002
- Page 1 LOW VOLTAGE FLOOD/PATHWAY LIGHT model no. 29002 Part Description Light Head Connection Tube Ground Stake Wire Connector Read all instructions before assembly. Failure to do so may result in incorrect assembly or possible injury.
- Page 2 Important Safety Information Please read and understand all instructions before attempting to assemble, operate, or install this product. Keep this manual for future reference. WARNING: • Risk of fire or electrical shock. Turn off power before assembly. • Do not install or connect wires with wet hands. •...
- Page 3 Running the Landscape Wire (Not Included) RUNNING THE LANDSCAPE WIRE: • The included cable connectors are to be used only on low voltage power cable with SPT-2W or equivalent 18, 16, 14, or 12 AWG cable. • Do not use landscape cable smaller than listed in the chart below. •...
- Page 4 3. Press both levers down to close. See Figure 1-Year Limited Warranty This product is covered under a one year limited warranty. Fusion Products Ltd. warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of one year from date of purchase.
