Summary of Contents for Spedal MC02
- Page 1 USER MANUAL Far Field AI-Denoising Microphone MC02 016C1C15-EN...
-
Page 2: Table Of Contents
CONTENT 1. DISCLAIMER AND SAFETY GUIDELINES .. 01 1.1 Disclaimer............01 1.2 Safety Guidelines ........... 03 2. PRODUCT AND INSTALLATION ....05 2.1 In the box............05 2.2 Product Diagram ..........06 2.3 Installation Guideline ........09 3. CONNECTION SETTINGS ......10 3.1 Windows system settings ....... -
Page 3: Disclaimer And Safety Guidelines
Failure to follow the instructions and warnings in this document may result in product damage or other possible injury or loss. You must strictly follow Spedal's guidelines to install and use the product, and never use non-stan- dard parts. Before assembling, setting up and using, be sure to carefully read all the instructions and warnings in this document. - Page 4 Spedal may formulate. You understand and agree that in the absence of videos or photos, Spedal may not be able to analyze the cause of your product damage or accident, and cannot provide you with after-sales service such as warranty.
-
Page 5: Safety Guidelines
1.2 Safety Guidelines 1.2.1 Warnings ● Do not install or operate the device with wet hands to avoid accidents; ● Do not install the device in places of high temperature or high humidity; ● Do not install the device in places of flammable or explosive gases or liquids;... - Page 6 1.2.2 Cautions ● Before connecting the headphone to the microphone, turn down the microphone gain and headphone volume to prevent hearing damage due to excessive loudness. ● Do not touch the microphone during recording, other- wise noises might be recorded. ●...
-
Page 7: Product And Installation
2. PRODUCT AND INSTALLATION 2.1 In the box Before using this product, please check whether the product package contains all of the following items. If anything is missing, please contact Spedal or your local agent. ● Microphone ● Type-C Cable ●... -
Page 8: Product Diagram
2.2 Product Diagram ③ ① ② ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩... - Page 9 ① Mic pickup gain button Rotate clockwise to increase Rotate counterclockwise to decrease ② Mic pickup pattern Sound Suitable Scenes Direction Streaming Podcasts Voice-overs Instruments Cardioid Vocals Instruments Stereo Conference Events Omnidirectional calls Interviews Instruments Vocal Duet Bidirectional...
- Page 10 ③ Metal mesh cover ④ Headphone monitoring gain button Rotate clockwise to increase Rotate counterclockwise to decrease ⑤ Mic mute button Green: Pickup mode Red: Mute mode ⑥ Angle adjustment knob ⑦ Mic base ⑧ 3.5mm headphone output port ⑨ Type-C data port / power port ⑩...
-
Page 11: Installation Guideline
2.3 Installation Guideline The USB plug of this product needs to be plugged into the USB port of the computer to connect the microphone to the computer. You can adjust the angle of the microphone to wards the user by adjusting the bracket support (angle) knob. -
Page 12: Connection Settings
We strongly recommend that you, if your computer allows it, please select this product as the default device (the device name is Spedal USB Live Mic) in the system settings or software settings to facilitate your daily use. - Page 13 Power Options Event Viewer System Device Manager Network Connections Shut down or sign out Desktop 2. If "Spedal USB Live Mic" is displayed in "Audio inputs and outputs", the connection is successful. Device Manager File Action View Help Audio inputs and outputs...
- Page 14 " on the right side of the taskbar " and select "Open Sound Settings" Open Sound settings Sounds Troubleshoot sound problems 2.In the "Select Input Device" under "Input", select "Spedal USB Live Mic", and click "Device Properties" under "Input"; Settings Sound Input Choose your input device...
- Page 15 4.In the pop-up "Microphone Properties" setting panel, click the "Listen" option panel, and make sure that "Listen to this device" is not checked; Microphone Properties Listen General Levels Advanced You can listen to a portable music player or other device through this Microphone jack.
- Page 16 6.Click the "Advanced" option panel. In the "Default Format", it is recommended to select the "DVD Quali- ty" option. In the "Exclusive Mode", make sure to check "Allow the application to exclusively control the device" and "Give exclusive mode application priority". Microphone Properties Advanced General...
- Page 17 2.Select "Spedal USB Live Mic" in "Choose your output device" under "Output". Click "Device Properties" under "Output"; Settings Sound Output Choose your output device Spedal USB Live Mic Certain apps may be set up to use different sound devices than one selected here.Customize app volumes and devices in advanced...
-
Page 18: Mac Os X System Settings
5.Click the "Enhanced" option panel, and make sure to check "Disable all sound effects"; Speaker Properties Enhancements General Levels Advanced Spatial sound select the enhancements to apply for your current speaker configuration. Changes may not take effect until the next time you start playback. Disable all enhancements Cancel Apply... - Page 19 3.2.2 Check 1.Click Apple "Menu", click "About This Machine"; File Edit About This Mac System Preferences... Location App Store... Recent ltems Sleep Restart... Shut Down... Lock Screen Log Out“ ”... 2.The overview window pops up, click "System Report"; Overview Displays Storage Support Resources...
- Page 20 3.Pull down "Hardware-Audio", if it displays "Spedal USB Live Mic", the installation is successful. MacBook Pro Hardware Audio Apple Pay Device Audio Spedal USB Live Mic Bluetooth MacBook Pro Microphone Camera Card Reader MacBook Pro Speakers Controller Diagnostics Disc Burning...
- Page 21 Apple ID, iCloud, Media & App Store Sound 3.In "Select a sound input device" under "Input", select "Spedal USB LiveMic" and adjust the input volume to a suitable level; 4.Select the appropriate output device under "Output", adjust the output volume to a suitable level, and make sure that "Mute"...
-
Page 22: Appendix
4. APPENDIX 4.1 Specifications 4.1.1 Microphone pickup parameters Power Supply DC5V/100mA ± 10mA Frequency response 20Hz-20KHz Sensitivity -40dB ± 3dB( at 1KHz) Signal-to-noise ratio 75dB Maximum sound pressure level 120dB (1kHz≤1%T.H.D) Bit rate 16bit-24bit Sampling Rate 48KHz Total harmonic distortion <0.1% Pickup diaphragm chamber 3 x 14mm... - Page 23 4.1.3 Frequency response curve Cardioid 0° 330° 30° 300° 60° 270° 90° 240° 120° 20KHz 210° 150° 180° Bidirectional 0° 330° 30° 300° 60° 270° 90° 240° 120° 20KHz 210° 150° 180° Omnidirectional 0° 330° 30° 300° 60° 270° 90° 240°...
-
Page 24: Warranty
4.2 Warranty Thank you for purchasing the Spedal AI-denosing condenser microphone. This unique product equipped with AI-denosing technology will capture clear sounds and is a powerful tool for audio production and video conferences. Customers enjoy a one-year warranty and after-sales service from the date of purchase. - Page 25 Please strictly follow the instructions in this manual to use this product to avoid unnec- essary losses. If you have any questions or problems while reading the product manual or using the product, please contact us by http://spedal.cc email: support@spedaltech.com or visit our official website.
