Summary of Contents for Spedal MC01
- Page 1 CONDENSER MICROPHONE MC01 008C1728-EN...
- Page 2 ● Typical Frequency Response Curve SPECIFICATION 0° Sensitivity: -36±3dB(1.5V, 680KΩ; 0dB = 1V/Pa, 1KHz) Output impedance: Low impedance(<680Ω) 180° Polar Pattern: Cardioid 20Hz 1000 10000 20000 Frequency range: 100Hz-18000Hz ● Polar Response SPL: 125dB 0° +5.0 Signal to noise ratio: >58dB -2.0 -2.0 -4.0...
- Page 3 ● Typical Frequency Response Curve FEATURES Plug one end of the USB cable into the power socket in the Insert headphones microphone, and connect the other end to a computer. The power indicator light will turn Power socket Volume adjustment blue if it is working properly.
- Page 4 Moving closer will make a more intimate and full GENERAL OPERATION sound, while moving further will contribute to a sound with room echo effect and avoid increased ● Positioning the microphone for users bass or low frequency response resulting from a too close sound source.
- Page 5 To manually adjust your input level via your 2. Click on ‘Sound’ to view the sound options. computer’s system preferences, please use the following instructions relevant to your device platform/operating system. Connect the other end of the USB cable to a computer. The power indica- tor light will turn blue if it is working properly.
- Page 6 2. Click on ‘Sound’ preferences in the ‘Control Panel folder’. USB LCS Audio ● Adjusting the input level on a Windows computer 3. Open the ‘Recording’ tab and double click on 1. Click on ‘Start’ menu and then ‘Control Panel’. ‘USB LCS AUDIO’...
- Page 7 4. Adjust the input level with the slider. - 6 -...
- Page 8 Descargue manuales en otros idiomas desde nuestra página de inicio. Scarica manuali in altre lingue dalla nostra homepage. Pobierz instrukcje obsługi w innych językach z naszej strony internetowej. Ladda ner manualer från andra språk från vår hemsida. ホームページから他の言語のマニュアルをダウンロードしてください。 Scan the QR Code For any questions please contact support@spedaltech.com www.spedal.cc...
