Summary of Contents for InHand InSwitch ISM-P Series
- Page 1 InHand InSwitch ISM-P Series WEB Configuration Manual V1.3—2022...
-
Page 2: Table Of Contents
Table of Contents Chapter 1 Basic Configuration ......................- 1 - 1.1 HTTP protocol configuration ..................- 1 - 1.1.1 Language Selection ..................... - 1 - 1.1.2 HTTP service port configuration ................- 1 - 1.1.3 Enabling the HTTP service .................. - 1 - 1.1.4 HTTP access mode Configuration .............. - Page 3 Table of Contents 4.1.4 Author Rule Management ................. - 15 - 4.1.5 Authentication Rule Management ..............- 16 - 4.2 Management Access ....................- 16 - 4.2.1 Server ........................ - 16 - 4.2.2 SNMP Community Management (SNMPv1/v2 community) ......- 17 - 4.2.3 SNMPv3 Configuration ..................
- Page 4 Table of Contents Chapter 7 Switching ........................... - 36 - 7.1 Storm Control ......................- 36 - 7.1.1 Broadcast Storm Control ................... - 36 - 7.1.2 Multicast Storm Control ..................- 36 - 7.1.3 Unicast Storm Control ..................- 37 - 7.2 Port Rate Limits ......................
- Page 5 Table of Contents Chapter 10 Redundancy ........................- 56 - 10.1 Link Aggregation Configuration ................. - 56 - 10.1.1 Port Aggregation Configuration ............... - 56 - 10.1.2 Port Channel Global Loading Balance ............- 57 - 10.2 Backup Link ....................... - 57 - 10.2.1 Backup Link Global Configuration ..............
- Page 6 Table of Contents Chapter 13 Help ........................... - 75 - 13.1 About ......................... - 75 -...
-
Page 7: Chapter 1 Basic Configuration
Chapter 1 Basic Configuration 1.1 HTTP protocol configuration Switches support not only can be configured by CLI and SNMP protocol, it also supports being configured by web. HTTP service port configuration and time configuration of abnormal message overtime and etc are also supported. 1.1.1 Language Selection Currently, there are two languages in ISM-P series Industrial Switch: you may choose English or Chinese. -
Page 8: Http Access Mode Configuration
WEB Configuration Manual ip http server Enabling HTTP service 1.1.4 HTTP access mode Configuration You can access a switch through two access modes: HTTP access and HTTPS access, and you can use the following command to set the access mode to HTTP. Command Purpose ip http http-access enable... -
Page 9: Https Service Port Configuration
WEB Configuration Manual 1.2.2 HTTPS Service Port Configuration As same as the HTTP service port, the service port in HTTPS is number 443. User can change the port number through command line in global configuration mode. Suggesting the port number is bigger than 1024 so as to avoid the port number collision. -
Page 10: Chapter 2 Accessing Switch
WEB Configuration Manual Chapter 2 Accessing Switch 2.1 Accessing the Switch Through Web When accessing the switch through Web browser, please make sure that the applied browser complies with the following requirements: ⚫ HTML of version 4.0 ⚫ HTTP of version 1.1 ⚫... -
Page 11: Upgrading To The Web-Supported Version
WEB Configuration Manual 2.2.1 Upgrading to the Web-Supported Version If your switch is upgraded to the Web-supported version during its operation and the switch has already stored its configuration files, then Web visit cannot be directly applied on the switch. Perform the following steps one by one to enable the Web visit on the switch: 1. -
Page 12: Introduction Of Web Interface
WEB Configuration Manual links. 2.4 Introduction of Web Interface The Web homepage appears after login, the whole homepage consists of the top control bar, the navigation bar, the configuration display area and the bottom control bar. 2.4.1 Top Control Bar Save All Write the current settings to the configuration file of the device. -
Page 13: Navigation Bar
WEB Configuration Manual 2.4.2 Navigation Bar The contents in the navigation bar are shown in a form of list and classified according to types. By default, the list is located at “system”. If a certain item need be configured, please click the group name and then the sub-item. -
Page 14: Bottom Control Bar
WEB Configuration Manual 2.4.4 Bottom Control Bar The configuration area always contains one or more buttons, and their functions are listed in the following table: Apply the modified configuration to the device. The application of the configuration does not mean that the configuration is saved in the configuration file. -
Page 15: Chapter 3 Basic Configuration
WEB Configuration Manual Chapter 3 Basic Configuration 3.1 System If you click Basic Setting -> System in the navigation bar, the page appears as shown as below： The system message will be displayed in the dialog box. The default name of the device is “Switch”. You can enter the new hostname in the text box and then click “Set”... -
Page 16: Port Configuration
WEB Configuration Manual ⚫ Setting the IP address of Interface VLAN 1 , in order to access the switch ⚫ This page is used to set the IP address of Interface Vlan 1 in the management interface of the device. In initial conditions, the MAC address of the device, the IP address, mask and gateway of the interface will appear on this page. -
Page 17: Software
WEB Configuration Manual This page set the auto-shutdown port and delay time of shutdown. Click the Set in the bottom control bar to complete the configuration, and click the Save on the top. The corresponding port will be shutdown in delayed time after the switch turned on. 3.5 Software If you click Basic Setting ->... -
Page 18: Restart
WEB Configuration Manual 3.7 Restart If you click Basic Setting -> Restart in the navigation bar, the page appears as shown as below figure: You can choose “Reboot” to reboot the switch, or choose “Clear MAC Address Table” , “Clear ARP Table”, “Clear port counters”. -
Page 19: Chapter 4 Security
WEB Configuration Manual Chapter 4 Security 4.1 User Management 4.1.1 User Management If you click Security -> User Management in the navigation bar, the page appears as shown as below figure: Click Modify to change user’s configuration at this page, and click Delete at the bottom bar to delete the selected user. -
Page 20: Group Management
WEB Configuration Manual Fill in configuration at every configuration column and click Set at the bottom bar to create new user. Click Reload to refresh the user information. And click Go Back to go back to previous level page. 4.1.2 Group Management Click Security ->... -
Page 21: Author Rule Management
WEB Configuration Manual Click Modify to change password regulation at this page. Click Delete at the bottom bar to delete password regulation. Click Create at the bottom bar to enter the following configuration page: Fill in configuration at every configuration column and click Set at the bottom bar to create new password regulation. -
Page 22: Authentication Rule Management
WEB Configuration Manual 4.1.5 Authentication Rule Management Click Security -> User Management in order and then click Authen Management to open configuration page as following: Click Modify to change authentication rules at this page. Click Delete at the bottom bar to delete the selected authentication rules. -
Page 23: Snmp Community Management (Snmpv1/V2 Community)
WEB Configuration Manual Click SNMP to configure SNMP related: 4.2.2 SNMP Community Management (SNMPv1/v2 community) Click Security -> Management Access -> SNMPv1/v2 Community at navigation bar in order to enter configuration page as following: Click Modify to change the feature of SNMP Community. Click Create to create a new SNMP Community: Click Delete to delete the selected SNMP Community. -
Page 24: Snmpv3 Configuration
WEB Configuration Manual Click Modify to modify feature of SNMP Host; Click Delete to delete the selected SNMP Host. 4.2.3 SNMPv3 Configuration Click Security -> Management Access -> SNMPv3 Configuration at navigation bar in order to enter configuration page as following: Click the Modify to change the features of SNMPv3 Group Configuration. -
Page 25: Cli ( Command Line Interface )
WEB Configuration Manual Click Delete at bottom control bar to delete the selected configuration information of SNMPv3 Group. 4.2.4 CLI ( Command Line Interface ) Click Security -> Management Access -> CLI at navigation bar in order to enter GLOBAL configuration page as following: Terminal’s overtime time could be configured at this page, and if configured as 0, it means there would be never overtime. -
Page 26: Port Security
WEB Configuration Manual 4.3 Port Security 4.3.1 IP MAC Binding Click Security -> Port Security at navigation bar in order, and then click IP MAC Binding to enter configuration page as following: Click Detail to check the IP MAC binding information of that port. Click Modify to change the selected binding items of the IP MAC. -
Page 27: Static Mac Filter
WEB Configuration Manual Interface’s Static MAC Filtration Mode could be configured at this page. 4.3.3 Static MAC Filter Click Security -> Port Security at navigation bar in order, and then click Static MAC Filter to enter configuration page as following: Click Detail to check the interface’s static MAC filtration items. -
Page 28: Dynamic Mac Mode
WEB Configuration Manual Click Modify to modify static MAC filtration items. Click Create to create new static MAC filtration items. Click Delete at bottom control bar to delete the selected static MAC filtration items. 4.3.4 Dynamic MAC Mode Click Security -> Port Security at navigation bar in order, and then click Dynamic MAC Mode to enter configuration page as following: Interface’s Dynamic MAC Mode could be configured at this page. -
Page 29: Keepalive
WEB Configuration Manual Click Reload to refresh the port protection group information. Click “Port Protect List”, enter the Port Protect Group Creating page: Click Reload at the bottom control bar, refresh the Port Protect Group information. Click Delete at the bottom control bar, delete the selected port protect group. Click Create at the bottom control bar, enter the Port Protect Group Creating page: Click Set at the bottom control bar, to finish the setting. -
Page 30: 802.1X Port Authentication
WEB Configuration Manual Click Set at the bottom control bar after configuration, to finish the port status setting. Click Reload at the bottom control bar, refresh the port setting information. 4.6 802.1X Port Authentication 4.6.1 Global Click Security -> 802.1X Port Authentication -> Global at navigation bar in order to enter configuration page as following: Configure the enabling/disabling operations of 802.1X port authentication at this page. -
Page 31: Authentication List
WEB Configuration Manual 4.6.2 Authentication List Click Security -> 802.1X Port Authentication -> Authentication List at navigation bar in order to enter configuration page as following: Click Reload at the bottom control bar, to refresh the authentication list. Click Delete at the bottom control bar, to delete the selected port authentication list. Click Create to create new authentication entry: 4.4.3 Port Configuration Click Security ->... -
Page 32: Statistics
WEB Configuration Manual 4.6.4 Statistics Click Security -> 802.1X Port Authentication -> Statistics at navigation bar in order to enter configuration page as following: All ports’ statistic information of 802.1x messages could be checked at this page. 4.7 RADIUS 4.7.1 Global Click Security ->... - Page 33 WEB Configuration Manual Radius server’s authentication port and accounting port can be configured at this page. Click Set at the bottom control bar, to finish the setting. Click Reload at the bottom control bar, refresh the authentication port and accounting port information.
-
Page 34: Chapter 5 Time
WEB Configuration Manual Chapter 5 Time 5.1 Basic Setting Click Time -> Basic Setting at navigation bar in order to enter configuration page as following: Click Reload to refresh the current displayed system time. System’s time-zone could be configured at this page. Select Set Time Manually to set system time manually. -
Page 35: Chapter 6 Network Security
WEB Configuration Manual Chapter 6 Network Security 6.1 DOS Configuration 6.1.1 DOS Global Configuration Click Network Security -> DOS -> Global at navigation bar in order to enter DOS global configuration page as following: You could set or cancel the related Preventing DOS Attack according to needs. Click Set to save configuration. -
Page 36: Dhcp Snooping Vlan Configuration
WEB Configuration Manual Click Network Security -> DHCP Snooping -> Global at navigation bar in order to enter DHCP Snooping global configuration page as following: Enable global DHCP Snooping protocol to detect all DHCP messages. Relative binding relationships forms. If client obtains addresses by the switch before the command is configured previously, switch cannot add relative binding relationships. -
Page 37: Dhcp Snooping Interface Configuration
WEB Configuration Manual After the DHCP Snooping function is enabled on the VLAN, the DHCP messages received by all untrusted physical ports on the entire VLAN will be legally inspected. Any responded DHCP messages received by untrusted physical ports within a VLAN will be lost to prevent users from counterfeiting messages or prevent a mistaken DHCP server from assigning addresses. -
Page 38: Access Control List
WEB Configuration Manual For hosts that do not use DHCP to obtain addresses, users can manually add entries for binding at the switch ports to enable the host to smoothly access to the network. The “no” command can be used to delete the binding entries. Entries bound manually proceed over those bindings through dynamic configuration. -
Page 39: Mac Rules
WEB Configuration Manual Click Modify on this page, to configure the rules of corresponding IP Access Control list. Click Go Back on the IP Access Control List page to go back to IPv4 Rules’ Page. Click Delete to delete the access control list. 6.3.2 MAC Rules Click Network Security ->... -
Page 40: Filter Function
WEB Configuration Manual 6.4 Filter Function Click Network Security -> Filter Function at navigation bar in order to enter the filter function global page as following: Click Set at the bottom control bar to finish the global configuration of filter function. Click Reload at the bottom control bar to refresh the global configuration of filter function. - Page 41 WEB Configuration Manual Click Set at the bottom control bar, to finish the configuration of port. Click Reload at the bottom control bar, refresh the port configuration of filter function. - 35 -...
-
Page 42: Chapter 7 Switching
WEB Configuration Manual Chapter 7 Switching 7.1 Storm Control Click Switching -> Storm Control at navigation bar in order to enter broadcast storm control, multicast storm control and unicast storm control configuration pages. 7.1.1 Broadcast Storm Control Through the dropdown boxes in the Status column, you can decide whether to enable broadcast storm control on a port. -
Page 43: Unicast Storm Control
WEB Configuration Manual Through the dropdown boxes in the Status column, you can decide whether to enable multicast storm control on a port. In the Threshold column you can enter the threshold value of the multicast packets. The legal threshold range for each port is given behind the threshold. 7.1.3 Unicast Storm Control Through the dropdown boxes in the Status column, you can decide whether to enable unicast storm control on a port. -
Page 44: Mac Address Table
WEB Configuration Manual Set rate-limit on ports receive speed and send speed of port at this page. By default all ports’ speed is not limited. Receive speed and send speed can be configured according to ratio or switch’s defined unit. 7.3 MAC Address Table Click Switching ->... -
Page 45: Igmp Snooping
WEB Configuration Manual Click “Aging Configuration” on the right of “Static MAC Address Table”, enter the aging configuration page: 7.4 IGMP Snooping 7.4.1 IGMP Snooping Configuration Click Switching -> IGMP Snooping, at navigation bar in order, and select “IGMP Snooping” tab page to enter IGMP Snooping configuration page as following: Whether switch forwarding unknown multicast, whether enabling IGMP-Snooping and whether taken as IGMP’s Querier can be configured at this page. -
Page 46: Igmp-Snooping Vlan
WEB Configuration Manual 7.4.2 IGMP-Snooping VLAN Click Switching -> IGMP Snooping, at navigation bar in order, and select “IGMP Snooping VLAN” tab page to enter IGMP Snooping VLAN configuration page as following: Click Modify, you can modify the member port, running status and immediate-leave of IGMP-Snooping VLAN. -
Page 47: Multicast List
WEB Configuration Manual On this page, the currently existing static multicast groups and port groups in each static multicast group are shown. Click Reload to refresh the contents in the list. 7.4.4 Multicast list Click Switching -> IGMP Snooping, at navigation bar in order, and select “Multicast List” tab page to enter multicast member list configuration page as following: The multicast groups in current network and ports’... -
Page 48: Vlan
WEB Configuration Manual 7.5 VLAN 7.5.1 VLAN configuration Click Switching -> VLAN, at navigation bar in order, and select “VLAN configuration” tab page to enter VLAN configuration page as following: Click Modify after VLAN entry to change VLAN name and the VLAN’s port feature. Select the check box before item and click Delete at the bottom control bar to delete the selected VLAN. -
Page 49: Vlan Batch Configuration
WEB Configuration Manual 7.5.2 VLAN Batch Configuration Click Switching -> VLAN, at navigation bar in order, and select “VLAN Batch Configuration” tab page to enter VLAN configuration page as following: Note: Before VLAN to be deleted, it should be added first. 7.5.3 Port VLAN Configuration Click Switching ->... -
Page 50: Gmrp
WEB Configuration Manual Note: VLAN-allowed and VLAN-untagged: Please add first before do delete operation. Please do not use Enter key. 7.6 GMRP 7.6.1 VLAN List Click Switching -> GMRP -> VLAN List at navigation bar in order, to enter port VLAN configuration page as following: - 44 -... -
Page 51: Port Configuration
WEB Configuration Manual This page shows the ID list information of GMRP VLAN. Click Reload at the bottom control bar to refresh the list. Click Create at the bottom control bar, create GMRP VLAN configuration. 7.6.2 Port Configuration Click Switching -> GMRP -> Port Configuration at navigation bar in order, to enter Port Configuration page as following: Click Set at the bottom control bar, finish the configuration. - Page 52 WEB Configuration Manual Click Switching -> GMRP -> Multicast List at navigation bar in order, to enter Multicast List page as following: This page shows the VLAN ID, multicast MAC address and member port information of GMRP multicast list. Click Reload at the bottom control bar, refresh the multicast list information. - 46 -...
-
Page 53: Chapter 8 Routing
WEB Configuration Manual Chapter 8 Routing 8.1 VLAN Interface and IP Address Configuration Click Routing -> VLAN Interface and IP Address at navigation bar in order, and then enter configuration page as following： Click Modify to enter relative VLAN interface items to do the modification. Click Create to create a new VLAN interface items. -
Page 54: Vrrp Configuration
WEB Configuration Manual Note ： Before setting the VLAN secondary IP address, you need to set the Primary IP Address first 。 8.2 VRRP Configuration Click Routing -> VRRP Configuration at navigation bar in order, and then enter VRRP List page as following: Click Reload at the bottom control bar, refresh VRRP list information. -
Page 55: Ip Express Forwarding
WEB Configuration Manual Click Set at the bottom control bar, finish the configuration of VRRP and other information. Click Go Back at the bottom control bar, back to the VRRP List Page. 8.3 IP Express Forwarding Click Routing -> IP Express Forwarding at navigation bar in order, and then enter IP Express Forwarding switch page as following: Click Set at the bottom control bar, to finish the setting of IP Express Forwarding. -
Page 56: Rip Configuration
WEB Configuration Manual Click Reload to refresh the static route information. Click Delete to delete the selected Static Route items. Click Create to create a new Static Route. Note: Only the Layer3 switches have the static route configuration page. 8.6 RIP Configuration 8.6.1 RIP Configuration Click Routing ->... -
Page 57: Rip Router Entries
WEB Configuration Manual 8.6.2 RIP Router Entries Click Routing -> RIP Configuration at navigation bar in order, and then click RIP Router Entries to enter RIP Router Entries configuration page as following： Enter the created RIP process ID, Click Set to enter the selected RIP Router Entries page. Click Create to create a new RIP Router Entries of selected RIP process. -
Page 58: Ospf Router Entries
WEB Configuration Manual 8.7.2 OSPF Router Entries Click Routing -> OSPF Configuration at navigation bar in order, and then click OSPF Router Entries to enter OSPF Router Entries configuration page as following: Enter the OSPF process ID which was created already, click Set to enter the selected OSPF Router Entries configuration page. -
Page 59: Chapter 9 Qos/Priority
WEB Configuration Manual Chapter 9 QoS/Priority 9.1 Global Click QoS/Priority -> Global at navigation bar in order, and then enter the global configuration page as following： You can do the setting of Schedule Policy, Default CoS Value and Trust Priority in the QoS Global page. -
Page 60: 802.1D/P Mapping
WEB Configuration Manual You can set the Port CoS value by port, and then click Set to save the changes. 9.3 802.1D/p Mapping Click QoS/Priority -> 802.1D/p Mapping at navigation bar in order, and then enter the configuration page as following: Click Set to save all 802.1D/p mapping configurations. -
Page 61: Queue Management
WEB Configuration Manual There are listed the 64 values of DSCP in the IP DSCP mapping page, you can set the mapping value per each DSCP. Click Clear and then clean all of the DSCP mapping configuration. Note: The number of table parameter may be different between different device model. 9.5 Queue Management Click QoS/Priority ->... -
Page 62: Chapter 10 Redundancy
WEB Configuration Manual Chapter 10 Redundancy 10.1 Link Aggregation Configuration 10.1.1 Port Aggregation Configuration Click Redundancy -> Link Aggregation at navigation bar in order, and then enter the link aggregation configuration port channel page as following: Click Modify to modify the member port and aggregation mode of the aggregation port. Click Create to create a new aggregation group. -
Page 63: Port Channel Global Loading Balance
WEB Configuration Manual An aggregation group is selectable when it is created but is not selectable when it is modified. When a member port exists on the aggregation port, you can choose the aggregation mode to be Static, LACP Active or LACP Passive. You can add or delete the aggregation group member port by buttons “<<”... -
Page 64: Link Backup Protocol Port Configuration
WEB Configuration Manual Click Modify on the right of the entry and configure the preemption mode and the preemption delay mode of the link backup group. The page lists current configured link backup group, including the preemption mode and the preemption delay mode. -
Page 65: Spanning Tree
WEB Configuration Manual Click Modify on the right of the entry and configure the link backup protocol of the port. The link backup group which has been configured to be primary port cannot be configured other port as the primary. In the same way, the link backup group which has been configured backup port cannot be configured other port as backup. - Page 66 WEB Configuration Manual You can configure the MST Global Revision Level in this page. Click Set to save configuration. 10.3.2.2 MST Instance Click Redundancy -> Spanning Tree -> MSTP at navigation bar in order, and then click the MST Instance to enter the configuration page as following: This page shows the VLAN Mapping, priority and etc.
-
Page 67: Spanning Tree Ports
WEB Configuration Manual 10.3.3 Spanning Tree Ports 10.3.3.1 Port Configuration Click Redundancy -> Spanning Tree -> Ports at navigation bar in order, and then click the Port Configuration to enter the configuration page as following: This page shows the protocol status, priority, path cost, edge port, RSTP ring, guard, BPDU guard and BPDU filter enabling status, which can be configured. - Page 68 WEB Configuration Manual This page shows the configuration of EAPS ring (ether-ring), including ring ID, node type, ring description, CONTROL VLAN, status, Hello Time, Fail Time, Pre Forward Time and primary and secondary port on the ring. Click Modify on the right, change the time, primary and secondary port configuration on the EAPS (ether-ring).
-
Page 69: Meaps
WEB Configuration Manual 10.5 MEAPS Click Redundancy -> MEAPS at navigation bar in order, and then enter the MEAPS list configuration page as following: The list displays the currently configured MEAPS ring, including the Domain ID、Ring ID、Ring Type、Control VLAN、Hello Time、Failed Time、Pre Forward Time and the Primary/Secondary Port on the ring. -
Page 70: Erps
WEB Configuration Manual 10.6 ERPS Click Redundancy -> ERPS at navigation bar in order, and then enter the ERPS list configuration page as following: This page shows the configured ERPS ring, including ring ID, control vlan, Ring-Node version, Ring-state, Signal Fail, WTR-time, guard time, send-time, primary and secondary port. Click Modify on the right of the list, configure the time and primary and secondary port. -
Page 71: Chapter 11 Diagnostics
WEB Configuration Manual Chapter 11 Diagnostics 11.1 System 11.1.1 System Information Click Diagnostics -> System -> System Information at navigation bar in order, and then enter the configuration page as following： - 65 -... -
Page 72: Report
WEB Configuration Manual The page lists the system information, state of redundancy protocol, port configuration, port statistics, user management port. Click Display More can check more information such as CPU utilization, task information and etc. 11.2 Report 11.2.1 Log Management Click Diagnostics ->... -
Page 73: Log Query
WEB Configuration Manual “Address of the system log server” textbox and select the log's grade in the “Grade of the system log information” dropdown box (grade 9 – debugging is the lowest grade of log). When enabling the log buffer was selected, the device will record the log information to the memory. -
Page 74: Error Packet Statistics
WEB Configuration Manual The page lists the port information, including the Receive Packets, Receive Bytes, Received Unicast Packets, Received Multicast Packets, Received Broadcast Packets …etc. 11.3.2 Error Packet Statistics Click Diagnostics -> Port -> Error Packet Statistics at navigation bar in order, and then enter the error packet statistics page as following: This page shows the communication data, including received discard, received error packets, FCS packets, Jabber packets, received oversize packets, received undersize packets, transmitted... -
Page 75: Cable Diagnosis
WEB Configuration Manual 11.3.4 Cable Diagnosis Click Diagnostics -> Port -> Cable Diagnosis at navigation bar in order, and then enter the configuration page as following： You can configure each port of cable diagnosis is enable or disable, and also can configure the diagnosis period. -
Page 76: Lldp Configuration
WEB Configuration Manual 11.4 LLDP Configuration 11.4.1 LLDP Basic Configuration Click Diagnostics -> LLDP -> Configuration at navigation bar in order, and then enter the basic configuration page of LLDP protocol as following： You can enable or disable the LLDP protocol. You cannot configure the LLDP protocol of the port when LLDP is disabled. - Page 77 WEB Configuration Manual Click Diagnostics -> LLDP -> Topology Discovery at navigation bar in order, and then enter the LLDP topology discovery and configuration page as following: The page lists the devices that have been found by this device. - 71 -...
-
Page 78: Chapter 12 Advanced
WEB Configuration Manual Chapter 12 Advanced 12.1 DHCP Server 12.1.1 DHCP Server Global Configuration Click Advanced -> DHCP Server -> Global at navigation bar in order, and then enter the DHCP server global configuration page as following: You can enable or disable the DHCP server feature in this page. The default value is 2 for Number of ICMP packets, ICMP timeout default value is 5 seconds. -
Page 79: Sflow
WEB Configuration Manual Click Create to create a new DHCP server pool, page as following: 12.2 SFlow 12.2.1 SFlow Global Configuration Click Advanced -> SFlow -> Configuration at navigation bar in order, and then click the Global tab page enter the SFlow global configuration page as following: You can configure the Agent IP address on this page, the default value of SFlow Version is 5, default value of Maximum Header Size is 20 (maximum number is 128). -
Page 80: Sflow Statistics
WEB Configuration Manual The page lists the port of SFlow enable/disable status, the default value of Egress/Ingress Sampling Rate is 500. You can configure the rate upon your requirement when it is setting to be enabled. 12.2.2 SFlow Statistics Click Advanced -> SFlow -> Statistics at navigation bar in order, and then click the Poller tab page enter the SFlow poller information page as following: Click Advanced ->... - Page 81 WEB Configuration Manual Chapter 13 Help 13.1 About Click Help -> About at navigation bar in order, enter the About page as following: The information will shown in this page which are included IOS version messages, company website, contact telephone and etc. --- End of File --- - 75 -...
