Owner's Manual
Instructions for Assembly, Testing, Operation, Servicing, and Storage
12V Plunger Pump: For use with non-potable liquids such as water-based
READ and UNDERSTAND the Owner's Manual completely before using this pump.
Assemble, test, and use only in accordance with the Owner's Manual instructions.
READ and FOLLOW chemical safety instructions. Pesticides are hazardous chemicals.
KNOW emergency procedures BEFORE handling chemicals. Pump leaks, bodily chemical
contact, poisoning, and spills require immediate response.
AVOID inhaling, ingesting, or coming into contact with any chemicals.
WEAR personal protective gear when operating, cleaning, and servicing the pump.
KEEP pump and spray materials away from children and pets. Pesticides are especially
toxic to them.
DO NOT TURN ON POWER to pump until ready to spray in order to avoid unintentional
spray release.
ALWAYS keep a fire extinguisher rated "ABC" nearby.
Improper use of the pump or handling of chemicals could result in serious injury or
illness to the operator or nearby persons/animals, or could cause damage to the
environment.
** This pump is recommended for use in spraying non-flammable liquids such as pesticides, water
for plants/trees or dust control, or water-based non-flammable sealants or stains for outdoor wood
surfaces. This pump should not be used to transfer any product intended for human consumption.
WE RECOMMEND THAT THE PUMP NOT BE USED FOR OTHER PURPOSES ONCE IT HAS
BEEN USED FOR SPRAYING PESTICIDES. Any chemical will leave some residual in the pump,
even after the pump has been properly cleaned. These residual chemicals can have unexpected
effects on future uses. For example, spraying water or other liquids that are contaminated with
residual pesticide may result in unforeseen hazards to plant or animal life.
used by people with reduced physical, sensory or mental capabilities or lack of experience and
knowledge.
Any Questions, Comments, Problems, or Parts Orders
Call Everflo Product Support 1-800-864-1649
EFHP-2000
ITEM NUMBER: EFHP-2000
SERIAL NUMBER: __________
agricultural pesticides and other liquids**
WARNING
This pump should not be
Advertisement
Table of Contents
Related Manuals for Everflo EFHP-2000
Summary of Contents for Everflo EFHP-2000
- Page 1 Any Questions, Comments, Problems, or Parts Orders Call Everflo Product Support 1-800-864-1649...
- Page 2 Hazard Signal Word Definitions...
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Summary of Important Safety Information ..................5 During Assembly During Operation General Chemical Safety Chemical Applicator Safety Chemical Accident Procedures Warning Label Location ........................7 Unpacking ............................. 8 Assembly ..............................9 Installation Step One: Mounting ........................ -
Page 4: Intended Use
For example, spraying water or other liquids that are contaminated with residual pesticide may result in unforeseen hazards to plant or animal life. Contact Everflo Product Support at 1-800-864-1649 for any questions about the appropriate use of the pump and/or optional accessories. -
Page 5: Summary Of Important Safety Information
Summary of Important Information WARNING Read and understand this owner’s manual completely before using the pump. Read each chemical label’s instructions before handling the chemical. Improper use of the pump or handling of chemicals could result in serious injury or illness for the operator or nearby persons/animals, or cause damage to the environment. -
Page 6: Chemical Accident Procedures
Summary of Important Information DO NOT EAT, DRINK, SMOKE, RUB YOUR EYES, or TOUCH YOUR BARE SKIN while handling chemicals and spraying. NEVER POINT A SPRAY GUN at people or animals. EXERCISE EXTRA CAUTION when spraying near areas accessible to children and pets. ... -
Page 7: Warning Label Location
Always make sure safety labels are in place and in good condition. If a safety label is missing or not legible, order new labels or unsafe operation could result. To order replacement safety labels, call Everflo Product Support at 1-800-864-1649. -
Page 8: Unpacking
Unpacking Closely inspect all contents in the shipping carton. If you have missing or damaged components, please contact Everflo Product Support at 1-800-864-1649 Plunger Pump Regulator Assembly P/N EFHP2000 Regulator: EF-792943 Quick Connect Plug (2) Quick Connect x 1/2” Hose barb (1) ¼”... -
Page 9: Assembly
Assembly Step 1 – Inlet Fitting Installation Tools Needed Flat blade Install (1) QC x 1/2” HB elbow fitting into the pump inlet port on the screwdriver bottom left side of the pump manifold. Install (1) QC x 1/2” HB elbow fitting into the pump inlet port on the bottom right side of the manifold. - Page 10 Assembly Tools Needed Step 2 – Plug or Optional Gauge Installation Wrench Install either the 1/4” MNPT Plug or Optional Gauge into the 1/4” FNPT port on the regulator. Use a wrench to thread the plug or gauge into the regulator port. Optional Gauge: 1/4”...
- Page 11 Assembly Step 3 – Regulator Installation Tools Needed Install the regulator into outlet port at the top right side of the Flat blade pump manifold. screwdriver Use flat blade screwdriver to remove QC clip from the pump before installing fitting. Snap QC clip back into pump after fitting is inserted.
- Page 12 Assembly Step 4 – Connect Inlet, Outlet, and Bypass Hoses Tools Needed Use a hose clamp (not provided) and connect a flexible hose (not Flat blade provided) to the regulator’s bypass port. The hose should return screwdriver to the pump’s water supply. See the Operation section of the manual for detailed information about the regulator’s bypass function.
-
Page 13: Installation
200psi (13.8bar) 1/2” (13mm) Inside diameter Inside diameter NOTE: Everflo does not recommend the use of metal fittings or rigid pipe to plumb the inlet/outlet ports. Standard plastic threaded fittings are available by calling Everflo Product Support at 1- 800-864-1649. ... -
Page 14: Step Three: Connect Pump To Vehicle Battery
) for wire lengths over 12 feet (3.6m). Do not exceed 25 feet (7.6m) of total wire length. A remote switch is included for temporarily shutting off the pump’s operation. Call Everflo Product Support at 1-800-864-1649 to order replacement remote switch Everflo Item #EF-794292. 3. Connect pump... -
Page 15: Step Four: Check And Test Completed Assembly
Installation (continued) 4. Disconnect AFTER EACH USE, disconnect power to the pump using the following after use procedure: Disconnect the vehicle battery ground wire. Disconnect the pump clamp with black wire from the negative (-) terminal of the battery. Disconnect the pump clamp with red wire from the positive (+) terminal of the battery. -
Page 16: Important Safety Information - Operation
Operation – Important Safety Information Now that you have completed and tested your assembly, there is some important safety and health information you need to know with regard to handling and spraying chemicals. WARNING Carefully read and make sure you understand the following safety information before using the pump. -
Page 17: Chemical Applicator Safety
Operation – Important Safety Information (continued) Chemical Application Safety: WARNING Caution must be used when spraying chemicals to avoid unsafe exposure to humans and the environment. Heed the warnings below and follow all instructions carefully. Before Spraying Pump prep. ALWAYS inspect and prepare the pump before use according to the directions provided in this manual. -
Page 18: Chemical Accident Procedures
Operation – Important Safety Information (continued) Chemical accident procedures: WARNING Before you use the pump, review the following information with regard to handling accidents. Chemical spills, pump leaks, personal contamination, and poisoning are accident situations which you may encounter. All require an immediate response – See instructions below. Pump leak In the event that the pump develops a leak while spraying chemicals, you must immediately stop spraying. - Page 19 Operation – Important Safety Information (continued) General procedures include: 1. Control the spill by stopping the source of the spill. If the source of the spill is a container leak, place the leaking container in a larger, watertight container. Keep unprotected people away from the spill site. 2.
-
Page 20: Preparing The Pump For Each Use
Be certain the pump materials will be compatible with the chemical being pumped. Everflo pumps are intended for intermittent or continuous duty when the proper operating criteria are met. If unsure of the chemical compatibility with the Everflo pump components or the motor’s intended design, please call... -
Page 21: Step One: Assess Wind Conditions And Clear Work Area
Operation – Using the Pump Step One: Assess wind conditions and clear work area. Before you decide to spray, you must determine whether wind conditions are suitable. You must also restrict access to the work area to ensure the safety of bystanders. WARNING Do not spray if wind speeds are greater than 4 MPH or if there are bystanders in the intended spray area. - Page 22 Operation – Using the Pump (continued) 4. Adjust -Rotate the pressure adjustment knob until the sprayer is running at the pressure as desired pressure. needed 1. Turn knob clockwise to increase pressure 2. Turn knob counter clockwise to decrease pressure Bypass line Pressure...
-
Page 23: Step Three: Clean Pump And Decontaminate After Use
Operation – Using the Pump (continued) 7. Discontinue If the pump becomes clogged or inoperative during use, discontinue use use if immediately. clogged or - DO NOT attempt to service while chemicals are in the pump and power is inoperative connected. - Page 24 Operation – Using the Pump (continued) 2. Unused Properly store or dispose of unused chemical: chemical a) If the unused pesticide is to be stored for future use: Store all unused pesticide in its original, or a suitably marked, container in a secure location out of the reach of children & animals. b) If remaining pesticide is to be disposed: Properly dispose of the remaining chemical and its container per the chemical manufacturer’s recommendation and according to local...
-
Page 25: Storage
Storage Prepare the pump for end-of-season storage by running RV antifreeze through the system. This will keep internal parts lubricated, protect against corrosion, and keep the unit from freezing. CAUTION The pump will be damaged if it freezes. Protect the pump from freezing during storage by following the instructions below. Preparing for storage: Pour RV antifreeze into the pump system. -
Page 26: Troubleshooting
Troubleshooting WARNING Before troubleshooting or attempting to service, read the following safety rules to avoid accidental exposure to chemical and also risk of electric shock. Note: A reserve, clean container capable of holding at least the volume of the entire pump system should be kept for use when the pump system needs to be emptied temporarily for repairs. - Page 27 Troubleshooting (continued) PROBLEM CAUSE SOLUTION Bad electrical connection Check battery connections Short in wires Check condition of wires Thermal protector activated Wait for motor to cool Pump will not turn on Fuse blown Replace fuse Faulty pressure switch Replace pressure switch assembly Faulty relay Replace relay Incorrect voltage...
-
Page 28: Specifications
The manufacturer reserves the right to make improvements in design and/or changes in specifications at any time without incurring any obligation to install them on units previously sold. Any Questions, Comments, Problems or Parts Orders Call Everflo Product Support 1-800-864-1649... -
Page 29: Accessories
Quick Attach x 3/4" Hose barb elbow barb elbow barb elbow Part # EF-QC-EL38 Part # EF-QC-EL12 Part # EF-QC-EL34 Pressure Gauge Tree Spray Gun Part # 2141GXB300 Part # SG-2200 Any Questions, Comments, Problems or Parts Orders Call Everflo Product Support 1-800-864-1649... -
Page 30: Parts Breakdown - Exploded View
Pump Exploded View – Rev A Ref# Part# Description EF-792954 Valve Assembly (4 Valves) EF-788929 Relay EF-792956 Motor Assembly EF-796511 Base Plate Assembly EF-793313 Pressure Switch Assembly EF-796610 Pump Head Assembly EF-792140 QC Clip EF-789160 QC Plug EF-794292 Remote Switch Assembly EF-793243 Replacement fuse... -
Page 31: Limited Warranty
Any costs incurred due to replacement or repair of items outside of a Everflo approved facility is the responsibility of the buyer and not covered under warranty. Everflo can supply you with the service center location in your area. - Page 32 Everflo A Brand of Valley Industries 180 Lake Ave N. Paynesville, MN 56362 Everflopump.com M796113_Rev. A...
