Innovatek IN-433B Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER's MANUAL
Mobile Video System
REL
BND
RESET
COMPACT
DIGITAL AUDIO
PAIR
AUX IN
MOTORIZED SLIDE DOWN AND
4.3 INCH
W
IDE
CAR DVD/VCD/CD/MP3 PLAYER WITH BLUETOOTH
AM/FM DIGITAL PLL TUNING RADIO
MPEG4 PLAYER
USB CONNECT
TV TUNER
IN-433B
VOL
CAR DVD/VCD/CD/MP3/MPEG4/TV PLAYER
DVD/RECEIVER CONTROL
DVD/RECEIVER CONTROL
MODE
REDIAL
MENU
LO/DX
OSD
BAND
TITLE/PBC
A/PS
VOL
VOL
SEL
SETUP
COLOR DIGITAL SCREEN TFT
MUTE
PLAY/PAUSE
STOP
ANGLE
MO/ST
PAIR
LOUD
EQ
CLK
ENTER
TOP
RPT
INT
1
2
3
RDM
5
6
4
7
8
9
+10
0
GOTO
DETACHABLE PANEL
MU
IR
COMPACT
DIGITAL VIDEO
EQ
SEL
MIC
CH 1-6
MOD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IN-433B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Innovatek IN-433B

Summary of Contents for Innovatek IN-433B

  • Page 1 IN-433B OWNER's MANUAL Mobile Video System RESET COMPACT DIGITAL VIDEO COMPACT DIGITAL AUDIO PAIR CH 1-6 AUX IN CAR DVD/VCD/CD/MP3/MPEG4/TV PLAYER DVD/RECEIVER CONTROL DVD/RECEIVER CONTROL MODE MUTE PLAY/PAUSE STOP ANGLE MO/ST REDIAL PAIR LOUD MENU LO/DX BAND ENTER TITLE/PBC A/PS...

  • Page 2: Table Of Contents

    CONTENTS Safety Information..................Disc Notes ....................Installation ....................Panel Angle Adjustment ................Electric Connection ..................Remote Control ..................Basic Operation ..................MP3/WMA/JPEG Disc Play ..............MPEG4 Player ..................AUX Operation ..................Scroll Caption Adjustment ................. Alternate Audio/video Source ..............Blue-tooth Operation ................

  • Page 3: Safety Information

    SAFETY INFORMATION CAUTION: THIS DVD PLAYER IS A CLASS I LASER PRODUCT. HOWEVER THIS DVD PLAYER USES A VISIBLE/INVISIBLE LASER BEAM WHICH COULD CAUSE . HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE DVD PLAYER CORRECTLY AS INSTRUCTED. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.DO NOT OPEN COVERS AND DO NOT...

  • Page 4: Disc Notes

    DISC NOTES Disc formats supported by this unusable) depending on your handle it player and conditions in the usage environment. Note these scratches are not an Audio and Video indication of any problem with the player. Disc size 12 cm Label side Audio and Video Disc size 12 cm...

  • Page 5: Installation

    INSTALLATION NOTES: Choose the mounting location where the unit will not interfere with the normal driving function of the driver. Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and the system work properly. Use only the parts included with the unit to ensure proper installation.
  • Page 6 INSTALLATION DASH BOARD HEX NUT METAL MOUNTING STRAP SPRING WASHER CONSOLE PLAIN WASHER SLIDE BRACKET TAPPING SCREW HOUSING HEX BOLT KEY PLATE PLASTIC COVER KEY PLATE If you want to take CHASSIS out of the SLIDE BRACKET HOUSING, first remove the PLASTIC COVER of the both sides away, then insert the two KEY PLATE into left and right side of chassis as above illustration.
  • Page 7 INSTALLATION How To Remove And Install The Front Panel When detaching or attaching the control panel, be careful not to damage the connectors on the back of the control panel and on the panel holder. Detaching The Front Panel Before detaching the control panel, be sure to turn off the power. 1).

  • Page 8: Panel Angle Adjustment

    PANEL ANGLE ADJUSTMENT CHANGING THE CONTROL PANEL ANGLE When you want to change the viewing angle of the operating unit to play, you can press the (angle)button repeatedly to select the desired angle as follows: Angle 1 Angle 2 Angle 4 Angle 3 Caution: Do not insert your finger behind the control panel.

  • Page 9: Electric Connection

    ELECTRIC CONNECTION WIRING CONNECTION MAIN UNIT (B+)12V WHITE REAR CAMERA SWITCH GREEN (B-)PARKING BRAKE TV ANT IN YELLOW REAR CAMERA INPUT AUX(optional) VIDEO IN YELLOW RCH IN RED ANTENNA CONNECTOR LCH IN WHITE RCA CABLE GREY SUBWOOFER VIDEO OUT 2 YELLOW IGNITION COAXIAL OUT BROWN SWITCH(B+)

  • Page 10: Remote Control

    REMOTE CONTROL DVD/RECEIVER CONTROL DVD/RECEIVER CONTROL MODE MUTE PLAY/PAUSE STOP MO/ST REDIAL ANGLE PAIR LOUD MENU LO/DX BAND ENTER TITLE/PBC A/PS SETUP GOTO Press it briefly to show / hide the clock, press longer to set the time. 1.CLK Press it to use the Bluetooth function , refer to the page 17 . 2.PAIR/ Press it to stop playback, press PLAY/PAUSE to resume playback .
  • Page 11 REMOTE CONTROL In TV mode, press it to ADD and DELETE channel . 24.SKIP In DISC mode, press it to reverse rapidly Numeric buttons. 25. 0 - 9 26.+10/ Tens digit select button, cooperatively used with numeric buttons. In Bluetooth menu, it serves as the button on your mobile handset.

  • Page 12: Basic Operation

    BASIC OPERATION RESET COMPACT DIGITAL VIDEO COMPACT DIGITAL AUDIO PAIR CH 1-6 AUX IN CAR DVD/VCD/CD/MP3/MPEG4/TV PLAYER 1.REL BUTTON Press the REL button to release the removable front panel. Refer to see page 6 (POWER On/Off)/MOD BUTTON Press it to switch the device ON, press and hold (approximately 2 seconds) to switch the device OFF .
  • Page 13 BASIC OPERATION . BAND BUTTON In RADIO mode, press the BAND button on the front panel or on the remote controller to select your desired radio band and word which band is selected will be displayed in the TFT . Press it to change the bands as below : For 3 Bands (Europe) For 2 Bands (Europe) For 2 Bands (USA)
  • Page 14 BASIC OPERATION /CH 1-6 BUTTON (RADIO PRESET) a). In Disc Playback Mode Press this button to pause playback, press it again to resume playback. b). In Radio Mode Press this button repeatedly to preset station. With this system a total of 30 stations can be stored in the memory .
  • Page 15 BASIC OPERATION 15. IR (infrared) Sensor for the remote control. 16. AUX IN SOCKET he operation of the AUX , please see page 16. 17. USB CONNECT LINE SOCKET The operation of the USB, please see page 19. 18. TFT Display (liquid crystal display) The operation of the TFT, please see page 18.

  • Page 16: Mp3/Wma/Jpeg Disc Play

    BASIC OPERATION d. In the state of DVD disc playing , long press the 3/INT button, the screen will display as follow (long press it again will release this mode.): SELECT DIGEST TYPE: TITLE DIGEST CHAPTER DIGEST TITLE INTERVAL CHAPTER INTERVAL 1).

  • Page 17: Mpeg4 Player

    BASIC OPERATION MPEG4 Disc Play MPEG4 disc is playing as the format 00:56 04:07 of FILE . For example: In stop mode , use on the Repeat one 001/001 remote control to select the item , then press ENTER button to confirm. MAY-AUG Pressing REPEAT button repeatedly can select three kinds of repeat play mode.

  • Page 18: Blue-Tooth Operation

    BASIC OPERATION BLUETOOTH CAR KIT USER MANUAL 1. “Pair” To Your Bluetooth Phone Prior to using the Car Kit for the fist time, you must pair it with a Bluetooth-enabled mobile handset. The following steps describes pairing the instruction for a typical Bluetooth- enabled mobile handset.

  • Page 19: Video Quality Adjustment

    BASIC OPERATION Adjust the Volume During conversation in progress, tune the Volume switch until you reach the desired volume level. Play MP3 music In Bluetooth menu, press MOD to select the “BT MUSIC”, you can play the MP3 from your mobile handset. (Note: please make sure it support the Bluetooth A2DP profile.) Note: a).

  • Page 20: Usb Operation

    BASIC OPERATION USB Operation On-Screen Display Function Following the diagram below, connect Press the OSD button during playback your USB device to the front panel to display the contents of the current USB port . If it is properly connected, disc on the screen.

  • Page 21: Multi-Audio Language Function

    BASIC OPERATION Notes: e.Press for the fifth time: - The language number is different The message on the screen will be according to the disc. cleared for SVCD and VCD. - Some discs only contain one subtitle C.Example for MP3: language.

  • Page 22: Setup

    SETUP GENERAL SETUP --- GENERAL PAGE --- DOLBY DOLBY -----General setup page---- -----General setup page---- TV Display TV Display Normal/PS Normal/LB Angle Mark Angle Mark Wide OSD Lang OSD Lang SPDIF/RAW Spdif Output Spdif Output Captions Captions Screen Saver Screen Saver Last Memory Last Memory Set TV Display Mode...
  • Page 23 SETUP DOLBY DOLBY -----General setup page---- -----General setup page---- TV Display TV Display Angle Mark Angle Mark OSD Lang Osd Lang SPDIF OFF Spdif Output Spdif Output SPDIF/RAW Captions Captions SPDIF/PCM Screen Saver Screen Saver Last Memory Last Memory Set Angle Mark Setup SPDIF ANGLE MARK DISPLAY SETUP 4.SPDIF OUTPUT...

  • Page 24: Speaker Setup

    SETUP SPEAKER SETUP DOLBY --- SPEAKER SETUP PAGE --- DOLBY -----General setup page---- TV Display -----Speaker Setup Page---- Angle Mark OSDLang DOWNMIX LT/RT Spdif Output STEREO Captions Screen Saver Set Downmix Mode Last Memory Screen Saver This is to activate the audio output from DOLBY AC3 5.1 DOWNMIX to 2 channel mode.

  • Page 25: Preferences Setup

    SETUP PREFERENCES SETUP --- PREFERENCES PAGE --- DOLBY DOLBY -----Preference Page---- -----Preference Page---- TV Type TV Type English AUTO Audio Audio French NTSC Subtitle Subtitle Spanish Disc Menu Disc Menu German Parental Parental Italian Password Password Portuguese Default Default Preferred Subtitle Language Set TV standard 1.TV TYPE SETUP 3.SUBTITLE LANGUAGE SETUP...

  • Page 26: Defaults Table

    SETUP DOLBY DOLBY -----Preference Page---- -----Preference Page---- 1KID SAF TV Type TV Type Audio Audio Subtitle Subtitle 4PG13 Disc Menu Disc Menu 5PGR Parental Parental Password Password 7NC 17 Default Default RESET 8 ADULT Load Fcatory Setting 7.DEFAULTS Set Parental Control Select reset to become factory initial 5.PARENTAL setting.

  • Page 27: Specifications

    SPECIFICATION Supply Voltage: 12V DC (11V-15V) Current Consumption: Less than10 A Signal System: Compositive video 1.0Vp-p 75 Discs Played: (1)DVD-VIDEO Disc 5"(12 cm) single-sided, single-layer 5"(12 cm) single-sided, double-layer (2)Compact Disc (CD-DA, VIDEO CD) 5"(12cm) disc TV System: NTSC/PAL TV Sensitivity: Audio Signal Output: 2ch&4ch line out Characteristics:...

  • Page 28: Trouble Shooting

    TROUBLE SHOOTING Before going through the check list, check wiring connection. If any of the problems persist after check list has been made, consult your nearest service dealer. SYMPTOM CAUSE SOLUTION If the power supply is properly connected to the car accessory The car ignition switch is terminal,switch the ignition key not on...
