CAUTION
!
Before use, thoroughly read MAXAIR
and available at www.maxair-systems.com).
Symbol Definitions
!
Warning, Caution, or Note
REF
Catalog Number
!
WARNING
Failure to follow User Instructions P/N 03521015 and the instructions
contained herein may be hazardous to the user's health.
Use only if package is received unopened and contents are
undamaged. If damage is noted, contact the shipper for replacement
or repair.
Prior to using any MAXAIR
®
familiar with the system's NIOSH approved configuration.
DO NOT use if any component is damaged. If any components are
damaged or contaminated and therefore unfit for safe and effective
use, they should be replaced immediately.
Only trained and experienced personnel who have read and
understand the User Instructions should use MAXAIR Products.
The institution using this product in any application is responsible
for determining the appropriateness of this equipment relative to
regulatory requirements. Bio-Medical Devices Intl, Inc. does not
recommend the appropriate systems for a particular institution or
facility.
Use only MAXAIR Systems/ NIOSH approved compatible
components.
NOT for use in atmospheres immediately dangerous to life or health
(IDLH), and atmospheres containing less than 19.5% oxygen, or
more than 25% oxygen.
Flammability Level I: fabric may burn if exposed to open flame.
Follow current local regulations governing biohazard waste to safely
dispose of single use MAXAIR Products.
If you need more information, contact your BMDI Sales
Representative, or call BMDI customer service at 1-800-443-3842.
User Instructions
®
2260-05SM
REF
01031435
P/N
Small-Medium
REF
2260-05ML
01031434
P/N
Medium-Large
P/N
NIOSH Number
System or component, be sure to be
CAPR
®
P/N 03521015 User Instruction (received with all CAPR Helmets
Intended Use
The MAXAIR CAPR Shroud Systems filter aerosolized and droplet
particulates when used with a MAXAIR CAPR Powered Air Purifying
Respirator (PAPR) Helmet and a Filter Cartridge.
Shrouds are designed for single use applications.
Standard CA-CAPR-36 System with 2260-05 DLC
Single Shroud
1. 2081-03 Helmet
(includes 2051-07 SnapOn
Cage removed, 2071-08 Liner,
2590-05 Power Cord)
4. 2500-36TSC Battery**
6. 2600-02 Battery Charger
*Alternate Filters include the 2180-05 Filter Cap and the 2166-10 Filter
Cartridge.
**Alternate Batteries include the 2500-37TSC.
Specifications
Materials
DLC Lens is PETG
DLC Cuff is Polyurethane
Shroud body is polypropylene
All MAXAIR components and disposables are latex free.
Recommended System Temperature Limits
Use/Handling: 0
Charging: 0
Storage: 0
Regulatory
NIOSH
DLC Single Shroud
1
4
5
7
2. 2167-10 Filter Cartridge*
3. 2061-08 Filter Cover Cap
5. 2000-76 Battery Belt
7. 2260-05 DLC Shroud
C to 54
C at a maximum 80% Relative Humidity.
o
0
C to 45
C at a maximum 80% Relative Humidity.
o
0
C to 35
C at a maximum 80% Relative Humidity.
o
0
2260-05
2
3
6
P/N 01023650 Rev C1 Page
1
Advertisement
Table of Contents
Related Manuals for Syntech MAX-AIR 2260-05SM
Summary of Contents for Syntech MAX-AIR 2260-05SM
- Page 1 User Instructions 2260-05 DLC Single Shroud CAUTION Before use, thoroughly read MAXAIR ® CAPR ® P/N 03521015 User Instruction (received with all CAPR Helmets and available at www.maxair-systems.com). Intended Use The MAXAIR CAPR Shroud Systems filter aerosolized and droplet particulates when used with a MAXAIR CAPR Powered Air Purifying Respirator (PAPR) Helmet and a Filter Cartridge.
- Page 2 User Instructions 2260-05 DLC Single Shroud WARNING WARNING Ensure that a Filter Cartridge and the Filter Cover Start with the ML size for medium to large head Cap are properly installed. sizes; the SM is for very small head sizes. Assembly to Helmet 1.Remove Shroud from package; 2. Grasp top of DLC Cuff and pull 3. Turn front TurnClip horizontal, attach the note Shroud is turned inside- gently outward so that Cuff and Shroud front Mounting Hole onto the TurnClip, out to mount to Helmet. Flappers are away from Lens.
- Page 3 User Instructions 2260-05 DLC Single Shroud 10. Use Pull Tap to position Shroud Rear Snap 11. Snap and secure left Rear Side Snaps between Shroud over FCC Rear Snap; snap and secure. and FCC. Then repeat on right Rear Side Snaps. Disassembly WARNING Reverse Assembly steps to remove Shroud from Helmet. Dispose of contaminated Shrouds according to your Institution’s protocols. Donning 1. Assemble Battery onto Belt - Place top 3.
- Page 4 User Instructions 2260-05 DLC Single Shroud 8. Continue pulling Shroud 9. Don outer body gown 10. Pull neck ties around to front, tie securely, down all around. under the shoud per gown leave about a ½ inch gap between neck and manufacturer’s instructions. Shroud. Pull waist ties around and tie in front. Doffing WARNING Discard ties, Shroud, and body 4. Doff the outer gown per body gown per Institutional manufacturer’s protocol for instructions. contaminated waste. 1. Untie and remove 2. Roll the Shroud up from the back, 3.
