B1 AND B2
USER'S GUIDE
Form 1574-060807 — August 2006
43044 Business Park Drive, Temecula, CA 92590-3614
Phone: 800-321-OPTO (6786) or 951-695-3000
Fax: 800-832-OPTO (6786) or 951-695-2712
www.opto22.com
Product Support Services
800-TEK-OPTO (835-6786) or 951-695-3080
Fax: 951-695-3017
E-mail: support@opto22.com
Web: support.opto22.com

Advertisement

Table of Contents
loading

Related Manuals for OPTO 22 Optomux B1

Summary of Contents for OPTO 22 Optomux B1

  • Page 1 B1 AND B2 USER’S GUIDE Form 1574-060807 — August 2006 43044 Business Park Drive, Temecula, CA 92590-3614 Phone: 800-321-OPTO (6786) or 951-695-3000 Fax: 800-832-OPTO (6786) or 951-695-2712 www.opto22.com Product Support Services 800-TEK-OPTO (835-6786) or 951-695-3080 Fax: 951-695-3017 E-mail: support@opto22.com Web: support.opto22.com...
  • Page 2 Specifications are subject to change without notice. Opto 22 warrants all of its products to be free from defects in material or workmanship for 30 months from the manufacturing date code. This warranty is limited to the original cost of the unit only and does not cover installation, labor, or any other contingent costs.

  • Page 3: Table Of Contents

    Table of Contents Welcome....................5 Overview..........................5 What’s In This Guide?....................... 6 Document Conventions....................6 Chapter 1: Introduction ................7 About Optomux ......................... 7 System Confi guration ...................... 8 Physical Layout......................8 Communications ......................8 Modular Construction....................8 Wiring .......................... 9 Data Transmission...................... 9 System Throughput....................
  • Page 4 Chapter 2: Installation and Wiring ..........13 Physical Installation......................13 Mounting ........................13 Communications Wiring ....................14 Host to First Optomux Unit ..................14 Unit to Unit .......................15 Installing Digital I/O Modules................16 Installing Analog I/O Modules ................17 Power Re quire ments.......................18 Connecting the Power Supply ................18 Third-Party Power Supply Vendors ................20 Brain Board Mount ing ....................

  • Page 5: Welcome

    E2s can communicate over both serial and Ethernet networks using Optomux, and simultaneously communicate using Modbus/TCP and the OptoMMP memory-mapped protocol over Ethernet. In addition, E1s and E2s can be used with Opto 22’s ioProject software suite. See form #1546, the E1 and E2 Data Sheet , for more information.

  • Page 6: What's In This Guide

    Appendix A, “Surge Protection For RS-422/485 Communication Links” Appendix B, “Troubleshooting Questions and Answers” “Product Support”—information on how to get help from Opto 22. Document Conventions • Bold typeface indicates text to be typed. Unless otherwise noted, such text may be entered in upper or lower case.

  • Page 7: Chapter 1: Introduction

    CHAPTER 1 Introduction About Optomux Optomux is a protocol used by a family of intelligent digital and analog I/O (input/output) units that operate as slave devices to a host computer. An Optomux I/O unit is a 4-, 8-, or 16-point assembly that accommodates optically-isolated analog or digital I/O modules.

  • Page 8: System Confi Guration

    CHAPTER 1: INTRODUCTION System Confi guration Physical Layout The high cost of electrical wiring and the noise susceptibility of analog signals make it desirable to place thecontrol or monitoring point as close to the controlled deviceas possible. Optomux offers design fl exibility, with as few as 4 points or as many as 4,096 points in one physical location.

  • Page 9: Wiring

    CHAPTER 1: INTRODUCTION Wiring Inputs and outputs are connected to the Optomux mounting rack via an industrial barrier strip with integral cable clamp for each terminal. Spade lugs, other wire terminations, bare wires, and tinned wires are all readily accepted. Serial link connections and power connections are also made via screw terminals. Data Transmission Optomux supports 8 baud rates (300, 600, 1,200, 2,400, 4,800, 9,600, 19.2K, and 38.4K) which are selectable via jumpers located on the Optomux unit.

  • Page 10: Features

    CHAPTER 1: INTRODUCTION Reading the values of 16 analog inputs on an analog Optomux unit requires a total of 79 command/response characters. The command sent by the host consists of 11 characters; the response from Optomux consists of 68 characters. If we assume a response time of 7 milliseconds, the following table shows system throughput based upon reading all 16 positions per transaction.

  • Page 11: Time Delays

    CHAPTER 1: INTRODUCTION Time Delays Any or all output positions can function in time delay mode. Outputs can be set to operate with four types of delays. • Delay before turning OFF • Delay before turning ON • Pulse ON •...

  • Page 12: High/Low Value Recording

    CHAPTER 1: INTRODUCTION High/Low Value Recording The B2 can be instructed to remember the highest and lowest readings at input positions for recall by the host computer. Gain and Offset Calculation The B2 can be instructed to calculate and set offsets and gain coeffi cients for input positions allowing for easy calibration under software control.

  • Page 13: Chapter 2: Installation And Wiring

    CHAPTER 2 Installation and Wiring Physical Installation Mounting The B1 or B2 Optomux unit can be mounted in any attitude on any fl at surface. The mounting rack and removable brain board portion of the Optomux unit are supplied with permanently-attached standoffs. All of the standoffs should be secured for maximum phys i cal strength.

  • Page 14: Communications Wiring

    CHAPTER 2: INSTALLATION AND WIRING Communications Wiring A complete data link con nec tion at each Optomux unit (except the last in a string) consists of 10 wires: two twisted pairs (4 wires) and a common coming from the computer or pre vi ous Optomux unit, and two twisted pairs and a common going to the next Optomux unit.

  • Page 15: Unit To Unit

    CHAPTER 2: INSTALLATION AND WIRING Unit to Unit The fol low ing fi gure shows the con nec tion between adjacent Optomux units on the serial link. The Optomux unit at the end of the data link has only 5 wires — “To Host,” “From Host,” and common. HINT: Always think of the previous Optomux unit as the host.

  • Page 16: Installing Digital I/O Modules

    CHAPTER 2: INSTALLATION AND WIRING Installing Digital I/O Modules CAUTION: Be sure that all Optomux unit power and power to the controlled devices is removed before installing or removing I/O modules. Each position on a digital mount ing rack can accept either input or output modules.

  • Page 17: Installing Analog I/O Modules

    + 24V 15V -15V -15V LOOP SUPPLY FUSE (OPTIONAL) OPTO 22 OPTO 22 PB16AH COMMUNICATIONS WIRING D O N O T C H A N G E M O D U L E S W I T H P O W E R A P P L I E D...

  • Page 18: Power Re Quire Ments

    If an Opto 22 PBSA/B/C power supply is used with the digital racks, the + 5 VDC log ic connection is made by the supply when it is screwed to the rack. In this case, the only connection to be made is the 120 VAC (220 VAC or 10-28 VDC de pend ing on supply type) connection to the PBSA (PBSB or PBSC) supply.
  • Page 19 CHAPTER 2: INSTALLATION AND WIRING Use a consistent color code from power supply to all Optomux units to prevent wiring errors. Size 18 AWG is recommended for power supply wiring. Optomux demo equip ment uses the following colors: • +5 Volts •...

  • Page 20: Third-Party Power Supply Vendors

    CHAPTER 2: INSTALLATION AND WIRING Third-Party Power Supply Vendors The fol low ing is a list of a few of the many power supply vendors: COMPUTER PROD UCTS INC. Power Conversion Group 2900 Gateway Dr. Pompano Beach, FL 33069 (305) 974-5500 ELPAC POWER SYS TEMS 3131 S.

  • Page 21: Brain Board Mount Ing

    CHAPTER 2: INSTALLATION AND WIRING Brain Board Mount ing The brain board mates with the header connector on the rack. The orientation of the digital brain board (B1) should be such that the brain board extends away from the rack. The ori en ta tion of the analog brain board (B2) is such that the brain board covers up the communications and power wiring on the an a log rack when it is plugged in.

  • Page 22: Selecting The Jump Ers

    CHAPTER 2: INSTALLATION AND WIRING Selecting the Jump ers TIP: Use the “OptoScan” utility as an aid in setting jumpers. There are two groups of jumpers lo cat ed on each B1 or B2 brain board. The jumpers are labeled Group A and Group B.
  • Page 23 CHAPTER 2: INSTALLATION AND WIRING Baud Rate Se lec tion Jumpers B8, B9, and B11 select the baud rate. Possible confi gurations are shown be low. Table 2-1: Baud Rate Jumper Settings Baud Rate Not Installed Not Installed Not Installed Not Installed Not Installed Installed...
  • Page 24 CHAPTER 2: INSTALLATION AND WIRING Figure 2-7: Jumper Addresses 24 24 24 24 24 B1 & B2 User’s Guide...

  • Page 25: Accessories

    There are several ac ces so ries for the Optomux family, ranging from power supplies to adapter cards. Several are listed be low. Please refer to the Opto 22 Web site (www.opto22.com) for detailed in for ma tion on the following products.
  • Page 26 CHAPTER 2: INSTALLATION AND WIRING 26 B1 & B2 User’s Guide...

  • Page 27: Surge Protection For Rs-422/485 Communication Links

    Appendix A Surge Protection For RS-422/485 Communication Links For more information or for catalog requests, contact: Phoenix Contact Inc. P.O Box 4100 Harrisburg, PA 17111-0100 E-mail: info@phoenixcon.com Phone: (717) 944-1300 Fax: (717) 944-1625 Fax-on-demand: (800) 944-9901 B1 & B2 User’s Guide 27...
  • Page 28 APPENDIX C 28 B1 & B2 User’s Guide...

  • Page 29: Troubleshooting Questions And Answers

    Appendix B Troubleshooting Questions and Answers Q. I send a command to turn on output 5 of an Optomux unit at address 255, and output 4 goes on. A. Module positions are numbered from 0 to 15. Therefore the fi fth bit in the bitmask is for position labeled 4.
  • Page 30 APPENDIX D Q. I send a command to activate several outputs. The Optomux unit responds with no error, but none of my outputs come on. A. If an output does not turn on, check the following: 1. Make sure you confi gured the outputs of the Optomux unit correctly. The unit defaults to all positions confi...
  • Page 31 APPENDIX D Q. When I read position 3 of an Optomux analog board, I receive a 0000, which converts to a decimal -4,096 value when I subtract the 1,000 hex offset. A. A -4,096 decimal reading may indicate one of the following: 1.
  • Page 32 APPENDIX D 32 B1 & B2 User’s Guide...

  • Page 33: Product Support

    Product Support If you have any questions about this product, contact Opto 22 Product Support Monday through Friday, 7 a.m. to 5 p.m. Pacifi c Time. Phone: 800-TEK-OPTO (835-6786) 951-695-3080 Fax: 951-695-3017 Email: support@opto22.com Opto 22 Web site: support.opto22.com When calling for technical support, be prepared to provide the following information about your system to the Product Support engineer: •...
  • Page 34 34 B1 & B2 User’s Guide...
