  • Page 1 USER MANUAL...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SPECIFICATIONS – pg. 3 MACHINE DIAGRAM – pg. 4 iii. ASSEMBLY INSTRUCTIONS – pg. 6 INSTALLATION INSTRUCTIONS – pg. 7 QUICK START INSTRUCTIONS a. CALIBRATION – pg. 8 b. AIRFLOW SETTING – pg. 9 FILTER REPLACEMENT INSTRUCTIONS a.

  • Page 4: Specifications

    SPECIFICATIONS Micro Voltage 120V Frequency (Hz) 50 / 60 Wattage (kW) Blower Type 1x Brushless Length (mm/inches) 432/17 Width (mm/inches) 254/10 Height (mm/inches) 660/26 Weight (Kg/Lbs) 36.3/80 Pressure: inH2O 80 (High Pressure) Construction Steel Design Independent Filters Operating Decibels Display/Control...

  • Page 5: Machine Diagram

    MACHINE DIAGRAM...
  • Page 6 MACHINE DIAGRAM – USER INTERFACE...

  • Page 7: Assembly Instructions

    3. Flex Hose 4” with Hose Clamp a. Specific hose adapters may also be provided The Filtrabox Micro is packaged without the Threaded Inlet to protect it in shipping. Follow the Installation Instructions on the next page to get started.

  • Page 8: Installation Instructions

    Calibration as the system will take all the bends and flow restrictions of the flex hose into account and provide optimal performance. 5. Install the supplied power cord onto the back of the Filtrabox Micro and turn it on with the Main Power Switch located to the right of the User Interface.

  • Page 9: Quick Start Instructions

    ! Failure to calibrate the device prior to usage may significantly reduce the life of your filters. 1. Hook up the Filtrabox fume extractor to the Laser Engraver, with the supplied hose or with the hose you intend to permanently use for the application. Arrange the laser, Filtrabox and the hoses into their desired locations.

  • Page 10: Airflow Setting

    This ensures that you are using your filters to their maximum potential which minimizes costs. ! USEFUL TIP 2: Start by setting your Filtrabox at 35% for a small sized laser and incrementally increase, using the 4-6 second rule to determine the minimum adequate evacuation setting.
  • Page 11 Note: “Airflow %” represents the Airflow potential of your system. ! If the AIRFLOW% setting is greater than 90%, the Filtrabox display will change color and show a “REDUCE FLOW RECOMM.” This is because if the machine is used past 90%, filter life will be severely reduced, please contact Filtrabox if your laser setup requires very high flow settings.

  • Page 12: Filter Replacement Instructions

    This is most likely due to airflow blockage in the Pre-filter or HEPA filter from normal usage. The Filtrabox Micro system has 3 types of filters; Pre-Filter, HEPA filter and Gas Filter. 1. Pre-Filter FIL-P-MC-426: Collects Fine Dust 2.

  • Page 13: Filter Check Feature

    2. Press the OK button to initiate the “CHECK FILTER” process; follow the prompts on screen. 3. Filtrabox will first assess the status of the Pre-Filter, the machine will then display a prompt to remove the Pre-Filter (refer to image below).

  • Page 14: Replacing The Dust Pre-Filter

    ! Important Note: The Filter Alignment Rings must be centered correctly into each filter. They should fit inside both filters when installed correctly. ! To avoid any risk of electrical discharge, turn off and unplug the Filtrabox before doing any activities that require disassembly of the unit.

  • Page 15: Replacing The Oxy-Carbon Gas Filter

    ! Important Note: The Filter Alignment Rings must be centered correctly into each filter. They should fit inside both filters when installed correctly. ! To avoid any risk of electrical discharge, turn off and unplug the Filtrabox before doing any activities that require disassembly of the unit.

  • Page 16: Menus

    (reduce or increase) the airflow restrictions in the entire system. SERVICE MENU SETTING This menu is only to be used by Filtrabox Technicians or with the guidance of a Filtrabox Technician.

  • Page 17: Support

    SUPPORT For any and all questions related to our Filtrabox products and accessories, please do contact us anytime. It will be our pleasure to make fume extraction easier and more effective for any of your applications. Please contact us through: info@filtrabox.com...

  • Page 18: Warranty

    WARRANTY 1 Goods manufactured by PAT: PAT warrants that the Goods manufactured by it will be free from defects in materials and workmanship for a period of 12 months from the date of item receipt. Exceptions: Spare parts including replacement filters: 1 month from installation. Used and ex-demonstration equipment: 1 month from installation.
