36-Volt Cordless Lawn Mower
H36GC16A, H36GC16B & H36GC16C& A36GC16B01
OPERATOR'S MANUAL
Ningbo AOSHENG Machine Co., Ltd
No.77 West Nantang Road, Linshan
Industrial Park, 315462, Yuyao City,
Zhejiang , P.R. China
Tel: 0574-62078293 Fax:0574-62037800
WARNING:
instructions carefully before operating this tool.
Improper use can cause serious or fatal injury.
Original Instructions
Read all safety rules and
Advertisement
Table of Contents
Related Manuals for HENX H36GC16A
Summary of Contents for HENX H36GC16A
- Page 1 36-Volt Cordless Lawn Mower H36GC16A, H36GC16B & H36GC16C& A36GC16B01 OPERATOR’S MANUAL Original Instructions Ningbo AOSHENG Machine Co., Ltd No.77 West Nantang Road, Linshan Industrial Park, 315462, Yuyao City, Zhejiang , P.R. China Tel: 0574-62078293 Fax:0574-62037800 WARNING: Read all safety rules and instructions carefully before operating this tool.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Symbols ............................3 Safety Instructions........................4-5 Safety Rules for Cordless Lawn Mower ....................6-9 Specifications ........................... 10-11 Assembly ..............................11 Description ..........................12-13 Operation ..............................14-24 Maintenance ..........................25-33 Troubleshooting ........................34-35 Warranty ..............................36 Parts List.............................. 37-39 IMPORTANT Read and understand this manual before assembling or operating this appliance. - Page 3 Safety Alert Indicates a potential personal injury hazard. Always wear safety goggles or safety glasses with side shields and a Eye Protection full face shield when operating this product. To reduce the risk of injury, user must read and understand operator’s Read Operator’s Manual manual before using this product.
- Page 4 This product complies with applicable EC directives. This product uses lithium-ion (Li-ion) batteries. Local, state, or federal laws may prohibit disposal of batteries in ordinary trash. Consult your Recycle Symbols local waste authority for information regarding available recycling and/or disposal options. Do not expose to rain Do not expose to rain.
-
Page 5: Safety Instructions
Direct Current Type or a characteristic of current No Load Speed Rotational speed, at no load ... /min Per Minute Revolutions per minute WARNING: To ensure safety and reliability, all repairs should be performed by a qualified service technician. SAFETY INSTRUCTIONS WARNING: Read these instructions carefully, be familiar with the controls and the proper use of the machine. - Page 6 12) Keep hands and feet away from cutting area. 13) Objects struck by the lawn mower blade can cause severe injuries to persons. The lawn should always be carefully examined and cleared of all objects prior to each mowing. 14) If lawn mower strikes a foreign object, follow these steps: i) Stop lawn mower.
- Page 7 ◼ Before using, always visually inspect to see that the blades, blade bolts and cutter assembly are not worn or damaged. Replace worn or damaged blades and bolts in sets to preserve balance. ◼ Mow only in daylight or in good artificial light. ◼...
- Page 8 Never operate the mower with damaged safety devices. Failure to do so can result in personal injury. ◼ If situations occur that are not covered in this manual, use care and good judgment. Contact HENX Customer Service for assistance. ◼...
- Page 9 H36MC100(XVE129- H36B25, H36B50 or H36GC16B 4200300) H36B75(1pc) H36KC400 H36MC100(XVE129- H36B25, H36B50 or H36GC16C 4200300) H36B75(1pc) H36KC400 A40KC250B01, A36B50B01 A36GC16B01 A36MC75B01 OPERATION ON A SLOPE: Slopes are a major factor related to slip-and-fall accidents, which can result in severe injury. Operation on slopes requires extra caution.
- Page 10 ◼ Check the blade and motor mounting bolts at frequent intervals for proper tightness. Also, visually inspect the blade for damage (e.g., bending, cracking and wear.). Replace the blade only with the identical replacement blade, as listed in this manual. Maintain your mower with care –...
-
Page 11: Specifications
Should you experience any problem you cannot easily remedy, please contact HENX customer service center 86 571-87248935. This manual contains important information on the safe assembly, operation and maintenance of your mower. Read it carefully before using the mower. -
Page 12: Assembly
Charger (model) H36KC400 A40MC75B01 H20KC40 Input 120-240VAC 50/60Hz, 100-240VAC 50/60Hz 120-240VAC 50/60Hz 75 W 400W Output 21Vdc/2.3A 40VDC, 8A 40VDC 1.8A Allowable charge 0-40°C 0 - 40 °C 4-40°C temperature range Charger (model) H20MC10 XVE129-4200300 A40KC250B01 Input 100-240Vac 50/60Hz 100-240VAC, 50/60Hz, 2.5A Max;... -
Page 13: Description
LIST OF CONTENTS PART NAME QUANTITY Lawn mower Grass bag Grass bag frame Side Discharge Chute Operator’s manual DESCRIPTION Safety button control panel high/low on/off button Speed button side rail Handle-locking clamp power indicator battery-pack cover grass bag quick-adjustment lever front wheel rear wheel cutting height... - Page 14 On/off switch Quick- adjustment lever(upper) high/low speed button wire clamp rear discharge door Quick-adjustment lever (lower) grass bag Battery-pack cover power indicator cutting height front wheel adjustment lever Model:H36GC16A, H36GC16B & A36GC16B01 side discharge chute(available separately) rear discharge door...
- Page 15 dual-battery port battery release button Single-battery port The safe use of this product requires an understanding of the information on the tool and in this operator’s WARNING: manual, as well as knowledge of the project you are attempting. Before use of this product, familiarize yourself with all operating features and safety rules.
-
Page 16: Operation
OPERATION ADJUSTING THE HEIGHT OF HANDLE(H40GC16A&H40GC16B&A40GC16B01) Quick-adjustment lever(lower) WARNING: Do not attempt to start the mower until the handle has been Quick-adjustment lever(upper) locked at one of the three preset operating positions (lower/middle/higher). 1. LOCKED STORAGE POSITION: Your mower is shipped with the upper and the lower side rails in the compact, locked position (Fig. - Page 17 ADJUSTING THE HEIGHT OF HANDLE(H36GC16C) WARNING: Do not attempt to start the mower until the handle has been locked at one of the three preset operating positions(lower/middle/higher). LOCKED STORAGE POSITION: Your mower is shipped with the handle in the compact, locked position (Fig. 1). EXTEND THE SIDE RAILS: move the side rails to the back of mower, release the handle-locking clamps(see Fig.3) and then fully extend the upper side rails by stretching them out (see Fig.2) before any operation.
- Page 18 ATTACHING/REMOVING THE SIDE DISCHARGE CHUTE(available separately) (Fig. 5a & 5b) WARNING: Do not at any time make any adjustment to the lawn mower without first stopping the motor, removing the battery pack and waiting for the blade to stop rotating. 1.
- Page 19 TO ATTACH/DETACH THE BATTERY PACK (Fig. 7 &8) CHARGE BEFORE FIRST USE. H36GC16A battery release button WARNING: If any parts are broken or missing, do not attempt to attach the battery pack to the mower or operate the mower until the broken or missing parts are replaced.
- Page 20 STARTING/STOPPING THE MOWER (Fig. 9 & 10)（H36GC16A&H36GC16B&A36GC16B01) The operation of any lawn mower can result in foreign objects being thrown into your or others’ eyes, which can WARNING: damage eyes severely. Always wear safety glasses while operating the mower or while performing any adjustments or repairs on the mower.
- Page 21 STARTING/STOPPING THE MOWER(Figure11,12&13) (H36GC16C) WARNING: The operation of any lawn mower can result in foreign objects being thrown into your or others’ eyes, which can damage eyes severely. Always wear safety glasses while operating the mower or while performing any adjustments or repairs on the mower. Ensure that other people and pets remain at least 100’...
- Page 22 MOWER OVERLOAD PROTECTION To prevent overload conditions, do not try to remove too much grass at one time. Slow down your cutting pace or raise the cut height. Your mower has built-in overload circuit protection. When the mower is overloaded, the motor will stop and the power indicator on the mower will flash red.
- Page 23 Sight and hold the line level with a vertical tree… Sight and hold the line level with a pole… or a corner of a building… or a fence post...
-
Page 24: Maintenance
MAINTENANCE WARNING: To avoid serious personal injury, always remove the battery pack from the mower before cleaning or performing any maintenance. WARNING: When servicing, use only identical replacement parts. Use of any other parts may create a hazard or cause product damage. - Page 25 A worn or damaged blade can break, causing blade pieces to be thrown from the mower. If the blades are found to be bent, take the lawn mower to an authorized HENX service center for inspection.
- Page 26 SHARPING FREQUENCY Sharpening the blade twice during a mowing season is usually sufficient under normal circumstances. Sand causes the blade to dull quickly; if your lawn has sandy soil, more frequent sharpening may be required. WHEN SHARPENING THE BLADE: ◼ Make sure that the blade remains balanced.
- Page 27 LUBRICATION Lubricate with light oil as directed below at least once each season. Periodically lubricate the torsion spring and pivot of the rear-discharge door with light oil to prevent rust (Fig. 21). pivot ◼ Place the mower into the locked storage position: 1.
- Page 28 REPLACING THE WHEELS (Fig. 23a &23b ) WARNING: Always remove the battery pack when servicing or transporting the mower. 1. Turn the mower over on its side and lean the upper surface against the wall 2. Use a flat-edged screwdriver to pry the dust cover off the wheels. 3.
- Page 29 STORING THE MOWER The following steps should be taken in order to prepare the lawn mower for storage. 1. Remove the battery pack from the mower and store it at room temperature in a dry location. 2. Clean the mower as described earlier in the maintenance section. 3.
-
Page 30: Troubleshooting
TROUBLESHOOTING WARNING: Always remove the battery pack when servicing or transporting the mower. Always protect your hands by wearing heavy gloves or wrapping the cutting edges with rags or other materials when performing any maintenance on the mower blade. Problem Cause Solution ◼... - Page 31 Problem Cause Solution ◼ Wet grass clippings are sticking to the ◼ Wait until the grass dries before mowing. The mower does not mulch underside of the deck. ◼ Raise the deck to a higher cutting height ◼ properly The mower is set to cut too much grass at setting.
-
Page 32: Warranty
YEARS from the date of original retail purchase, this HENX product is warranted against defects in material or workmanship. Defective product will receive free repair. FOR ONE YEAR from the date of original retail purchase, the HENX battery pack and charger are warranted against defects in material or workmanship. Defective product will receive free repair. -
Page 33: Parts List
PARTS LIST 40V LITHIUM-ION CORDLESS LAWN MOWER MODEL NUMBER The Model Number will be found on the Nameplate attached to the rear-discharge door of the lawn mower. Always mention the Model Number when ordering parts for this tool. EXPLODED DRAWING... - Page 34 PARTS LIST Part Name Quantity Grass Bag Side Discharge Chute Quick-adjustment lever(upper) Quick-adjustment lever(lower) Rear Hubcap Rear Wheel Assembly Blade adapter Blade Flat washer Spring washer Hexagon bolt Front Hubcap Front Wheel Assembly Height-Adjustment Lever External circlip Flat washer Wire clamp To comply with European Directive 2012/19/EU concerning old electric and electronic equipment and its implementation in national laws, old electric power tools have to be separated from other waste and disposed of in an environment-friendly fashion, e.g.
- Page 35 Cordless lawn mower commercial name: Cordless lawn mower function: cut grasses or weeds on lawns, gardens and pastures and turn recycled dry grass into forage model: H36GC16A / H36GC16B / H36GC16C/A40GC16B01 type: Battery powered serial number: N/A fulfils all the relevant provisions of Directives...
