Operation manual / Spare parts list
Single disc machines
Operation manual
Single disc machines
Model overview
Model
Working power
Rotation
Working width
RO-1800
RO-2200
1 800 W
2 500 W
150 rpm
280 rpm
400 mm
400 mm
RO-3000
RO-3000V
3 000 W
3 000 W
280 rpm
120 - 280 rpm
400 mm
400 mm
1
Advertisement
Related Manuals for Roll RO-1800
Summary of Contents for Roll RO-1800
- Page 1 Operation manual / Spare parts list Single disc machines Operation manual Single disc machines Model overview Model RO-1800 RO-2200 RO-3000 RO-3000V Working power 1 800 W 2 500 W 3 000 W 3 000 W Rotation 150 rpm 280 rpm...
- Page 2 Starting the machine Leading the machine Speed regulation After the operation Inspection before, during and after the operation Annex E: Exploding view Ordering information for spare parts Ordering address Exploding view RO-1800 Exploding view RO-3000 / RO-3000V CE Declaration of conformity...
- Page 3 Single disc machines Preliminary notes Dear customer, you have decided for the Roll-single disc machine, the correct choice for quality and performance. This operation manual contains important notes for the operation of your machine. Note Please read the operation manual carefully, in particular the safety notes and ensure that all operators read this operation manual prior to operate the machine.
- Page 4 Operation manual / Spare parts list Single disc machines The operation manual identify important notes on safety and damage prevention using the following symbols: Please comply with these instructions to avoid any damages and injuries. They point to a possible dangerous situation. The nonobservance can lead to the death, to heavy injuries and to material damages.
- Page 5 Single disc machines Guarantee and liability ROLL ensures a guarantee and liability are in accordance with our currently valid general business and sales conditions. The guarantee runs out after 12 months from purchase date. We reject any guarantee claims for tools which are not in their original condition, or for altered or changed tools or which are not used in accordance to the intended use.
- Page 6 Switch of the machine immediately when the operation is completed. Designated use The Roll-single disc machine has been designed and built exclusively for sanding, polishing and cleaning of floors. By no means may the machine be used for the treatment of other surfaces.
- Page 7 Single disc machines Basic safety notes The Roll-single disc machine was designed and constructed for its intended use in accordance with the generally approved rules of technology, the industrial safety and accident prevention regulations, and the directive for the safety of machines of the EC.
- Page 8 The dust can be vacuumed with the optional Roll-vacuum system. Wood dust in combination with an ignition source and the oxygen present in the air, may cause fires and explosions.
- Page 9 The cardboard is usable again and can be used for storage. We recommend to keep the cardboard for the purpose of possible back delivery for the examination or repair. Dimensions / Weight / Technical details Total weight: RO-1800 44,- kg RO-3000 55,- kg...
- Page 10 Operation manual / Spare parts list Single disc machines Assembly The machine is delivered ready to use. The assembly of the sanding or special disc occurs only at the application place. Transport In many cases it is inevitable to transport resp. carry the machine to the point of utilisation. Due to the low weight and the manual measurements no instruction references are required for this.
- Page 11 Operation manual / Spare parts list Single disc machines Liquid tank (optional) The liquid tank is mounted on the handle of the machine and is used to put the cleaning agent onto the floor during the work. Use: Pull the lever of the spray device and dispense the cleansing liquid steadily on the ground. After the use empty the liquid tank to avoid crustification by cleansing liquid.
- Page 12 2. Roll up the connection cable Roll up the cable around the lower cable holder and the handle grip. Attention! Check the cable while rolling up and remove impurities like dust and sanding remainders. 3. Clean the liquid tank...
- Page 13 In order to avoid transmission errors and extensive descriptions it is recommended to use only the part numbers in the spare parts list. Ordering address Address your spare parts order to: Phone: +49(0)7128-92800 Roll GmbH Albstr. 12 Fax: +49(0)7128-928011 E-Mail: info@roll-gmbh.de D-72820 Sonnenbühl...
- Page 14 Operation manual / Spare parts list Single disc machines Exploding view RO-1800 Complete handle Back site Front site Motor covering Machine housing Transportation wheels...
- Page 15 Operation manual / Spare parts list Single disc machines Exploding view RO-1800 Gear Motor Wiring diagram...
- Page 16 Operation manual / Spare parts list Single disc machines Exploding view RO3000 / RO3000V Complete handle Front site 31 Back site 4 Transformator Reinforced machine support...
- Page 17 Operation manual / Spare parts list Single disc machines Exploding view RO3000 / RO3000V Machine housing Motor Transportation wheels Gear Wiring diagram...
- Page 18 Operation manual / Spare parts list Single disc machines CE Declaration of conformity We, Roll GmbH, Albstr. 12, D-72820 Sonnenbühl declare on our own responsibility that this product Single disc machine RO-1800, RO-3000 an RO-3000V, corresponds to the following standards or normative documents:...
