The SCALEREO
system is available in two different variants:
SCALEREO-Desk
Complete 3D microscope system, including a height adjustable desk microscope unit (image
3a) with integrated microscope optics, stereo camera unit and flexible lighting system.
SCALEREO-AddOn
3D video extension kit, including a 3D camera add-on module (image 3b) to upgrade existing
optical microscopes (e.g. Leica M-Series / Olympus / Zeiss / ...) to become a digital 3D video
microscope system.
1. Start-Up
1.1 System components
The Power supply may not be connected until all components
have been connected to the Signal Procession Unit (SPU) correctly!
NEVER disconnect any component while the system is running!
TD_QSG_SCALEREO_EN
Quick Start Guide
Stereo 3D Video Microscope System
–
1
–
2
3a –
3b –
–
4
Rev. 2.0 / 19.04.2022
3D Global Solutions GmbH
Am Krebsgraben 15 / Geb. 2.2
DE-78048 Villingen-Schwenningen
www.3dgs.eu / info@3dgs.eu
Tel: +49 (0) 7721-916 19 60
3D Display
Signal Processing Unit (SPU)
Desk Microscope Unit
AddOn Module
System Control Bar
Page 1 / 4
Advertisement
Table of Contents
Related Manuals for 3D Global SCALEREO
Summary of Contents for 3D Global SCALEREO
- Page 1 3D Global Solutions GmbH Am Krebsgraben 15 / Geb. 2.2 DE-78048 Villingen-Schwenningen www.3dgs.eu / info@3dgs.eu Tel: +49 (0) 7721-916 19 60 Quick Start Guide Stereo 3D Video Microscope System ® The SCALEREO system is available in two different variants: SCALEREO-Desk Complete 3D microscope system, including a height adjustable desk microscope unit (image 3a) with integrated microscope optics, stereo camera unit and flexible lighting system.
- Page 2 Detach the original tube from your optical microscope • Attach the SCALERO AddOn Module instead of the original tube • Optionally attach the tube on top of the SCALEREO AddOn Module for SCALEREO-Desk and SCALEREO-AddOn • Connect the camera signal cable to the SPU •...
- Page 3 Desk-Systems: Move focus-plane downwards 4. Using the system 4.1 Camera adjustments (available only at SCALEREO-Desk) • Short press (< 0,5s) on button ”Z+” or “Z-“ will perform an auto focus adjustment • Long press (> 0,5s) on button ”Z+” or “Z-“ to zoom in or out •...
- Page 4 4.3 Lighting modes (available only at SCALEREO-Desk) There are 7 different modes for the LED light system: Central Ring Left Right Middle Ring Right Ring All 4.4 Headtracking modes 4.4.1 Freeze • Press “Freeze” to instantly pause the headtracking system. The user´s current position is “freezed”...
