Car lift installation, operation and maintenance manual
Type：4SF-4000B
●Electro-Hydraulic 4 post life for wheel alignment
●Pneumatic lock release
●Lifting capacity：4000Kg
INSTALLATION,OPERATION AND MAINTENANCE MANUAL
The instructions is part of the product. Please keep them where you can easily find them as reference.
Read the instructions carefully before starting installation, operation and maintenance.
The manufacturer and its distributor are not liable for any accidents caused by customer's arbitrary modification of
the part or operation.
1
Type：4SF-4000B
Advertisement
Table of Contents
Related Manuals for Safe 4SF-4000B
Summary of Contents for Safe 4SF-4000B
- Page 1 Car lift installation, operation and maintenance manual Type：4SF-4000B Type：4SF-4000B ●Electro-Hydraulic 4 post life for wheel alignment ●Pneumatic lock release ●Lifting capacity：4000Kg INSTALLATION,OPERATION AND MAINTENANCE MANUAL The instructions is part of the product. Please keep them where you can easily find them as reference.
- Page 2 Car lift installation, operation and maintenance manual Type：4SF-4000B INDEX 1.SAFETY INSTRUCTIONS..............................1.1 Statement 1.2 Qualified operator and instructions for use 1.3 Notes 1.4 Warning Signs 1.5 Noise standard 2.INTRODUCTION..............................2.1 Product description 2.2Technical parameter 2.3Main structure of the machine 3.INSTALLATION..............................
-
Page 3: Safety Instructions
Car lift installation, operation and maintenance manual Type：4SF-4000B SAFETY INSTRUCTIONS 1.1 Statement ● We will give the user one-year warranty of quality for the machine. If something wrong with the machine within the term of service, we will repair or replace the product according to the user’s demand. The manufacturer will not take any responsibility for improper installation and operation, overload running, wrong concrete ground (that can not meet the requirements in the manual), normal mechanical abrasion and insufficient maintenance. -
Page 4: Warning Signs
Car lift installation, operation and maintenance manual Type：4SF-4000B Attention： The parking car lift belongs to high-risk products, installation or improper operation, or modify the mechanical components, are likely to cause injury or death of the operator, read the instructions carefully and strictly in accordance with the requirements of work, and do not randomly discharge liquid, protect the surrounding environment。... -
Page 5: Product Description
Car lift installation, operation and maintenance manual Type：4SF-4000B INTRODUCTION 2.1 Product description： A：Four car lift is composed of main and sub column ,beam, bridge,approach bridge, safety mechanism, hydraulic cylinder, power unit, control box,rolling jack and other major components. B：The power unit is switched on, the gear pump operation, promote the hydraulic oil cylinder piston rod, wire rope driven mobile cylinder movement process, because the steel wire rope traction between bridge decks and beams, so as to realize the lift up and down movement, and then achieve the purpose of lifting. -
Page 6: Before Installation
Open the package and check for missing parts in accordance with attachment 1 (complete machine packing list). Once found, contact the distributor or the manufacturer immediately. If leakage is found, installation is still performed,SAFE and distribute shall not be held responsible... -
Page 7: Precautions During Installation
Car lift installation, operation and maintenance manual Type：4SF-4000B Packing dimension drawing 3.2 Precautions during installation ▲ During installation, please observe that the two upright columns are parallel and vertical to the ground, and shall not be tilted. ▲ hydraulic hose and steel cable connection, the joint must be connected in place, so as to avoid oil leakage and steel cable loose. - Page 8 Car lift installation, operation and maintenance manual Type：4SF-4000B <2>: Remove the packing： <3>：Remove the connecting screws between the main bridge board and the packing rack. Hang the main bridge board with the crane and put it in the free space.
- Page 9 Car lift installation, operation and maintenance manual Type：4SF-4000B Main beam 1 piece (no gap) Vice beam 1 piece(gap) <6>:Remove the screw of the main bridge plate under the package and the packing frame,remove the packing frame. Take H: main bridge plate...
- Page 10 Car lift installation, operation and maintenance manual Type：4SF-4000B A:4048 B:2722 C:5267.2 D:4947.5 Step 7：Using the lifting device to position the large parts of lifting machine according to the position below： 7.1,For easy installation, use the “Block the tire bracket ”to pad the beams.
- Page 11 Car lift installation, operation and maintenance manual Type：4SF-4000B Step 9：Contact column and beam： 9.1 Remove M10*30 semicircular head square neck screw , M10 spring washer , M10 flat pad, M10 nut 9.2 Raise the insurance strip in the column (above the beam) As shown below, and follow the direction of the arrow to move the insurance strip and down to push the column into the beam 9.3 Insert the insurance strip into the beam along the inside of the beam end sealing plate...
- Page 12 Car lift installation, operation and maintenance manual Type：4SF-4000B Step 10：Install steel cable limit shaft: Step 11：Install top limit switch: Step 12：Install power unit and control box: Step13：Install four column caps and beam end cover: Step 14：Install approach bridge: Step 15：Installation of oil pipe joints：...
- Page 13 Car lift installation, operation and maintenance manual Type：4SF-4000B Step 16：Install rolling jack: 16.1 The rolling jack outline is shown below 16.2 Rolling jack technical parameter Lifting capacity Rise / fall time Lifting Height Total width Total height 2000kg 《25s 488mm...
- Page 14 Car lift installation, operation and maintenance manual Type：4SF-4000B 17.1 Installation of gas path elements 1.24V electronic valve 2.1/4-￠8mm quick straight head tracheal joint 3. M4*35 cross recessed pan head screw 4. Y￠8mm quick tracheal joint 5. M4*20 cross recessed pan head screw 6. Single connection oil-water separator 7. 1/4-￠8mm quick straight head tracheal joint 8.9.10.11 M6*16 cross recessed pan head screw,spring washers, flat pad, nut...
- Page 15 Attention： 1.The above steps are all the installation steps of the four post car lift， 2.SAFE is committed to continuously improve product quality, update technical specifications, subject to change without notice. 3.4 Check the items after installation 3 、The wire rope is connected in place 1、The upright post is perpendicular to the ground...
-
Page 16: Operation
Otherwise, the manufacturer will not bear any responsibility for the consequence resulted from the operation above mentioned. 4.1.4 The staff or operators shall be in a safe position when the machine lift or lower. 4.1.5 When lifting arms are in high position, The power must be switched off to avoid misoperation by non operating personnel. -
Page 17: Troubleshooting
3.Press the up button to raise the lift to the height you need. Release the lift button and the lift stops immediately. 4.When rises to the required height, check the car is safe, then press down power unit on the unloading valve handle, let the safety lock in place, turn off the power, can work under the carriage. -
Page 18: Maintenance
Car lift installation, operation and maintenance manual Type：4SF-4000B Oil suction pipe loose and fall off Tighten the suction pipe Cushion valve is loose or blocked Tighten or clean the cushion valve Cylinder seal is bad Replace seals Check the oil hose for leaks... -
Page 19: Daily Pre-Operation Check
Car lift installation, operation and maintenance manual Type：4SF-4000B 6.1 Daily pre-operation check The user should perform daily check. Daily check of safety latch system is very important the discovery of device failure before needed could save you from expensive property damage, lost production time, serious personal injury, even death. -
Page 20: Packing List
Car lift installation, operation and maintenance manual Type：4SF-4000B ENCLOSURE Packing list Enclosure 1： Figure No. Name Source Remark Main bridge plate Assembly parts Second bridge plate Assembly parts Main column Assembly parts Sub column Assembly parts Main beam assembly Assembly parts... - Page 21 Car lift installation, operation and maintenance manual Type：4SF-4000B XH-8455Q-6000-02 Hand pressure rod; pneumatic 500mm Outsourcing pump; tubing XH-6435-5000-15 Rolling jack block Outsourcing Control box Outsourcing M5*12 cross head screw Standard parts Galvanized XH-9440Q-6000-01 6 meter telescopic trachea Standard parts Two metal joints...
- Page 22 Car lift installation, operation and maintenance manual Type：4SF-4000B Enclosure 2: dimensions drawing Enclosure 3：Foundation installation drawing Enclosure 4：Hydraulic principle diagram...
- Page 23 Car lift installation, operation and maintenance manual Type：4SF-4000B 1. Oil cylinder, 2. Parachute valve, 3. One-way valve, 4. Relief valve, 5. Electromagnetic unloading valve, 6. Motor, 7. Gear pump, 8. Flow control valve, 9. Filter Enclosure 5：Schematic diagram of electrical equipment SB1: Emergency stop button SB2: Up button SB3: Down button SB4: Lock button KM: A.C.
- Page 24 Car lift installation, operation and maintenance manual Type：4SF-4000B...
