EN Variable Temperature Electric Kettle
User's manual
• Prior to using this appliance, please read the user's manual
thoroughly, even in cases, when one has already familiarised
themselves with previous use of similar types of appliances. Only use
the appliance in the manner described in this user's manual. Keep
this user's manual in a safe place where it can be easily retrieved for
future reference.
• We recommend saving the original cardboard box, packaging
material, purchase receipt and responsibility statement of the vendor
or warranty card for at least the duration of the legal liability for
unsatisfactory performance or quality. In the event of transportation,
we recommend that you pack the appliance in the original box from
the manufacturer.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DESCRIPTION OF THE KETTLE

A1
Open lid button
A2 Lid
A3 Spout
A4 Filtration strainer
(cannot be removed)
A5 Water level mark
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DESCRIPTION OF THE CONTROL PANEL

B1 Temperature setting LED
indicators
B2 On/Off button
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BEFORE FIRST USE OF THE KETTLE
Remove all wrapping material from the kettle and its base A6.
1.
2. Fill the kettle with clean water up to the maximum water mark. Boil
the water and empty the contents of the kettle. Repeat this process
2 to 3 times.
Note:
To boil water in the fast boil kettle proceed according to
the instructions in chapter Using the kettle.
3. Now the kettle is ready for operation.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

USING THE KETTLE

1. Set the desired length of the power cord. Push the power cord into
the groove in the base A6. Place the base A6 on a stable, even and
clean surface.
2. Press button A1 to open the lid A2, then fill the kettle with the
required amount of water. The water level must reach at least the
minimum mark (0.5l) and must not exceed the maximum mark (2l).
After filling it, close the lid A2 and make sure that it is secured in the
closed position.
Attention:
Do not fill the kettle when it is placed on the base A6.
When filling the kettle, there is a risk of water splashing out.
Place the kettle on the base A6 and insert the power cord plug
3.
into a power socket. When the power cord is connected to a power
socket, a short beep will be made and all the LED indicators B1 and
the LED light A9 will light up for an instant and another beep will be
Copyright © 2022, Fast ČR, a.s.
A6 Base with a central connector
A7 Control panel
A8 Handle
A9 LED light for the inside of the
kettle
B3 Set temperature button
– 50, 70, 80 or 90 °C.
made. The kettle will then switch to stand-by mode and is ready for
use. The default temperature setting is 100 °C.
4. Possible uses of the kettle:
4.1 Boil water
• To start the water boiling process, press button B2. A beep confirms
that the button was pressed. The kettle will start heating water to
100 °C. The LED light A9 is lit red. When the water starts to boil, the
kettle will turn off automatically. Two beeps are made and the LED
light A9 will turn off.
Note:
The water boiling process can be stopped at any time by
again pressing button B2.
4.2 Heating water to a selected temperature
• Use button B3 to set the heating temperature 50, 70, 80 or 90 °C.
The temperature setting changes each time button B3 is pressed.
Each press of the button is accompanied by a short beep. The
temperature setting is signalled by the respective LED indicator B1
being lit. To start the process of heating water to the set temperature,
press button B2. LED light A9 will be lit:
– 50°C – dark green (baby porridge)
– 70°C – blue (green tea)
– 80°C – violet (white tea)
– 90°C – light green (instant coffee)
– 100°C – red (black/fruit/herbal tea)
• When the water is heated to the set temperature, the kettle will turn
off automatically. Two beeps are made and the LED light A9 will turn
off. LED indicator B1 remains lit for approximately one minute after it
is turned off. Then it turns off and the kettle switches to the stand-by
mode.
Note:
If you set a temperature using button B3 and then do not
press button B2 to start the water heating process, after 15
seconds the kettle will switch to the stand-by mode and the
respective LED indicator B1 will turn off.
The temperature setting can be changed while the appliance
is running.
The process of heating water to a set temperature can be
stopped at any time by again pressing button B2.
If you set a temperature that is lower than the current
temperature of the water inside the kettle, a beep will be
made after button B2 is pressed and the kettle will turn off
automatically.
4.3 Keep warm mode
• This mode is usually used when you wish to heat water to a required
temperature and then maintain it at this temperature, or when you
wish to boil water and then keep it warm.
• Use button B3 to select the required temperature 50, 70, 80, or
90 °C. The respective LED indicator B1 will be lit. Press button B2 and
hold it down for approx. 3 seconds. The respective LED indicator B1
will start flashing, the coloured LED light A9 will be lit as described
in point 4.2 and the process of heating water to the set temperature
will start. When the set temperature is reached, two beeps are made
and the kettle automatically switches to the keep warm mode. In
this mode, the heating element automatically switches on and
off to maintain the set temperature. The keep warm mode ends
automatically after 30 minutes. Two short beeps are made, the LED
light A9 and the respective LED indicator B1 will turn off, and the kettle
will switch to the stand-by mode.
• Using the above described method, it is possible to set the keep
warm mode after previously boiling or heating water according to
described points 4.1 and 4.2. If, for this mode, you set a temperature
- 4 -
