Blu-ray Disc™ /
DVD Player
BDP1502
Register your product and get support at
www.philips.com/support
User Manual
For further assistance, call the customer
support service in your country.
•
To obtain assistance, contact Philips Customer
Care Center;
In the U.S.A., Canada, Puerto Rico, or the U.S.
Virgin Islands; 1-866-202-5960
Advertisement
Table of Contents
Related Manuals for Philips BDP1502/F7OM
Summary of Contents for Philips BDP1502/F7OM
- Page 1 Register your product and get support at www.philips.com/support For further assistance, call the customer support service in your country. User Manual • To obtain assistance, contact Philips Customer Care Center; In the U.S.A., Canada, Puerto Rico, or the U.S. Virgin Islands; 1-866-202-5960...
-
Page 2: Table Of Contents
Contents Introduction ............3 List of settings ..........31 Safety instruction .............. 3 Setups ............... 35 Included accessories ............6 EasyLink (HDMI CEC) ............ 35 Features .............. 7 HDMI video resolution ..........36 Features ................7 Parental control .............. 37 Version information ............ -
Page 3: Introduction
Register online at www.philips.com/support today to get the most benefits from your purchase. Registering your model with Philips makes you eligible for all of the valuable benefits listed below, so don't miss out. Register online at www.philips.com/support to ensure: * Ad... - Page 4 (2) this device must accept any interference received, including interference that may cause undesired operation. Supplier's declaration of conformity Trade name : PHILIPS Responsible party : Funai Corporation, Inc. Model : BDP1502/F7 A, BDP1502/F7 B...
- Page 5 Laser safety This apparatus is classified as a CLASS 1 LASER PRODUCT. CLASS 1 LASER PRODUCT This apparatus employs a laser. Only a qualified service person should remove the cover or PRODUIT LASER DE CLASSE1 attempt to service this apparatus, due to possible eye injury. CAUTION: Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
-
Page 6: Included Accessories
Important Registering your model with Philips makes you eligible for all of the valuable benefits listed below, so don't miss out. www.philips.com/support to ensure: Register online at... -
Page 7: Features
Features 2.1. Features Blu-ray Disc™ Pop menu You can enjoy Blu-ray Disc™ which is capable of storing Some BD-Videos have a pop menu which is a navigation five times more data than a conventional DVD. menu that can be called up and be operated on the TV screen without interrupting playback. -
Page 8: Version Information
“Version Info” screen provides information about this unit's software version. You can also download the latest software from the Philips website and update it yourself if it is newer than the version currently on your unit. The current version of software on your unit can be seen on the “Version Info” screen. -
Page 9: Functional Overview
Functional overview 3.1. Front panel 3* 4* * The unit can also be turned on by pressing this button. 1. Disc tray 2. Infrared sensor window 3. A (OPEN/CLOSE) button* 4. Kt (PLAY/PAUSE) button* Press to start playback. • During playback, press to pause playback. •... -
Page 10: Remote Control
3.3. Remote control (SKIP) button During playback, press once to return to the • beginning of the current title, chapter, track or file. During playback, press twice to return to the • previous title, chapter, track or file. During JPEG playback, press to return to the •... - Page 11 ■ Using the remote control Note Remote control usage guidelines: Use the included remote control. Remote-control • Make sure that there are no obstacles between the • operation on any other remote control, such as a remote control and the infrared sensor window on the universal remote control, is not guaranteed.
-
Page 12: Guide To On-Screen Display
3.4. Guide to on-screen display ■ Home menu When you turn on the unit, the home menu will appear automatically. Otherwise, press Q (HOME) . Disc Setup 1. “Disc”: Initiates playback of inserted disc, displays a list of tracks / files or the media filter menu. 2. -
Page 13: Connections
Connections 4.1. Connection to a TV ■ HDMI connection (Supports up to 1080i(*1), 1080p(*2), 1080p/24(*3) resolution.) Your TV HDMI cable (not included) HDMI IN (*1) 1080i: Outputs video data with a frame rate of 30 frames per second. (*2) 1080p: Outputs video data with a frame rate of 60 frames per second. -
Page 14: Hdmi Audio Output
4.3. HDMI audio output “AUDIO” > “HDMI audio” setting Bitstream LPCM Re-encode Media Source Dolby Digital Dolby Digital 2ch PCM Dolby Digital Dolby Digital Plus Dolby Digital Plus 2ch PCM Dolby Digital Plus Dolby TrueHD Dolby TrueHD 2ch PCM Dolby TrueHD 2ch PCM DTS-HD High DTS-HD High... -
Page 15: Before You Start
Before you start 5.1. Initial setup After you have completed all of the connections to your TV, review the steps below. Press 9(POWER) to turn on the unit. 2. Turn on your TV. 3. Language setup screen will appear. Use to select your language, then press [OK]. -
Page 16: Information On Playback
Information on playback 6.1. Information on playback ■ Playable discs and files Playable discs Logos Blu-ray Disc™ BD-video • BD-RE* (ver. 2.1) • (Recorded in BDMV format) BD-R* (ver. 1.1 / 1.2 / 1.3) • (Recorded in BDMV format) (Unfinalized disc may not be played back.) DVD-video DVD-RW (finalized video mode discs only) - Page 17 ■ Recommended specifications AVCHD This unit cannot play back stand-alone AVCHD files (*.m2ts, *.mts or *.m2t) written to a DVD or copied to an SD memory card. The DVD or SD memory card containing AVCHD files must have a proper file and folder structure meeting AVCHD format specifications.
- Page 18 ■ Region codes This unit has been designed to play back BD-video with region “A” and DVD-video with region “1” or BD-video “ALL”. You cannot play back BD-video or DVD-video that is labeled for other regions. Look for the symbols on your BD-video or DVD-video. If these region symbols do not appear on your BD-video or DVD-video, you cannot play back the disc on this unit.
-
Page 19: Guide To File List
6.2. Guide to file list ■ Photo file list mixture location multi media size Photo 1 Photo 2 Photo 3 Type:JPG Photo 4 Size:0.069M Photo 5 HDMI Video:800 Photo 6 Photo 7 4 / 20 1. Folder list 2. File list 3. -
Page 20: How To Insert A Disc
6.3. How to insert a disc Press A (OPEN/CLOSE) to open the disc tray. 2. Place the disc on the disc tray with its label side facing up. 3. Press A (OPEN/CLOSE) to close the disc tray. It may take a while to load the disc. •... -
Page 21: Basic Playback
Basic playback 7.1. Playing back a disc Insert a disc (refer to “How to insert a disc” → (page 20)). For Blu-ray Disc™ / DVD / AVCHD / audio CD or a disc containing only one type of file, playback will start •... -
Page 22: Playing Back Contents From A Usb Memory Stick
Note for photo playback Every press of will turn the image by 90 degrees when an image is displayed. • Some unplayable folders or files may be listed due to the recording status. • High-resolution photo files take longer to be displayed. •... -
Page 23: Special Playback
Special playback 8.1. Fast forward / fast reverse During playback, press D (FORWARD) repeatedly for fast forward. During playback, press E (REVERSE) repeatedly for fast reverse. 2. Press K (PLAY) to return to normal playback. Note For Blu-ray Disc™, DVD, AVCHD, audio CD, and music files, speed changes at 5 different levels. •... -
Page 24: Repeat Playback
8.4. Repeat playback Available repeat functions vary depending on the disc. ■ Using [REPEAT] During playback, press [REPEAT]. 2. Use to select the desired repeat mode. You can also change the repeat mode by pressing [REPEAT] repeatedly. • ■ Using [OPTIONS] During playback, press [OPTIONS] to display the play menu. -
Page 25: Slide Show
8.6. Slide show Follow steps 1 and 2 in “Playing back a disc” → (page 21). 2. Open the folder which contains the desired photo files. 3. Use to select a desired file to be played back, then press K (PLAY) or [OK]. An image will be played back from the selected file. -
Page 26: Title / Chapter Search
8.8. Title / chapter search ■ Using (SKIP) / (SKIP) During playback, press (SKIP) to skip the current title or chapter and move to the next. The title or chapter will move forward one at a time. If there is no chapter in a title, the current title may be skipped. •... -
Page 27: Time Search
8.10. Time search During playback, press [OPTIONS] to display the play menu. 2. Use to select “Search”, then press [OK]. 3. Use to select time search, then press [OK]. Blu-ray Disc™ / DVD-Video / AVCHD: “Title Time” or “Chapter Time”. •... -
Page 28: Switching Subtitles
8.12. Switching subtitles Some video materials may have subtitles in one or more languages. For commercially available discs, the supported languages can be found on the disc case. Follow the steps below to switch the subtitle language during playback. ■ Using [SUBTITLE] During playback, press [SUBTITLE]. -
Page 29: Switching Audio Soundtrack
8.13. Switching audio soundtrack When playing back video material recorded with two or more soundtracks (these are often in different audio languages or audio formats), you can switch between them during playback. ■ Using [AUDIO] During playback, press [AUDIO]. Pressing [AUDIO] repeatedly switches the audio. •... -
Page 30: Switching Camera Angles
8.14. Switching camera angles Some BD-videos and DVD-videos contain scenes which have been shot simultaneously from various angles. You can change the camera angle when appears on the TV screen. During playback, press [OPTIONS] to display the play menu. 2. Use to select “Angle”, then press [OK]. -
Page 31: List Of Settings
9. List of settings In “Setup”, you can customize various kinds of settings as you prefer. Refer to the following instructions to navigate through the setup menu. Press Q (HOME) to access the home menu. 2. Use to select “Setup”, then press [OK]. 3. - Page 32 Category Menus / Options Preference Subtitle Bulgarian Italian Chinese Japanese Czech Korean Danish Norwegian Dutch Polish English Portuguese Finnish Romanian French Russian German Slovak Greek Spanish Hungarian Swedish Icelandic Turkish Irish Other Disc menu Bulgarian Italian Chinese Japanese Czech Korean Danish Norwegian Dutch...
- Page 33 Category Menus / Options Accessibility Voice Guide Voice Guide Volume Loud Medium Soft Voice Guide Speed Fast Normal Slow Voice Guide Pitch High Medium Voice Guide Verbosity Detail Basic CC style Auto Custom CC font color Default White Black Green Blue Yellow Magenta...
- Page 34 Category Menus / Options Accessibility CC background color Default White Black Green Blue Yellow Magenta Cyan CC background opacity Solid Translucent Transparent CC window color Default White Black Green Blue Yellow Magenta Cyan CC window opacity Solid Translucent Transparent Note In order to enable the voice guide function, the OSD language needs to be set to English or Spanish.
-
Page 35: Setups
10. Setups 10.1. EasyLink (HDMI CEC) Q(HOME) A “Setup” A “Preference” A “EasyLink” EasyLink(HDMI CEC) allows integrated system control over HDMI and is part of the HDMI standard. This function may not work properly depending on the device connected to the unit. When “EasyLink” setting is set to “On” the functions listed below will be available. -
Page 36: Hdmi Video Resolution
10.2. HDMI video resolution Q(HOME) A “Setup” A “Video” A “HDMI Video” Set the resolution of the video signal being output from the HDMI OUT jack. You can select the desired video resolution among the settings listed below: “Auto”, “480p”, “720p”, “1080i”, “1080p”, “1080p/24”. -
Page 37: Parental Control
10.3. Parental control Some BD-videos or DVD-videos feature parental lock levels. Playback will stop if the ratings of the content exceed the levels you set on the player, it will require you to enter a password before the disc will play back. This feature prevents your children from viewing inappropriate material. -
Page 38: Software Update
You can update the software by using a disc or USB memory stick. Prepare a blank disc or USB memory stick for software update: www.philips.com/support , and download the latest version software to a blank disc or USB memory stick Navigate to using a PC by following the directions described on the website. -
Page 39: Voice Guide
10.5. Voice guide Q(HOME) A “Setup” A “Accessibility” Menus to configure various settings for the voice guide function. to select “Setup” in the home menu, then press [OK]. 2. Use to select “Accessibility”, then press [OK]. 3. Use to select the desired setting, then press [OK]. “Voice Guide”: Turns on/off the voice guide function. -
Page 40: Restore Default Settings
10.6. Restore default settings Q(HOME) A “Setup” A “Advanced” A “Restore default settings” Menus to reset player settings. to select “Setup” in the home menu, then press [OK]. 2. Use to select “Advanced”, then press [OK]. 3. Use to select “Restore default settings”, then press [OK]. 4. -
Page 41: Troubleshooting
11. Troubleshooting Problem No power. Check the AC power cord, if it is properly connected. Try another power outlet. Unplug the AC power cord, and wait for about 5-10 seconds. Plug it back in and attempt to power on the unit. No sound or picture. - Page 42 Problem “BD-ROM Data(USB) Check” Connect a USB memory stick first, then insert the Blu-ray Disc™. message appears when Upon loading a Blu-ray Disc™, this unit will check the USB Memory Stick used – attempting to play a Blu-ray to save necessary information for playback of some BD-ROM discs. Disc™.
- Page 43 Problem Cannot load a Blu-ray Disc™ (stuck Unplug unit from AC outlet for 20 seconds. Plug unit back in and press the in “Loading…” mode) and cannot A (OPEN/CLOSE) on the unit to eject the disc. open the disc tray to eject the disc. Cannot read a USB memory stick.
-
Page 44: Specifications
12. Specifications General Signal system NTSC Color Power requirements 120 V AC, 60 Hz Power consumption 15 W (standby: 0.5 W) Dimensions (width x height x depth) 11.1 x 1.7 x 7.9 inches (280.0 x 41.0 x 198.5 mm) Weight 1.0 kg (2.21 lbs.) Operating temperature 41°F (5°C) to 104°F (40°C) -
Page 45: Maintenance
Eject the disc (if possible), disconnect the USB memory stick (if connected to the unit), place the unit into standby mode, unplug the AC power plug, and please contact: 1-866-202-5960 or visit : www.philips.com/support ■ Cleaning the cabinet Wipe the front panel and other exterior surfaces of the unit with a soft cloth. -
Page 46: Trademark Information
14. Trademark information The terms HDMI, HDMI High-Definition Multimedia Blu-ray Disc™, Blu-ray™, BD-Live™, and the logos are trademarks of the Blu-ray Disc Association. Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the double-D symbol are is a trademark of DVD Format/Logo Licensing trademarks of Dolby Laboratories. -
Page 47: Glossary
15. Glossary AACS Digital audio Advanced Access Content System (AACS) is the content An indirect representation of sound by numbers. During protection scheme used with Blu-ray™ discs. recording, the sound is measured at discrete intervals (44,100 times a second for CD audio) by an analog-to- Analog audio digital converter, generating a stream of numbers. - Page 48 PCM (Pulse Code Modulation) The most common system of encoding digital audio, found on CD and DAT. Excellent quality, but requires a lot of data compared to formats such as Dolby Digital and MPEG audio. For compatibility with digital audio recorders (CD, MD and DAT) and AV amplifiers with digital Inputs, this unit can convert Dolby Digital, DTS, and MPEG audio to PCM.
-
Page 49: Limited Warranty
16. Limited warranty Ninety (90) days limited warranty Warranty coverage: This Limited Warranty does not cover: This warranty obligation is limited to the terms as set forth below. • Shipping charges to return defective product. • Labor charges for installation or setup of the product, adjustment Who is covered: of customer controls on the product, and installation or repair of This product warranty is issued to the original purchaser or the... - Page 50 This product has been manufactured by and is sold under the responsibility of Funai Corporation, Inc., and Funai Corporation, Inc. is the warrantor in relation to this product. The Philips trademark and the Philips Shield Emblem ECU0EUL/ECU03UL are registered trademarks of Koninklijke Philips N.V. used under license.
