- Page 1 BG-VOP-MT HDMI2.0 over IP Multicast Transceiver System with Video Wall support & PoE support User Manual Made in Taiwan...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ........................1 FEATURES ..........................1 PACKAGE CONTENTS ......................2 CONNECTION DIAGRAM ...................... 2 SPECIFICATIONS ........................3 PANEL DESCRIPTIONS ......................4 IR PASS-THROUGH ....................... 6 WARRANTY ..........................7 MISSION STATEMENT......................8... -
Page 3: Introduction
PoE, IR, and RS-232 pass-through. By transmitting the A/V signal over the local area network the BG-VOP-MT makes it easy to add a source or display to your system anywhere there is an active ethernet connection. When combined with broadcasting management software and Gigabit Ethernet network switch (supporting IGMP), BG-VOP-MT is a complete UHD video broadcasting solution for digital signage. -
Page 4: Package Contents
PACKAGE CONTENTS 1x BG-VOP-MT 1x IR blaster cable 1x IR receiver cable 1x User Manual CONNECTION DIAGRAM... -
Page 5: Specifications
SPECIFICATIONS Model Name BG-VOP-MT Technical BG-VOP-MT Role of usage Transmitter HDMI compliance HDMI HDCP compliance Input Video support Up to 4K2K@60 (4:4:4 8bits) Output Video support Up to 4K2K@30 (RGB) Latency 2 frames (33 ms) maximum HDMI over UTP Ultra HD (4K2K60)-120m (396ft) [CAT.X]... -
Page 6: Panel Descriptions
PANEL DESCRIPTIONS 1. USB(USB 2.0 downstream port): Connect to USB flash driver or other USB devices (device configure as RX) 2. RS-232: Connect to PC serial port with a DB-9 male-male cable 3. Dip Switch: Video channel selection 4. IR Blaster: Infrared 3.5mm socket for plugging in the extension cable of IR blaster 5. - Page 7 [ ] configures as a receiver Notes: TX/RX group ID dip-switch setting For ID=1~63, please refer the table below to set up (Hardware control) For ID=64~1023, please adjust the DIP switch to ID=0, and the real ID can be decided by the external software (Software control) Pin1 Pin2...
-
Page 8: Ir Pass-Through
IR PASS-THROUGH [IR Extenders] IR Blaster IR Receiver [IR Sockets] IR BLASTER: plug in the IR blaster to emit all IR command signals received from the IR receiver for device control. IR RECEIVER: plug in the IR receiver to receive all IR command signals from the remote control of the corresponding devices. -
Page 9: Warranty
WARRANTY BZBGEAR wants to assure you peace of mind. We're so confident in the quality of our products that along with the manufacturer's one-year limited warranty, we are offering free second-year warranty coverage upon registration*. Taking advantage of this program is simple, just follow the steps below: 1. -
Page 10: Mission Statement
The unparalleled support from our team is our way of showing we care for every one of our customers. Whether you’re an integrator, home theater enthusiast, or a do-it-yourselfer, BZBGEAR offers the solutions to allow you to focus on your project and not your budget.
