- Page 1 INSTALLATION GUIDE Hisense Laser TV Screen Before installing this product, read this guide carefully and make sure you understand all of the content. ENGLISH ES-L215110...
- Page 2 Structure diagram of laser TV screen 100 inches Parameters for laser TV screen Name Fresnel laser TV screen 100 inches Size 100" Screen material Projection scale 16:9 Projected area 2214 × 1245 mm Net weight 11.7 kg Screen color Grey Screen size 2250 ×...
- Page 3 Overall structure diagram of laser TV screen...
- Page 4 Tool preparation before installation Tape measure ×1 Electric drill × 1 Woodworking pencil × 1 Screw driver × 1 Hammer × 1 Metal detector × 1 Level ruler × 1 Hardware and Parts List The appearance drawn in this manual is a schematic diagram. Please refer to the purchased actual object. After opening the package, please carefully check the parts list.
- Page 5 Code Name Picture Quantity Code Name Picture Quantity Outer frame Outer frame splicing connector connector Long side outer Long side outer frame (Q1) frame (Q2) M3 × 6 outer Short outer frame splicing frame screw M3 × 6 outer Cushion block frame screws Wall hanging Adjusting rod...
- Page 6 Screen assembly steps ( I ) Assemble inner frame First, find the white protective sheet (1) in the packing box, spread out the sheet and lay it on the clean ground for the following installation: 1. Take out all the frames from the foam cotton and gently put them on the sheet separately. Check whether they are missing according to the parts list.
- Page 7 (II) Installation of screen surface 1. Loosen the screws on the brackets at both ends of the paper tube with an M4 Allen screw wrench (Z2), remove the brackets on both sides, slowly remove the screen surface from the paper tube, and wear installation gloves to prevent the screen surface from being stained with sweat.
- Page 8 2. There are 6 fiber rods in total, of which 4 are of the same length and are used for two long sides. Insert 4 fiber (J1) rods into the sleeves of the long sides, and the other 2 slightly longer fiber rods (J2) into the sleeves of the short sides.
- Page 9 3. Slide the screen edges into grooves of the pull rod (N) and pull rod (M) as shown in the illustration below. 4. Center the inner frame on the back of the screen surface.
- Page 10 5. Ensure that the four sides of the screen are aligned with the outer edge of the frame. The M4 × 45 pull nail screw (L) is screwed into the Pull pin nut (K) in pull rod through the hole in the inner frame hole. Install the four corners first according to the installation sequence of 1-1 →...
- Page 11 (III) Install the outer frame After splicing the long side outer frames (Q1) and (Q2) with the outer frame connecting screws (S), slightly lift the inner frame to buckle the outer frame on, and then splice the short outer frame (R) with the outer frame connector (0).
- Page 12 (IV) Paste cushion block Tear off the release film on one side of the cushion block and paste the cushion block on the inner frame as shown in the illustration below. After the screen is hung on the wall, tear off the release film on the other side to fix the lower side of the screen to the wall.
- Page 13 (V) Install wall mounting bracket 1. According to the dimensions in the illustration below, after drilling on the wall with cp8 drill, fix the wall hanging bracket to the wall by inserting the plastic expansion pipe (Z1) into the hole on the wall. 2.
