Summary of Contents for AUTHOR Alarm IGLA
- Page 1 OPERATING MANUAL...
- Page 2 Dear car owner! Please note that the AUTHOR Alarm’s anti-theft devices are not intended for self-installation. We strongly recommend to install and configure the purchased equipment only in certified installation centers. version 803.1 nRF51...
-
Page 3: Table Of Contents
TABLE OF CONTENTS General information ............4 Benefits of the system ............4 OPERATION CONCEPT ............5 Security deactivation ............5 Authorization with the key fob or with smartphone ..5 Authorization with the PIN-code ........6 Anti-Hi-Jack mode .............. 7 Service mode ............... -
Page 4: General Information
General information IGLA is unique device to protect your car from theft. The device has an innovative mechanism of engine locking that uses standard wiring of the car so there is no additional wiring that can be easily found. The... -
Page 5: Operation Concept
If the key fob was not detected (PIN-code was incorrect or was not entered at all), IGLA will lock the engine. In some car models the system switches to the engine start inhibit mode after the engine is shut off. -
Page 6: Authorization With The Pin-Code
In order to log into the system it is enough to have a key fob (if the key fobs were included into IGLA system set) or smartphone paired to the system (if the key fobs were not included into IGLA system set). -
Page 7: Anti-Hi-Jack Mode
It is recommended to enter the PIN-code right before the ride. The interval between the pressing of the buttons shall not exceed 2 seconds. There is no difference between long and short press of the button. When the key fob/smartphone is detected, code there will be 2 indication signals (see the annex), after that you can start driving. - Page 8 3. Press the service button 16-times (16 indication signals will confirm that this mode is switched on). 4. Release the accelerator pedal. The «Anti-Hi-Jack» mode will be trigged automatically if the following conditions are met: • you are logged into the system (via key fob, smartphone or PIN-code) •...
-
Page 9: Service Mode
Service mode The service mode is used for a temporary deactivation of the anti-theft device when you give your car for the maintenance (without giving away the PIN-code and saying about the device). It is better to activate the service mode before the ignition or the engine is off at the end of the trip. -
Page 10: Transport Mode
Transport mode The transport mode is used for temporary switch off the anti-theft system IGLA and in comparison to the Service mode it can be deactivated only via entering PIN-code. This mode should be used when you do not want... -
Page 11: Protection From Key Programming
Use your smartphone as a key fob In order to authorize automatically your smartphone can be used as a key fob if there is no key fobs in the IGLA system set. The car-owner can log into the system manually via entering the PIN-code or automatically using smartphone with IGLA app running in the background mode. - Page 13 Download and install IGLA app using the link or QR- code below: https://itunes.apple.com/ru/app/igla/id1068014851?mt=8 https://play.google.com/store/apps/details?id=com.dma.author.igla ATTENTION! Only one smartphone can be used as a key fob. ATTENTION! Before pairing your smartphone with IGLA system we recommend to switch off all Bluetooth connections in your smartphone with all other devices (Bluetooth module must be ON!).
- Page 14 The color of the «Key» button will change from grey to blue. Now your smartphone will be functioning as a key fob. The connection to the IGLA system is done via the encrypted channel. ATTENTION! Smartphone functioning as a key fob only when Bluetooth is switched ON.
- Page 15 - there will be 2 double indication signals. It is recommended to do this procedure right after the smartphone is lost. If it is necessary to delete your smartphone form the IGLA system, do it in the IGLA app on the tab «Settings».
-
Page 16: Additional Features
ADDITIONAL FEATURES Additional options are activated/deactivated according to the item «Options of the anti-theft IGLA system», page 25. ATTENTION! The additional options are supported depending on the car model and its configuration.* «Comfort» option Some car models* support Comfort option that closes windows and the sunroof when the security system is activated using a standard key fob. -
Page 17: Additional Options
the ignition is off. The option functions only after the authorization. By default the central lock opening option is off. Additional options There are additional options for some car models*, e.g. automatic shutdown START-STOP, indication signal change etc. * See the section System compatibility on the web-site author-alarm.com... -
Page 18: System Settings
An additional locking circuit is activated at the attempt of driving without authorization (or in Anti-Hi-Jack mode) when there is no data in the CAN-bus that needed for the IGLA system or the digital locking has failed. In other cases the activation of the additional circuit is impossible. -
Page 19: Device Number Check
followed by an indication signal. The number of clicks shall be in the range from 3 to 20 clicks. The interval between clicks shall not be more than 2 seconds. There is no difference between long and short press of the button. Different combinations of buttons and their order can be used, e.g. -
Page 20: Change Of The Pin-Code
It is recommended to do this check right after one gets the car with the installed anti-theft system IGLA from the service centre. 1. Switch on the ignition without starting the engine. - Page 21 3. Press the accelerator pedal* as far as it can go and keep it pressed. 4. Enter the current PIN-code once again. The device will pass to the PIN-code change mode and the indication signals will start flashing every 3 seconds. Release the accelerator pedal*.
-
Page 22: Pin-Code Emergency Resetting
The card is a part if the anti-theft system IGLA. Prepare the card before the PIN-code resetting procedure. 1. Switch on the ignition without starting the engine. -
Page 23: Connection And Deleting Of Key Fobs
It is recommended to put the key fob closer to the IGLA system during the procedure of connection. * For some car model other controls are used instead of an accelerator pedal. - Page 24 ATTENTION! The old key fob (from the IGLA system set) cannot be connected to the device. Use only new key fobs bought from the manufacturer.
-
Page 25: Reference Information
** Initial status of an option depends on the car model (see the section «Supported cars» on the web-site author-alarm.com). When this option is switched OFF the IGLA system stalls the running engine via the CAN-bus or additional circuit (depending on the IGLA system installation). - Page 26 The state of option set in the system by default («Switch ON», «Switch OFF») is marked with grey color in the table. The figures in the table show how many times the service button shall be pressed to choose a particular option state.
- Page 27 CONTOUR, a control module for the hood catch, secures the under hood space when working together with the IGLA system. Apart from the hood catch control there is an option for the control of the additional normally closed locking relay.
- Page 28 TOR – a digital CAN-bus relay aimed to provide complex protection of car with the IGLA system installed. TOR uses the additional locking circuit that is activated in case the connection with the engine control unit via CAN -bus is faulty or disrupted. Locking allows to...
- Page 29 Place of device installation ATTENTION! Keep the PIN-code in mind or write it down after you have changed the PIN-code. Do not leave the plastic card with the code as well as this guide inside the car!
- Page 30 (the ignition is off) ............ 6-8 mА Operating voltage ............6-15 V Radio-channel frequency ........2,4 GHz Battery life .............. 6 months Key fob battery type ..........CR2032 List of standard equipment Anti-theft system IGLA 1 pcs Operating manual 1 pcs Installation manual 1 pcs Plastic card «Emergency code and Instruction»...
- Page 31 WARRANTY CERTIFICATE Warranty is 12 months from the date of the purchase. During this period technical support and maintenance are guaranteed for free. The warranty does not apply to the items with: • mechanical damage, burnt and char pieces, components, conductive tracks etc.;...
- Page 32 Supported Cars List App.
Need help?
Do you have a question about the IGLA and is the answer not in the manual?
Questions and answers
After remote starting my truck, key in the pin, put foot on break and shift into gear my truck radio restarts, also it seems like the truck wants to shut down.
The AUTHOR Alarm IGLA system could cause the truck radio to restart and the truck to want to shut down after remote starting if the system does not receive proper authorization, such as the correct PIN code or key fob. Without this authorization, the system may inhibit engine operation via the CAN-bus or an additional circuit, leading to shutdown behavior.
This answer is automatically generated
@Mr. Anderson thank you for your answer, I put the pincode and it flashes twice like usual. When I start my vehicle normal this doesn't happen. Any suggestions how to fix this issue? TIA
