- Page 1 User Manual Model No.: F02SA V2.2...
-
Page 2: Product Features
Hello Thank you for purchasing this camera. Please read the manual carefully before using, and keep it in a safe place for future reference. The screenshots and illustrations used in this manual are to explain the operation of this camera in more detail and intuitively. Operation Guide This camera comes with built-in 64GB EMMC (32GB/128GB optional), no need to insert an extra Micro SD card before using. -
Page 3: Button Instruction
1. OK /Confirm Button 2. Mode Button 3. Power Button 4. Microphone 5. Microphone for Voice control 6. Lens 7. Speaker 8. Back screen 9. Front screen 10. Fill light 11. Magnetic interface 12. Working indicator 13.Charging indicator 14. Reset 15.1/4”... - Page 4 1. Press and hold the Power button to turn on the camera. 2. When camera is on, short press Power button to turn on Wi-Fi. 3. When Wi-Fi is on, short press Power button to turn off Wi-Fi. 4. When in setting mode or playback mode, short press Power button to scroll down the menu.
-
Page 5: Photo Mode
R Button Short press with your nail to turn off the camera when freezing, (Reset) then you can restart the camera. Photo Mode Photo preview interface Photo setting menu 1. Photo mode 2. Number of captured photos 3. Remaining photo quantity of the memory storage 4. - Page 6 Video playback preview interface Photo playback preview interface Delete the files: When “Video/Photo playback preview interface”, click the icon , and click the file you would like to delete, then click the icon again, it pops up the following screenshot, then click the option to delete the files. Delete interface WIFI App Connection The camera allows full control, live previewing and playback of photos/videos on most S...
- Page 7 a. Download the App “Super Cam” from “Google Play” or from the Apple “App Store”. b. Short press the Power button (or click the wifi icon on quick menu) of the camera to turn on WIFI, the "Waiting for WI-FI Connection…" appears on the screen. c.
-
Page 8: App Interface
App interface 1. Mobile phone 2. Connection 3. Camera 4. WiFi SSID 5. Gallery 6. Home... - Page 9 7. APP Version Live-view interface Playback interface Setting interface 1. Exit 2. Photo Mode 3. Confirm/Shutter 4. Playback 5. Video Mode 6. Settings Brief introduction a. Video Recording Click the icon , it will light red during recording; b. Photo Capturing Click the icon , it will flash red once when taking a single picture c.
-
Page 10: Voice Control
Computer download photos / videos When the camera is connected to computer, and used as a removable disk, the removable disk will be added in "My Computer" window. The captured photos or videos will be stored in the " JPG/VIDEO " directory in the removable disk. You can enter this directory to copy files to your computer's hard disk. -
Page 11: Specification
Включите WIFI WiFi を開く Activa WIFI Attiva WIFI WIFI выключен Wifi を閉じる Apaga WIFI Disattiva WIFI Фотографировать 写真を撮る Toma la Foto Scatta la Foto Выключите камеру 電源オフ Apágate Spento Specification... - Page 12 Sensor IMX386 Lens 170 degree wide-angle Display screen Back screen: 2.2 inches; Front screen: 1.4 inches Gyro Support Voice control Support Support Fill light mode Support Storage Built in 64G EMMC(optional 32G / 128G) Support Remote control Support Power input Shrapnel contact, 5v1.5A English, simplified Chinese, traditional Chinese, German, Language...
- Page 13 FCC Caution: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
