THRUNITE Thrower User Manual

Guiding You Through The Night
Thrower
说明书
（CHS）简体中文
+86-0755-26809357
service@thrunite.com
http://www.thrunite.com
广东省深圳市宝安区西乡宝源路168号
名优采购中心A栋640室
Guiding You Through The Night
Thrower
User Manual
（EN）English
+86-0755-26809357
service@thrunite.com
http://www.thrunite.com
Room 640, Tower A,
NO.168 Baoyuan Road, Xixiang,
Baoan, Shenzhen 518102, China
Thrower充电式LED头灯采用最新的SFT40灯珠，最大流明可达1755流明，最大射程可达323米。
规格参数
LED灯珠 光镜
镀膜增透
SFT40*1
钢化玻璃
配件
THRUNITE 3400mAh 18650电池*1，防水圈*2，USB胶塞*1，USB-C充电线*1
极亮档
1755 流明
档位亮度
续航时间
5.5 分钟 + 240 分钟
最大射程
最大光强
防跌落等级
防水等级
注：上述参数只是一个近似值，以THRUNITE 3400mAh 18650电池在实验环境中测试所得，可能会随着手电，电池和使用环境而发生变化。
电量指示灯
电量等级
LED状态
相对电压点
注意：月光模式下指示灯不亮。
操作说明
注意：请在使用前拧紧灯头和灯尾再进行后续操作。
手电开关
单击侧开关即可点亮或关闭手电。
模式切换
手电打开后，长按侧开关即可循环3个不同的模式（低亮-中亮-高亮）。
快捷方式到月光档：手电关闭状态时，长按侧开关即可进入月光档。
任何模式快速按压两次进入极亮档。快速按压三次进入SOS模式。
记忆模式
记忆关机后的任意一个模式，月光、极亮和SOS除外。
低电量提示
当电池电量低于10%，开关处红色指示灯闪烁，提示更换电池或充电。
Thrower rechargeable LED headlamp adopts the SFT40 to make output up to 1755 lumens and max beam distance of 323 meters.
Specifications
LED Lens
Anti-reflective coated
SFT40*1
ultra-clear toughened glass lens
Accessories
THRUNITE 3400mAh 18650 battery *1, Spare O-rings *2, USB rubber plug *1, USB-C Charging Cable *1
1755
lumens
Output
Run time 5.5 mins + 240 mins
Distance
Intensity
Impact Resistance
Waterproof
Notes: The above parameters tested with one THRUNITE 3400mAh 18650 battery are approximate and may vary between lights, batteries and environment.
Indicator
Power Capacity
Indicator
Voltage
Note: The indicator will be OFF in firefly mode.
Operation
CAUTION :Please screw down the light head and tail cap tightly before use.
Turn ON/OFF
Single click the side switch to turn the light on/off.
Change Modes
When the light is on, press and hold the side switch to cycle through low, medium, high.
Shortcut to firefly: When the light is off, long press the side switch to get firefly mode.
Double click quickly to turn to turbo from any mode.Triple click quickly to turn to SOS.
Memory Function
The light will turn on in the last mode used, except firefly, turbo and SOS.
Low Power Indication
When the power capacity is less than 10%, the indicator on the switch will flash red.
Please replace battery or charge the headlamp immediately.
Rechargeable Function
During charging, the indicator is RED. After being fully charged, the indicator will be
BLUE. When indicator flashes purple, it means abnormal charging. Please tighten
the tail cap before use and charge. Only firefly mode is available while charging.
机械参数
光杯 工作电压 材质
光面 2.75V-4.2V AL 6061-T6
ANSI/NEMA FL1参数
照明模式
高亮档
735 流明
373 流明 395 流明
6.5 分钟 + 240 分钟
0% 1 - 10%
无指示 红闪
0-2.6V 2.6-2.8V
Technical Parameters
Reflector Working Voltage
Smooth
2.75V-4.2V
reflector
ANSI/NEMA FL1 Parameters
General Mode
Turbo High
735
lumens
373 lumens 395 lumens
6.5 mins + 240 mins
0% 1 - 10%
Off Flashing red
0-2.6V 2.6-2.8V
表面处理 尺寸
三级硬质氧化 107.5mm*26.5mm*23mm
中亮档 低亮档
258 流明 62 流明
10 小时 48 小时
323米
26100坎德拉
1.5米
IPX-8 水下2米
11 - 20%
红灯常亮
2.8-3.1V
充放电功能
充电中开关处指示灯亮红色，充满后亮蓝色，紫灯闪烁代表充电异常。
使用或者充电时，请拧紧灯头灯尾。充电时，按压侧按按钮只有月光模式。
保修条款
1. 2年免费包换：THRUNITE产品自出售之日起2年内，用户在正常使用情况下，
出现产品质量问题，则享受2年免费包换。
2. 30天无条件退款，邮费自理。
3.终身有限保修：在超过2年免费包换时间外，THRUNITE公司将提供有偿保修，
费用以实际更换材料费用为准，不另收取人工费用。
警示
1. THRUNITE手电亮度高，请勿直视发光体，以免造成视力损伤。
2. 请远离儿童防止其误食。
3. 为了保护电池，电路板以及LED灯珠，我们建议操作极亮模式不要超过10分
钟。
Material Surface Finish Dimension
Premium type III 107.5mm*26.5mm
AL 6061-T6
hard-anodized *23mm
Medium Low
258 lumens 62 lumens
10 hours 48 hours
323 meters (max.)
26100 cd (max.)
1.5 meter
IPX-8 (2M)
11 - 20%
Red
2.8-3.1V
Warranty
1. 2-years free replacement: We will offer free replacement within 2 years of
purchase if problems develop with normal use.
2. 30-days refund by Amazon: You may return most new, unopened items sold
and fulfilled by Amazon within 30 days of delivery for a full refund.
3. Lifetime limited maintenance: As to those exceed 2 years of the purchase
date, we will still provide with maintenance service, but the cost of parts will be
charged and freight should be paid by customers.
Warnings
1. THRUNITE flashlights are high-intensity lighting devices capable of causing
eye damage or other harms, so please avoid shining our light directly into
anyone's eyes.
2. Please keep flashlights away from children.
3. To protect the battery, driver circuit and LED, we Do NOT recommend you run
the light at max mode more than ten minutes.
重量
裸机56g
(不含电池）
月光档 SOS
0.4 流明 600 流明
39 天 5 小时
21 - 100%
蓝灯常亮
3.1-4.2V
Weight
56g
(battery excluded)
Firefly SOS
0.4 lumens 600 lumens
39 days 5 hrs
21 - 100%
Blue
3.1-4.2V
